Поз.
Артикул
Описание
3
HOSE , Replaced By: A0009872827
3
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
6
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
9
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
9
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
9
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
12
UNION NUT LINE CONNECTION
12
UNION NUT LINE CONNECTION, Replaced By: N000000006239
15
SEAL CONE LINE CONNECTION
15
GLAND , Replaced By: A0019901967
18
SLEEVE LINE CONNECTION
21
LOOM TIE LINE MOUNTING
24
BRAKE VALVE (SERVICE BRAKE VALVE) BOSCH
24
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
24
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
27
VALVEWABCO
30
REPAIR KIT , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO WABCO NR.0182, Replaced By: A0004306360
30
REPAIR KITTO 002 431 06 05,WABCO
30
REPAIR KIT , Replaced By: A0004308206
33
GASKET KITBOSCH
33
REPAIR KIT , Replaced By: A0014308460, +001A0004303506
36
HOLLOW SCREW LINE CONNECTION
36
HOLLOW SCREW HEATING CONNECTION
39
SEAL RING LINE CONNECTION
42
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
45
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
48
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
54
TEST CONNECTION
54
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
54
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
54
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
56
PLUG
58
BANJO UNION BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
60
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR
60
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR,5 234164
60
BRAKE PRESSURE REGULATORWABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
60
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE BOSCH
60
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE,5 234164
60
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
64
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
64
REPAIR KIT BRAKE POWER REGULATOR BOSCH
64
REPAIR KIT COVERING TO 001 431 36 12
64
REPAIR KIT COVERING BOSCH
64
REPAIR KIT VALVE BOSCH
64
REPAIR KIT BRAKE POWER REGULATOR
64
REPAIR KIT , Replaced By: A0004300207
64
REPAIR KIT BRAKE POWER REGULATOR WABCO
66
BRACKET BRAKE POWER REGULATOR
68
BRACKET BRAKE POWER REGULATOR
72
NUT STRAP TO BRACKET
78
SCREW BRACKET TO SIDE MEMBER
78
SCREW , Replaced By: N304017010002
84
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
90
NUT , Replaced By: N910113010000
90
NUT STRAP TO BRACKET
92
SCREW BRACKET TO CROSS CONNECTION STRUT
92
SCREW , Replaced By: N304017008034
94
NUT STRAP TO BRACKET
108
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
110
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
112
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
130
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
136
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
142
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
148
GUIDE SIGN LOAD-DEPENDING BRAKE,5 185308
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6245843721
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE,5 354936
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE
148
GUIDE SIGN LOAD-DEPENDING BRAKE,5 185308
148
GUIDE SIGN LOAD-DEPENDING BRAKE,5 185308
148
GUIDE SIGN LOAD-DEPENDING BRAKE
152
METAL SPRING BELLOWS ,4 957941, Replaced By: A0004311718, +001N000961012047
152
METAL SPRING BELLOWS ,4 9579425 498312
156
METAL SPRING BELLOWS BEARING BRACKET TO REAR AXLE,K 006315
158
BRACKET METAL SPRING BELLOWS,4 428485
158
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6204313740
158
BRACKET METAL SPRING BELLOWS
160
BRACKET METAL SPRING BELLOWS,REAR AXLE I
162
BRACKET LINK
164
SCREW BRACKET TO EXHAUST MUFFLER BRACKET
164
SCREW AT ENGINE MOUNTING,TO MOUNT LINES
170
LOCK WASHER FITTING TO BRACKET
172
WASHER , Replaced By: N000125015019
172
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
176
SCREW , Replaced By: N308676016004
176
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
182
WASHER BEARING BRACKET AND METAL SPRING BELLOWS BRACKET TO REAR AXLE, IN CASE OF STEEL AXLE
182
WASHER BRACKET TO FRAME
182
WASHER , Replaced By: N000125017016
190
ROD , Replaced By: A3954310192
190
ROD BRAKE POWER REGULATOR CONTROL
194
CONNECTOR PULL ROD TO LEVER
198
CLAMP CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
204
CLAMP , Replaced By: N000000000665
204
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
212
LEVER , Replaced By: A6204310839
212
LEVER , Replaced By: A6744310039
212
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
230
CONNECTOR , Replaced By: A0004310735
230
CONNECTOR PULL ROD TO LEVER
236
WASHER , Replaced By: N000125008443
236
WASHER EXHAUST MUFFLER TO STRAP
242
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
248
ROD , Replaced By: N900331008262
248
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
248
ROD , Replaced By: N900331008262
248
ROD
254
CLAMP , Replaced By: N000000000665
254
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
260
NUT
266
LOCK RING PULL ROD TO LINK
999
VALVE (RELAY VALVE) WABCO
999
SPACER TUBE , NOT USED
999
ADHESIVE FOIL GUIDE SIGN
999
NUT BALL PIVOT TO LEVER
999
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
