Поз.
Артикул
Описание
10
ANGLE BUMPER,LEFT
10
ANGLE BUMPER,LEFT
20
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
20
SCREW , Replaced By: N308676014020
20
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
30
NUT BRACKET TO SIDE MEMBER
30
NUT , Replaced By: N910113014001
35
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
35
SCREW , Replaced By: N308676012026
40
NUT SUPPORT TO SIDE MEMBER
50
ANGLE BUMPER,RIGHT
50
ANGLE BUMPER,RIGHT
60
SCREW CONSOLE TO SIDE MEMBER
65
NUT SUPPORT TO SIDE MEMBER
999
VACUUM BOX
999
GASKET OUTSIDE
999
GASKET INSIDE
999
FILTER ELEMENT
999
HOSE
999
FILTER ELEMENT
999
SNAP RING DIA., 128 MM
999
CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, TO BE ADAPTED DURING ASSEMBLY
999
FILTER ELEMENT , Replaced By: A0010941004
999
HOSE CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, Replaced By: A0019951910
999
AIR CLEANER
999
BOOT INTAKE PIPE TO AIR CLEANER, THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE
999
BOOT
999
AIR INTAKE PIPE INTAKE PIPE TO AIR CLEANER
999
SUPPORT
999
AIR INTAKE PIPE
999
CLAMP
999
BOOT INTAKE PIPE TO AIR CLEANER
999
WASHER BRACKET TO CAB REAR PANEL
999
SCREW SHIFT CASE TO SLOTTED GATE
999
SCREW LICENSE PLATE TO BRACKET M 6X18,4 707518
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008027
999
SCREW , Replaced By: N304017008034
999
SCREW BRACKET TO SIDE MEMBER
999
WASHER , Replaced By: N009021008213
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
WASHER , Replaced By: N009021010209
999
WASHER BRACKET TO COVERING
999
SCREW PIPE CLAMP
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
NUT PUMP TO BRACKET
999
NUT , Replaced By: N913004006001
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
CLAMP , Replaced By: A0059971490
