Поз.
Артикул
Описание
5
PLATE ACCELERATOR PEDAL
10
BEARING TUBE ACCELERATOR PEDAL CONTROL,GB718835
10
BEARING TUBE ACCELERATOR PEDAL CONTROL
15
GUARD PLATE ACCELERATOR PEDAL BEARING
20
SCREW CLAMP TO BRACKET AND TO PIPE
25
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
30
LEVER , INAPPLICABLE TO SUPERCHARGING SYSTEMGB718835
35
BALL PIVOT , Replaced By: A3129910120
40
WASHER PULL ROD TO SHIFT LEVER
45
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
50
NUT , Replaced By: N304032008006
95
ROD FROM CONTROL SHAFT TO INTERMEDIATE SHAFT
98
ROD FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
101
NUT , Replaced By: N304032006004
104
BALL SOCKET PULL ROD TO LEVER
107
SNAP RING SPRING-LOADED PUSH ROD
110
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
113
KNOB
131
CLAMP
134
GROMMET
137
SCREWM 6X10
143
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
146
NUT CLAMP TO BRACKET
152
SCREWM 6X12
155
LOCK WASHER CLAMP TO BRACKET
155
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
