Поз.
Артикул
Описание
1
RESERVOIR INSIDE, THEFT-RELEVANT PART
2
RESERVOIR BOTTOM
2
RESERVOIR BOTTOM
2
RESERVOIR BOTTOM
2
RESERVOIR COMPRESSED AIR 60 L.
2
RESERVOIR ,5 936755, Replaced By: A0034322701, +002A0009970934
2
RESERVOIR40L,276 MM,8.5 BAR
2
RESERVOIR , Replaced By: A0034322501
2
RESERVOIR , Replaced By: A0024320501
4
DISTRIBUTOR AT AIR RESERVOIR
6
PRESSURE REGULATOR WITH REFILL CONNECTION
7
REPAIR KIT , UP TO 625
7
REPAIR KIT , FROM 626
9
T-FITTING COMPRESSED AIR VALVE CONNECTION
10
ADAPTER FITTING RESERVOIR TO SUPPORT
10
ADAPTER FITTING RESERVOIR TO SUPPORT
10
ADAPTER FITTING RESERVOIR TO SUPPORT
10
ADAPTER FITTING RESERVOIR TO SUPPORT
11
T-FITTING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
12
THRUST RING CHECK VALVE TO AIR RESERVOIR
12
THRUST RING CHECK VALVE TO AIR RESERVOIR
12
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
13
O-RING CHECK VALVE TO AIR RESERVOIR
13
O-RING CHECK VALVE TO AIR RESERVOIR
14
NUT CHECK VALVE TO AIR RESERVOIR
14
NUT CHECK VALVE TO AIR RESERVOIR
15
VALVE PRESSURE LIMIT,K 025180
15
VALVE ,K 025179, Replaced By: A0044297044
15
VALVE PRESSURE LIMIT,K 025180
15
VALVE ,K 025179, Replaced By: A0044297044
15
VALVE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 903131, Replaced By: A0034295044
16
FITTING LINE MOUNTING
16
FITTING , Replaced By: N074304022201
17
SEAL RING VALVE TO VALVE,K 025179
18
SWITCH PRESSURE SWITCH M 24 X 1 MM
19
SEAL RING PNEUMATIC VALVE
19
SEAL RING , Replaced By: N007603010110
20
T-FITTING
22
THRUST RING CHECK VALVE TO AIR RESERVOIR
22
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
24
O-RING CHECK VALVE TO AIR RESERVOIR
26
NUT CHECK VALVE TO AIR RESERVOIR
28
CROSS FITTING AIR RESERVOIRS I,II,III
30
CONSOLE AIR RESERVOIR
32
SCREW , Replaced By: N308676012012
32
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
34
LOCK WASHER FITTING TO BRACKET
36
FITTING , Replaced By: A0039972072
36
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
36
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236
38
TEST CONNECTION
38
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
38
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
38
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
199
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 24X1
199
PLUG SOCKET , Replaced By: A3805402181
199
PLUG SOCKET , Replaced By: A3805400181
999
BRACKET AT SIDE MEMBER
999
PLUG
999
SPRING
999
SPRINGTO 002 430 69 01
999
SPRING
999
INSTRUCTION PLATE IN GERMAN
999
WASHERTO 002 430 41 01, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
SCREWTO 003 430 72 01,SCHAEFER
999
COVER. THREADED UNION
999
WASHER , Replaced By: A0004311176
999
COVERING
