Поз.
Артикул
Описание
2
COVER
2
COVER , 015 UP TO TRANSMISSION 005207, Replaced By: A1122700705, +001A1129970530, +001N007603010101
3
SCREW PLUG , 021,023 FROM TRANSMISSION 024425
4
SEAL RINGTO 001 431 72 14
5
SEAL RING
6
HOUSING WITH PRIMARY PUMP
7
SEAL RING
8
SEAL RING
9
SPRING WASHER
10
SCREW
11
GASKET
11
GASKET , Replaced By: A1122711380
12
SPACER WASHER0.1 MM, NO LONGER AVAILABLE
13
THRUST WASHER
14
SCREW
15
SCREW
16
SPRING WASHER BRACKET TO PEDAL ASSEMBLY BEARING BRACKET, 000,001,004,010 UP TO CHASSIS 064105 EXCEPT FOR, SEE FOOTNOTE 2, 10/50, 20/60, 100,101,104,110 UP TO CHASSIS 099641 EXCEPT FOR , SEE FOOTNOTE 3, ALSO INSTALLED ON 099892
17
FLANGE
18
GUARD PLATE
19
SEAL RING
20
FLANGE , 015 FROM TRANSMISSION 005208
21
PISTON
21
PISTON , 000040, Replaced By: A1122722331, +001A3162720792
22
SEAL RING , 015 UP TO TRANSMISSION 000040, Replaced By: A1152721292, +001A1122722231
22
BOOT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3162720792
22
BOOT
23
BOOT
24
SPRING
25
SPRING RETAINER
26
SNAP RING
27
OUTER DISC 2.0 MM
28
INNER DISC
29
GUARD PLATE 0.6 MM
30
SPRING
31
GUARD PLATE , 015 FROM TRANSMISSION 005208
32
LOCK
33
DRIVE SHAFT
34
GUARD PLATE , NO LONGER AVAILABLE
54
PLANETARY CARRIER FRONT PLANETARY GEAR TRAIN
55
GUARD PLATE , NO LONGER AVAILABLE
56
GUARD PLATE , NO LONGER AVAILABLE
57
PIN
58
SPRING
59
BALL SHIFTING CYLINDER
60
RING , NO LONGER AVAILABLE
61
LOCK RING
62
SEAL RING DRIVE SHAFT
63
GUARD PLATE , NO LONGER AVAILABLE
64
FLANGE , 015 FROM TRANSMISSION 005208
64
FLANGE , 015 UP TO TRANSMISSION 005207, Replaced By: A1122703920, +001A1152721492
64
FLANGE , 015 UP TO TRANSMISSION 005207, Replaced By: A1122703920, +001A1152721492
64
FLANGE , 015 UP TO TRANSMISSION 005207, Replaced By: A1122703920, +001A1152721492
65
PISTON , 000040, Replaced By: A1122722231, +001A3162720792
65
PISTON , NO LONGER AVAILABLE
66
SEAL RING , 015 UP TO TRANSMISSION 000040, Replaced By: A1152721292, +001A1122722231
66
BOOT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3162720792
66
BOOT
67
SPRING
68
BOOT
69
SPRING RETAINER
70
SNAP RING
71
NEEDLE BEARING
72
OUTER DISC 2.0 MM
73
OUTER DISC , 021,023 UP TO TRANSMISSION 001944, Replaced By: A1122721126, +001A1122721226
73
OUTER DISC , 012, 014 FROM TRANSMISSION 001945, 015 FROM TRANSMISSION 007429
74
INNER DISC
74
INNER DISC , 003528, Replaced By: A1122720225, +002A1092720826
75
GUARD PLATE 0.6 MM
84
LOCK
93
SCREW BRACKET TO CROSS CONNECTION STRUT
93
SCREW , Replaced By: N304017008034
94
SPRING WASHER GROUND CABLE TO TRANSMISSION
999
NUT RETAINER HEATER CASE TO FIRE WALL
999
SEAL RING FUEL LINE TO SIDE MEMBER
999
SEAL RING , 015 UP TO TRANSMISSION 005207
999
OUTER DISC , Replaced By: A1092721826
999
SPACER WASHER AS REQUIRED 0.2 MM, 015 FROM TRANSMISSION 005208
999
SHIFTING ROD
999
LOCK
999
DRIVE SHAFT , 015 FROM TRANSMISSION 005208 NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
999
OUTER DISC
999
OUTER DISC , 017664 EXCEPT FOR 015709-017194
999
BREATHER TRANSFER CASE
999
KNOB LIGHT IVORY-COLORED, 000,001,004,010,016 UP TO CHASSIS 130558, 100,101,104,110 UP TO CHASSIS 225648 ON SPECIAL REQUEST
