Поз.
Артикул
Описание
5
PLANETARY GEARING AVAILABLE AS AN ASSEMBLY ONLY I1:3.167, V 207699
8
BELL HUB WITH PLANETARY CARRIER
11
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
11
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
11
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
14
THRUST WASHER PLANETARY GEAR TRAIN
17
NEEDLE PLANETARY GEAR TRAIN
20
THRUST WASHER PLANETARY GEAR TRAIN
23
OUTER RACE NEEDLE BEARING
26
OUTER RACE NEEDLE BEARING
29
THRUST WASHER PLANETARY GEAR TRAIN
32
LOCK RING PLANETARY GEAR TRAIN
35
PLANET GEAR PARTS KIT, V 208582
38
WHEEL HUB CASTING
41
TAPERED ROLLER BEARING PLANETARY GEAR TRAIN
41
TAPERED ROLLER BEARING PLANETARY GEAR TRAIN
41
TAPERED ROLLER BEARING PLANETARY GEAR TRAIN
44
OIL COLLECTOR , Replaced By: A3553560882
47
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
47
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
47
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
47
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
53
COVER PLATE WHEEL HUB, INSIDE
56
SEAL RING WHEEL HUB, INSIDE, ORDER ADDITIONALLY: A 015 997 49 47
56
SEAL RING FRONT WHEEL HUB,OUTSIDE, ONLY APPLICABLE TO MODELS: 748.271
56
SEAL RING WHEEL HUB, INSIDE, ORDER ADDITIONALLY: A 015 997 90 45
56
RADIAL SHAFT SEALING RING WHEEL HUB, OUTSIDE, ORDER ADDITIONALLY: A 013 997 89 46
59
THRUST RING WHEEL BEARING
62
OUTSIDE GEAR
65
SUPPORT OUTSIDE GEAR, V 207287
68
WIRE RING OUTSIDE GEAR TO SUPPORT
71
REAR AXLE SHAFT LESS INTERLOCK SERRATIONS
71
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS
74
LOCK PLATE WHEEL HUB TO AXLE JOURNAL
77
GROOVED NUT WHEEL HUB TO REAR AXLE TUBE
77
GROOVED NUT HUB AND SUPPORT TO AXLE CASING
80
SNAP RING
83
SUN GEAR NUMBER OF TEETH: 30
86
THRUST WASHER
89
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.80 MM
92
RETAINING RING MOUNTING TO WHEEL HUB 108X4.0
98
WHEEL MOUNTING BOLT DISC WHEEL TO REAR DRUM HUB, Replaced By: A0004013471
98
WHEEL MOUNTING BOLT DISC WHEEL TO REAR DRUM HUB M 22X1.5X105, Replaced By: A0004013871
98
WHEEL MOUNTING BOLT DISC WHEEL TO AXLE M 22X1.5X105
98
WHEEL MOUNTING BOLT DISC WHEEL TO REAR DRUM HUB
101
CAPSCREW W HEXAL. DRIVE BRACKET TO PUMP M12X25
104
SEAL RING PLANETARY GEAR TRAIN TO REAR WHEEL HUB
107
HUB CAP BELL HUB
110
GASKET COVER TO HUB
113
SCREW COVER TO BELL HUB
116
SCREW PLUG OIL DRAIN
119
SEALING RING. SEAL RING OIL DRAIN
122
SCREW PLUG OIL FILLING
125
SEALING RING OIL FILLING
999
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS
999
REAR AXLE SHAFT LESS INTERLOCK SERRATIONS
