Поз.
Артикул
Описание
652
SCREW BRACKET TO THROTTLE HOUSING
652
SCREW , Replaced By: A1249902101
653
SPRING WASHER GROUND CABLE TO TRANSMISSION
655
OIL FILLER PIPE , UP TO CHASSIS 003544
657
OIL DIPSTICK
658
HOLLOW SCREW , Replaced By: N915036010108
658
HOLLOW SCREW FUEL LINE TO FEED PUMP
659
SEAL RING INJECTION PUMP
660
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
660
SCREW , Replaced By: N304017008016
661
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
662
LINE , FROM CHASSIS 036081, Replaced By: A1232701347, +001A1162700241, +001A1232700079, +001A1129970381, +001A1159975082
662
LINE , Replaced By: A1232701347, +001A1162700241, +001A1232700079, +001A1129970381, +001A1159975082
662
LINE , Replaced By: A1232701347, +001A1162700241, +001A1232700079, +001A1129970381, +001A1159975082
662
LINE
663
HOLLOW SCREW OIL LINE
664
SEAL RINGTO 001 431 72 14
665
GROMMET OIL LINE TO CONVERTER HOUSING,313761
668
HOLLOW SCREW OIL LINE TO CONVERTER HOUSING
669
SEAL RING
672
GROMMET OIL LINE TO CONVERTER HOUSING
673
CLAMP OIL LINE TO CONVERTER HOUSING
674
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
675
SCREW BEARING BRACKET TO TRANSMISSION
676
BRACKET
677
BRACKET
678
CLAMP FLEXIBLE SHAFT TO BRACKET, TO BE ADAPTED DURING ASSEMBLY
679
BUSHING OIL LINES TO ENGINE,001498
681
BRACKET ELECTRIC CABLE TO KICK-DOWN SOLENOID VALVE
999
FLANGE , WITH 108 270 09 01: UP TO TRANSMISSION 033564 NO LONGER AVAILABLE
999
GUARD PLATE , 013131 EXCEPT FOR 010364-010763
999
DISC SUPPORT ,017085
999
GUARD PLATE
999
GUARD PLATE
999
SEAL RING , Replaced By: A0119976447
999
CASE ,026754
999
DRIVE GEAR ,015265
999
SEAL RING
999
GUIDE
999
SPACER WASHER
999
INTERMEDIATE PLATE ,024694
999
DETENT
999
LOCKING SHEET ,019885
999
INTERMEDIATE PLATE ,024694
999
SCREW , TO 115 270 12 11, 115 270 17 11
999
LOCKING SHEET ,042334, Replaced By: A1152771183, +001A1152772880
999
VALVE PART
999
SCREW , TO 115 270 27 11, 115 270 30 11, 115 270 39 11
999
SHIFT VALVE
999
SHIFT VALVE , NO LONGER AVAILABLE
999
GASKET , Replaced By: A1152773280
999
SHIFT VALVE
999
VALVE PART
999
GASKET , Replaced By: A1152772980
999
INTERMEDIATE PLATE , TO 115 270 33 07
999
SHIFT VALVE
999
SHIFT VALVE
999
VALVE BODY ASSEMBLY
999
COVER
999
HOUSING
999
SHIFT VALVE
999
FLANGE
999
BOOT
999
BOOT
999
BOOT
999
SEAL RING
999
BOOT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3162720792
999
BOOT
999
PIN
999
PISTON , WITH 108 270 09 01: UP TO TRANSMISSION 033564
999
BOOT
999
BOOT
999
SEAL RING , Replaced By: A3162720455
999
PLANET GEAR
999
BOOT
999
SEAL RING
999
PISTON
999
ANNULUS , NO LONGER AVAILABLE INDIVIDUALLY
999
SPACER WASHER 0.5 MM,AS REQUIRED
999
SPACER WASHER AS REQUIRED 0.2 MM
999
SPACER WASHER 0.5 MM,AS REQUIRED
999
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.20 MM
999
SPACER WASHER AS REQUIRED 0.5 MM
999
SPACER WASHER AS REQUIRED 0.2 MM
999
BRAKE BAND
999
BRAKE BAND
999
PLANETARY CARRIER
999
TRANSMISSION CASE , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365, Replaced By: A1152705911, +001A1092700689, +001A1092701189
999
BRAKE BAND , Replaced By: A1152707362
999
DRIVE SHAFT , 053009
999
TRANSMISSION CASE , FROM TRANSMISSION: 115.000,002,010,015 031535 115.100,102,103,110,112,115 024366, Replaced By: A1152707711, +001A1152700457
999
BRAKE BAND , Replaced By: A1152707062
999
PLANETARY CARRIER , 053009
