Поз.
Артикул
Описание
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE WABCO
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER), ONLY REPLACEABLE BY PAIRS
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE GRAU
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE KNORR
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE BOSCH
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER), ONLY REPLACEABLE BY PAIRS
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE WABCO
5
WHEEL BRAKE CYLINDER (COMBINATION CYLINDER),RIGHT, ONLY REPLACEABLE BY PAIRS
5
WHEEL BRAKE CYLINDER FRONT LEFT,DIAPHRAGM CYLINDER, ONLY REPLACEABLE BY PAIRS
8
SPRINGTO WABCO
8
SPRINGTO 017 420 22 18/23 18
11
CUPTO 006 420 28 18,WABCO
11
DIAPHRAGMBOSCH
11
DIAPHRAGMTO 008 420 60 18,62 18,KNORR
17
PLUGTO 694 420 71 18/72 18
17
PLUGBOSCH
20
PISTONBOSCH
23
NUT TAIL LAMP TO BRACKET
29
CUPKNORR
29
CUPTO 007 420 68 18,WABCO
29
CUP , Replaced By: A0004215386
32
REPAIR KIT DIAPHRAGM PART WABCO,K 186393
32
REPAIR KIT (DIAPHRAGM CYLINDER),FRONT AXLE TO WABCO
32
REPAIR KITTO 694 420 73 18/74 18
35
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
47
BRAKE ANCHOR LEFT BRAKE SHAFT
47
BRAKE ANCHOR RIGHT BRAKE SHAFT
50
BUSHING BRAKE CAMSHAFT BEARING,OUTSIDE
50
BUSHING INSIDE
53
BUSHING OUTSIDE
53
BUSHING BRAKE CAMSHAFT BEARING,INSIDE
56
SEAL RING , Replaced By: A0129974147
56
SEAL RING BRAKE CAMSHAFT BEARING IN CASE
56
SEAL RING INSIDE BEARING BRACKET
56
SEAL RING , Replaced By: A0149972247
56
SEAL RING INSIDE BEARING BRACKET
59
SEAL RING OUTSIDE BEARING BRACKET
59
SEAL RING BRAKE CAMSHAFT BEARING
59
SEAL RING OUTSIDE BEARING BRACKET
59
SEAL RING OUTSIDE BEARING BRACKET
62
GREASE NIPPLE INTERMEDIATE LEVER
68
SCREW BEARING BRACKET TO BRAKE ANCHOR
71
NUT BEARING BRACKET TO BRAKE ANCHOR
71
NUT WITH COLLAR
74
BRAKE CAMSHAFT WITH LUBRICATING BORE,LEFT
74
BRAKE CAMSHAFT WITH LUBRICATING BORE,RIGHT
77
SPACER WASHER ADJUSTER TO BRAKE CAMSHAFT
83
ADJUSTER SLACK ADJUSTER "SAB"
89
WORM SCREW"SAB"
92
CONTROL UNIT
95
REPAIR KIT SLACK ADJUSTER "SAB"
113
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
113
PIN WHEEL CYLINDER TO SLACK ADJUSTER
116
WASHER
119
COTTER PIN STRAP TO SUPPORT
122
STOP WASHER SLACK ADJUSTER TO BRAKE SHAFT
125
SPACER WASHER ADJUSTER
128
SPACER WASHER ADJUSTER,AS REQUIRED 1.50 MM
128
SPACER WASHER ADJUSTER,AS REQUIRED 2.00 MM
128
SPACER WASHER ADJUSTER,AS REQUIRED 2.50 MM
128
SPACER WASHER ADJUSTER,AS REQUIRED 0.50 MM
131
LOCK RING ADJUSTER TO BRAKE CAMSHAFT
999
CUPBOSCH/WABCO