999
OIL FILLER PIPE , 000,001,004,010,016 UP TO CHASSIS 130557, 100,101,104,110,116 UP TO CHASSIS 225647
999
FLANGE , 000,001,004,010,016 UP TO TRANSMISSION 003600
999
LINE , 014 UP TO ENGINE 005623 EXCEPT FOR 005409,005527-005529,021,023 UP TO ENGINE 001892 EXCEPT FOR 001805,001806,001871,001872
999
BRACKET
999
SEAL RING , 004963, Replaced By: A1112720092, +001A1112720431
999
BOOT , 000,001,004,010,016 UP TO TRANSMISSION 003600
999
GUARD PLATE , 008595
999
PISTON , 004963, Replaced By: A1112720431, +001A1112720092
999
PISTON , 000,001,004,010,016 UP TO TRANSMISSION 003600
999
GUARD PLATE , 008596-015979
999
BRACKET , 010 UP TO ENGINE 000082,012 UP TO ENGINE 001683
999
GUIDE PLATE , 000,001,004,010 UP TO CHASSIS 096131, 100,101,104,110 UP TO CHASSIS 156041
999
SHIFTING SEGMENT , 000,001,004,010 UP TO CHASSIS 096131, 100,101,104,110 UP TO CHASSIS 156041
999
SHIFTING SEGMENT , 000,001,004,010 UP TO CHASSIS 096131, 100,101,104,110 UP TO CHASSIS 156041
999
SHIFTING SEGMENT , 000,001,004,010 FROM CHASSIS 096132, 100,101,104,110 FROM CHASSIS 156042 000,001,004,010 UP TO CHASSIS 130557, 100,101,104,110 UP TO CHASSIS 225647
999
SLOTTED GATE , 000,001,004,010 UP TO CHASSIS 096131, 100,101,104,110 UP TO CHASSIS 156041
999
GASKET KIT , Replaced By: A1122701800
999
HOUSING , 015 UP TO TRANSMISSION 005207
999
DRIVE SHAFT
999
BREATHER REPAIR SIZE, 012, 014 UP TO TRANSMISSION 006059, 015 UP TO TRANSMISSION 008636
999
DRIVE SHAFT , 015 UP TO TRANSMISSION 005207
999
REGULATOR VALVE , NO LONGER AVAILABLE
999
VALVE BODY ASSEMBLY , 015 UP TO TRANSMISSION 005207 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE BODY ASSEMBLY , 015 UP TO TRANSMISSION 005207
999
VALVE BODY ASSEMBLY
999
VALVE BODY ASSEMBLY , NO LONGER AVAILABLE 015 UP TO TRANSMISSION 005207
999
PLANETARY CARRIER , 015 UP TO TRANSMISSION 005207
999
GASKET KIT
999
FLANGE , 015 UP TO TRANSMISSION 005207
999
SPACER WASHER , Replaced By: A1122710052
999
SPACER WASHER 0.5 MM
999
BUSHING
999
SPACER WASHER AS REQUIRED 0.5 MM
999
DISC SUPPORT , 015 UP TO TRANSMISSION 005207
999
SPACER WASHER AS REQUIRED 0.7 MM
999
GUARD PLATE , 015 UP TO TRANSMISSION 005207
999
GEAR MAIN SHAFT, 015 UP TO TRANSMISSION 005207
999
SPACER WASHER , Replaced By: A1122720052
999
OUTER DISC , 015 UP TO TRANSMISSION 003528, Replaced By: A1092720826, +003A1122720225
999
SPACER WASHER AS REQUIRED 0.1 MM, 015 UP TO TRANSMISSION 005207
999
OUTER DISC , 015 UP TO TRANSMISSION 003528, Replaced By: A1092720826, +003A1122720225
999
FLANGE , 015 UP TO TRANSMISSION 005207
999
SPACER WASHER , Replaced By: A1122720352
999
LOCK , 015 UP TO TRANSMISSION 005207
999
SPACER WASHER 0.20 MM
999
LOCK , 015 UP TO TRANSMISSION 005207
999
SPACER WASHER 0.15 MM
999
SPACER WASHER , Replaced By: A1122720652
999
SPACER WASHER AS REQUIRED 0.1 MM
999
GUARD PLATE , 015 UP TO TRANSMISSION 005207
999
GUARD PLATE , 015 UP TO TRANSMISSION 005207
999
GUARD PLATE , 015 UP TO TRANSMISSION 005207
999
GUARD PLATE , 015 FROM TRANSMISSION 005208
999
BRACKET
999
PIN , 004995
999
INSULATING RING , NO LONGER AVAILABLE
999