999
PISTON
999
DRIVE SHAFT ,029735043589 NO LONGER AVAILABLE
999
PISTON ,019885
999
DRIVE SHAFT ,031315
999
DRIVE SHAFT , Replaced By: A1152705425, +001A0029942641
999
DRIVE SHAFT , FROM TRANSMISSION: 115.000,002,010,015 015645-043913 115.100,102,103,110,112,115 013132-031415, Replaced By: A1152705925, +001A1152721155
999
DRIVE SHAFT ,022985
999
DRIVE SHAFT ,009363
999
VALVE BODY ASSEMBLY
999
TRANSMISSION CASE ,019885
999
PLANETARY CARRIER , FROM TRANSMISSION: 115.000,002,010,015 015645-043913 115.100,102,103,110,112,115 013132-031415, Replaced By: A1152705643, +001A1152721155
999
PLANETARY CARRIER , 013131 EXCEPT FOR 010364-010763
999
GASKET KIT
999
BUSHING
999
GASKET KIT ,019885
999
VALVE BODY ASSEMBLY
999
BUSHING , UP TO TRANSMISSION 000,002,010,015 012077 100,102,103,110,112,115 009785, Replaced By: A1152702150, +001A1152704120, +001A1152721407, +001A1092720326, +002A1092722326
999
GOVERNOR ,024694
999
VALVE ,019885
999
BUSHING , UP TO TRANSMISSION 000,002,010,015 012077 100,102,103,110,112,115 009785, Replaced By: A1152702150, +001A1152704120, +001A1152721407, +001A1092720326, +002A1092722326
999
VALVE ,024694
999
GUIDE TUBE , AGAINST SQUEALING OF TRANSMISSION
999
TRANSMISSION CASE ,019885
999
THRUST PIN
999
BRACKET
999
REGULATOR VALVE
999
GASKET KIT , Replaced By: A1152702201
999
GASKET KIT , Replaced By: A1152702001
999
OIL PAN
999
BUSHING , UP TO CHASSIS: 000,002,010 056141 015 060261 100,102,103,110,112 139360 115 065085 FROM CHASSIS: 000,002,010 095002 015 115531 100,102,103,110,112 244263 115 122228
999
GUIDE PIVOT
999
CAP
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 111660 015 143500 100,102,103,110,112 295223 115 150670 005,017,105,107,108,117,119 000001
999
SHIFT LEVER , 019136
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 095002 015 115531 100,102,103,110,112 244263 115 122228 UP TO CHASSIS: 000,002,010 111659 015 143499 100,102,103,110,112 295222 115 150669, Replaced By: A1152604539, +001A1152670114, +001A1152680172
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 095002 015 115531 100,102,103,110,112 244263 115 122228 UP TO CHASSIS: 000,002,010 117631 015 154063 100,102,103,110,112 315098 115 161611, Replaced By: A1152604439, +001A1152670114, +001A1152680172
999
SHIFT LEVER , FROM CHASSIS: LESS POWER STEERING 000,002,010 20/60 088430 015 20/60 104519 100,102,103,110,112 20/60 225573 115 20/60 111936 FROM CHASSIS: WITH POWER STEERING 000,002,010 20/60 088396 015 20/60 104453 100,102,103,110,112 20/60 225471 115 20/60 111824 FROM CHASSIS: LESS POWER STEERING 000,002,010 22/62 087647 015 22/62 103137 100,102,103,110,112 22/62 222276 115 22/62 110305 FROM CHASSIS: WITH POWER STEERING 000,002,010 22/62 086764 015 22/62 101812 100,102,103,110,112 22/62 220495 115 22/62 109110 UP TO CHASSIS: 000,002,010 095001 015 115530 100,102,103,110,112 244262 115 122227, Replaced By: A1152604539, +001A1152670114, +001A1152680550, +001A1152680172, +001N007346005000
999
SHIFT LEVER , FROM CHASSIS: LESS POWER STEERING 000,002,010 10/50 085059 015 10/50 099480 100,102,103,110,112 10/50 216012 115 10/50 106668 FROM CHASSIS: WITH POWER STEERING 000,002,010 10/50 086622 015 10/50 101629 100,102,103,110,112 10/50 220100 115 10/50 108872 FROM CHASSIS: LESS POWER STEERING 000,002,010 12/52 086675 015 12/52 101862 100,102,103,110,112 12/52 220490 115 12/52 109122 FROM CHASSIS: WITH POWER STEERING 000,002,010 12/52 083151 015 12/52 097115 100,102,103,110,112 12/52 211906 115 12/52 104334 UP TO CHASSIS: 000,002,010 095001 015 115530 100,102,103,110,112 244262 115 122227, Replaced By: A1152604439, +001A1152680550, +001A1152680172, +001N007346005000
