Поз.
Артикул
Описание
83
CYLINDER TRANSVERSE DIFFERENTIAL LOCK
86
GASKET SHIFTING CYLINDER TO INTERMEDIATE FLANGE
89
PISTON TRANSVERSE DIFFERENTIAL LOCK
89
PISTON TRANSVERSE DIFFERENTIAL LOCK
92
SEAL RING SHIFTING CYLINDER
95
NUT
98
HEADLESS SETSCREW TRANSVERSE DIFFERENTIAL LOCK
101
SHAFT SHIFTING ROD,232175
104
SHIFTING FORK LONGITUDINAL DIFFERENTIAL LOCK, MAN AXLE
107
SPRING SHIFTING FORK
110
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
110
SCREW , Replaced By: N304014008001
113
SWITCH , Replaced By: A0015455709
113
SWITCH
116
SEAL RING SWITCH TO CASE COVER
116
SEAL RING ON OIL PUMP HOUSING
119
CYLINDER TRANSVERSE DIFFERENTIAL LOCK
122
GASKET SHIFTING CYLINDER TO INTERMEDIATE FLANGE
125
PISTON TRANSVERSE DIFFERENTIAL LOCK
125
PISTON TRANSVERSE DIFFERENTIAL LOCK
128
SEAL RING SHIFTING CYLINDER
131
HEADLESS SETSCREW TRANSVERSE DIFFERENTIAL LOCK
134
NUT
137
SHAFT SHIFTING ROD,232175
140
SHIFTING FORK DIFFERENTIAL LOCK
143
SPRING SHIFTING FORK
146
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
146
SCREW , Replaced By: N304014008001
149
SWITCH , Replaced By: A0015455709
149
SWITCH
152
SEAL RING SWITCH TO CASE COVER
152
SEAL RING ON OIL PUMP HOUSING
155
LOCK FOLLOWER
158
DIFFERENTIAL LOCK PARTS KIT
161
SCREW REAR AXLE HOUSING TO AXLE CASING M12 X 35
161
SCREW BRACKET TO BRACKET
161
SCREW , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3559901704
999
WHEEL HUB DRIVE , MAN AXLE
999
WHEEL HUB DRIVE , MAN AXLE
999
SIDE GEAR , MAN AXLE
999
WHEEL HUB DRIVE WHEEL HUB DRIVE
999
DIFFERENTIAL PINION , MAN AXLE
999
SIDE GEAR P.T.O.
999
DIFFERENTIAL PINION THROUGH-DRIVE DIFFERENTIAL GEAR