DIAPHRAGM , 015 UP TO TRANSMISSION 002755, Replaced By: A1122772475, +001A1122700079, +002A1122770977, +001A1129932402
999
INSULATING RING
999
SPACER WASHER , 015 UP TO TRANSMISSION 002755, Replaced By: A1122772475, +001A1122700079, +002A1122770977, +001A1129932402
999
SPACER WASHER , 015 UP TO TRANSMISSION 002755
999
PIN AS REQUIRED 36 MM
999
PIN 37 MM AS REQUIRED
999
BUSHING , 015 UP TO TRANSMISSION 005207
999
GASKET , Replaced By: A1122772080
999
INTERMEDIATE PLATE , 015 UP TO TRANSMISSION 005207
999
SPRING RETAINER , 015 UP TO TRANSMISSION 005207
999
PIN , 015 UP TO TRANSMISSION 002755, Replaced By: A1122772475, +001A1122700079, +002A1122770977, +001A1129932402
999
COVER , 015 UP TO TRANSMISSION 005207
999
GASKET , 015 UP TO TRANSMISSION 005207
999
PIN AS REQUIRED 81 MM, 015 FROM TRANSMISSION 002756
999
PIN AS REQUIRED 82 MM
999
SHIFT VALVE , NO LONGER AVAILABLE
999
PISTON , NO LONGER AVAILABLE 015 UP TO TRANSMISSION 005207
999
BUSHING , 021,023 UP TO TRANSMISSION 002079
999
SHIFT VALVE , 015 UP TO TRANSMISSION 005207
999
SHIFT VALVE , 015 UP TO TRANSMISSION 005207
999
BUSHING
999
SHIFT VALVE , NO LONGER AVAILABLE
999
PISTON , 043 UP TO TRANSMISSION 002079 NO LONGER AVAILABLE
999
ROD , 000029
999
PIN REPAIR SIZE 5.5 MM, NOT INCLUDED IN RANGE OF DELIVERY 112 270 11 16
999
SPRING
999
SPRING , NO LONGER AVAILABLE
999
SPRING , 015 UP TO TRANSMISSION 005207
999
SPRING , TO 112 270 09 07
999
SPRING , NO LONGER AVAILABLE
999
SPRING , 002755
999
SPRING , NO LONGER AVAILABLE
999
SPRING , 015 UP TO TRANSMISSION 005207
999
SPRING
999
SPRING OUTSIDE, NO LONGER AVAILABLE
999
SPRING , TO 112 270 09 07
999
SPRING , NO LONGER AVAILABLE
999
SPRING , 015 UP TO TRANSMISSION 005207
999
SCREW PLUG , 014 UP TO TRANSMISSION 000903
999
PLUG , 014 FROM TRANSMISSION 000904, 015 FROM TRANSMISSION 006447
999
FILTER RANGE OF DELIVERY COMPRISES:, 021,023 FROM TRANSMISSION 006751-009935, FROM TRANSMISSION 023011
999
LINE VACUUM
999
LOCK
999
PIN
999
KNOB , Replaced By: A1112680842
999
BALL SOCKET , 010 UP TO CHASSIS 040631,012 UP TO CHASSIS 087732
999
SCREW , 015 UP TO TRANSMISSION 005207
999
SCREW CLAMP MOUNTING
999
SCREW STEERING COLUMN PANELLING M 5X12
999
COTTER PIN , 014,10/50,12/52 UP TO CHASSIS 049461 NOT INSTALLED ON,SEE FOOTN. 15,014,20/60,22,62 UP TO CHASSIS 049390 NOT INSTALLED ON,SEE FOOTN.16AND 19
999
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
999
WASHER HORN TO ENGINE CROSS MEMBER
999
LOCK WASHER , 002755, Replaced By: A1122772475, +001A1122700079, +002A1122770977, +001A1129932402
999
LOCK WASHER
999
LOCK WASHER
999
SPRING WASHER , Replaced By: N000137004202
999
SPRING WASHER AT GENERATOR TERMINAL D+, 010,10/50 UP TO CHASSIS 066175,010,12/52 UP TO CHASSIS 067208 EXCEPT FOR 067205,010,20/60 UP TO CHASSIS 065672,010,22/62 UP TOCHASSIS 068683 012,10/50 UP TO CHASSIS 151591 EXCEPT FOR,SEE FOOTNOTE 074,012,12/52 UP TO CHASSIS 153776 EXCEPT FOR 153758,153760,153771 012,20/60 UP TO CHASSIS 148879 EXCEPT FOR 148827,148837,148844,148850,148852,012,22/62 UP TO CHASSIS 158113
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
SPRING WASHER
999
WASHER