999
SHIFT LEVER , FROM CHASSIS: 000,002,010 056142 015 060262 100,102,103,110,112 139361 115 065086 UP TO CHASSIS: LESS POWER STEERING 000,002,010 12/52 086674 015 12/52 101861 100,102,103,110,112 12/52 220489 115 12/52 109121 UP TO CHASSIS: WITH POWER STEERING 000,002,010 12/52 083150 015 12/52 097114 100,102,103,110,112 12/52 211905 115 12/52 104333, Replaced By: A1152604439, +001A1152681442, +001A1152680172
999
LINE , Replaced By: A1232700396
999
LINE LEFT
999
FILTER RANGE OF DELIVERY COMPRISES:, 021,023 FROM TRANSMISSION 006751-009935, FROM TRANSMISSION 023011
999
PLUG , 014 FROM TRANSMISSION 000904, 015 FROM TRANSMISSION 006447
999
SPRING , NO LONGER AVAILABLE 015 FROM TRANSMISSION 005208
999
SPRING OUTSIDE, NO LONGER AVAILABLE
999
SPRING
999
SPRING , NO LONGER AVAILABLE
999
SPRING
999
SPACER TUBE
999
PIN REPAIR SIZE 5.5 MM, NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
999
BUSHING
999
PIN AS REQUIRED 82 MM
999
PIN AS REQUIRED 81 MM, 015 FROM TRANSMISSION 002756
999
PIN 37 MM AS REQUIRED
999
PIN AS REQUIRED 36 MM
999
INSULATING RING
999
INSULATING RING , NO LONGER AVAILABLE
999
GUARD PLATE , 015 FROM TRANSMISSION 005208
999
BOOT , Replaced By: A1152720692
999
SPACER WASHER AS REQUIRED 0.1 MM
999
SPACER WASHER , Replaced By: A1122720652
999
SPACER WASHER 0.15 MM
999
SPACER WASHER 0.20 MM
999
SPACER WASHER , Replaced By: A1122720052
999
SPACER WASHER AS REQUIRED 0.7 MM
999
SPACER WASHER AS REQUIRED 0.5 MM
999
BUSHING
999
SPACER WASHER 0.5 MM
999
SPACER WASHER , Replaced By: A1122710052
999
SPACER WASHER0.1 MM, NO LONGER AVAILABLE
999
GASKET KIT
999
GASKET KIT , Replaced By: A1122701800
999
SLOTTED GATE
999
GUIDE PIVOT
999
SHIFTING ROD
999
SHIFTING ROD
999
LEVER
999
LEVER , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
LEVER
999
SEAL RING
999
SEAL RING
999
CLAMP , NO LONGER AVAILABLE
999
BALL
999
BUSHING
999
SHAFT
999
RUBBER PAD
999
BEARING
999
RUBBER RING
999
LEVER
999
SCREW , 024,025 FROM CHASSIS 002864 ALSO INSTALLED ON, SEE FOOTNOTE 3 024,025 UP TO CHASSIS 004834, 026,027 UP TO CHASSIS 001398
999
NUT , WITH L.H.D,ON MODELS 111.024,025 FROM STEERING 198396 WITH R.H.D,ON MODELS 111.024,025 FROM STEERING 199281
999
PIN 26 MM,AS REQUIRED
999
PIN 25 MM,AS REQUIRED
999
PIN AS REQUIRED 24 MM
999
PIN AS REQUIRED 23 MM
999
OUTER DISC , WITH 108 270 09 01: FROM TRANSMISSION 025698-033564 ALSO INSTALLED ON 020066-023715, WITH 108 270 13 01: FROM TRANSMISSION 000 001
999
BOOT , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
BOOT
999
GASKET
999
GASKET , Replaced By: A1092710180
999
GEAR INDICATOR , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
GEAR INDICATOR , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
LEVER , 016 UP TO CHASSIS 027622 EXCEPT FOR, SEE FOOTNOTE 3, 018 UP TO CHASSIS 012 FROM CHASSIS 058444 ALSO INSTALLED ON, SEE FOOTNOTE 80, 014 FROM CHASSIS 045294 ALSO INSTALLED ON, SEE FOOTNOTE 81
999
SLOTTED GATE , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
LOCK
999
SLOTTED GATE , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
HOUSING
