Поз.
Артикул
Описание
10
ROOF PANELLING , Replaced By: A1106500570
10
ROOF PANELLING
18
FRAME
24
RUBBER BUFFER TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
31
SEAL
31
SEAL , Replaced By: A1157820098
39
HOSE
46
GROMMET
238
COVER RAIL
246
SLIDING RAIL FRONT LEFT
260
FILLER , FROM CHASSIS:110.010 022627 110.110 031398 111.010 036514 111.012 078363 111.014 031345 112.014,015 001250
293
HEADLINER WITH FRAME, STATE COLOR CODE NO.WHEN ORDERING
300
PANELLING LESS BOWS
307
FRAME , STATE COLOR NUMBER WHEN ORDERING
314
RUBBER SEAL LEATHER & IMITATION LEATHER 837 MM
314
RUBBER SEAL , Replaced By: A0019876052
321
BOW
329
BOW
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
CLAMP CABLE HARNESS MOUNTING 22 MM
999
SCREW PUMP TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
SCREW
999
SCREW
999
SCREW
999
SCREW , 010 UP TO CHASSIS 001747,012 UP TO CHASSIS 003396
999
SCREW ELECTRIC CABLE TO HORN
999
SHEET METAL SCREW
999
SHEET METAL SCREW
999
TOOTHED WASHER MASKED STOP LAMP
999
TOOTHED WASHER , 123.020 082784 123.023 100522 123.026 050534 123.120 116041 123.123 080963 123.126 045537 123.130 101733
999
TOOTHED WASHER COVER TO COVERING,K 093739
999
CLAMPING SLEEVE
999
SCREW
999
SCREW COVER PLATE TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
SCREW RODS TO LINKAGE
999
WASHER BRACKET TO HEAT SHIELD
999
WASHER
999
SCREWTO R & S, 10/20 695199 50/60 696575 8 000001 10/20 910468 50/60 910357 ALSO INSTALLED ON 910659,910662,910667,910748,910750,910812,910813,910817,910818,910833,910880,911127,911436,911440, 911442,911753,911832.
999
SCREW
999
PANELLING LESS BOWS
999
RUBBER BUFFER , Replaced By: A1109870539
999
RUBBER BUFFER
999
PAD , Replaced By: A0009833087
999
PAD , Replaced By: A0009833087
999
PAD FRAME PART,CENTRAL 860 MM
999
PAD , Replaced By: A0009830098
999
PAD , Replaced By: A0009830098
999
PAD , Replaced By: A0009830098
999
PIN , 010 UP TO CHASSIS 086235,110 UP TO CHASSIS 137067
999
LOCKING HANDLE , 010 UP TO CHASSIS 086235,110 UP TO CHASSIS 137067, Replaced By: A1107830284, +001A1235860078
999
LOCKING HANDLE , UP TO CHASSIS: 110.010 086235 110.110 137067 111.010 057874 111.012 126645 111.014 060832 112.014 006068, Replaced By: A1107830284, +001A1235860078
999
SLIDING RAIL LEFT
999
SLIDING RAIL FRONT RIGHT
999
RAIL RIGHT
999
RAIL LEFT
999
SPRING RIGHT, UP TO CHASSIS: 111.010 001747 111.012 003397 111.014 000712
999
SLIDING RAIL , Replaced By: A1107820826
999
RAIL , Replaced By: A1107820124
999
PLATE RIGHT
999
SPRING LEFT, UP TO CHASSIS: 111.010 001747 111.012 003397 111.014 000712
999
SLIDING RAIL , Replaced By: A1107820726
999
RAIL , Replaced By: A1107820524
999
SPRING , Replaced By: A1107820135
999
SLIDING JAW
999
COVER RAIL , Replaced By: A1107820113
999
ROD RIGHT
999
SEAL , Replaced By: A1107820407
999
ANGLE REAR, 010,011 FROM CHASSIS 087490,110 FROM CHASSIS 139289
999
SEAL , Replaced By: A1107821498
999
SEAL , Replaced By: A1107820407
999
FRAME , FROM CHASSIS:111.010 001748-005225111.012 003398-011661111.014 000713-002879, Replaced By: A1107800529, +001A1107821498, +001A1157820098
999
SEAL , Replaced By: A1107870098
999
SLIDING ROOF MECHANISM , Replaced By: A1107800322
999
FRAME , UP TO CHASSIS: 111.010 001747 111.012 003397 111.014 000712, Replaced By: A1107800529, +001A1107820726, +001A1107820826, +001A1107821498, +001A1157820098
999
FRAME ROOF, 010 UP TO CHASSIS 066415,110 UP TO CHASSIS 103373 STATE COLOR CODE NO.WHEN ORDERING
999
SEAL , UP TO CHASSIS: 111.010 005225 111.012 011661 111.014 002879
999
ANGLE , Replaced By: A1107800512
999
INSULATION , Replaced By: A0009831298
999
INSULATION , Replaced By: A1106820251
999
INSULATION BETWEEN REINFORCEMENT AND ROOF PANELLING 40X520X10 MM, ORDER BY THE METER
999
INSULATION , Replaced By: A0009831298
999
ROOF PANELLING , Replaced By: A1106500570, +001A1106700639, +004A1159971040, +004N000084004137, +004N009021004103
999
SCREW , Replaced By: A1409900436
999
PAD , Replaced By: A1107841597
999
HOSEWASSERABLAUF HINTEN 250 MM
999
CLIP , Replaced By: A0019881778
999
CLIP DOOR OUTSIDE
999
HOSE , Replaced By: A0009978482
999
WASHER , 010 UP TO CHASSIS 086235,110 UP TO CHASSIS 137067
999
CLEANER
999
ADHESIVE TAPE 6 MM DIA.50 MM LONG, ORDER BY THE METER
999
CLEANER , Replaced By: A0009899271
999
RUBBER BUFFER REAR
999
RUBBER SEAL , Replaced By: A1107870098
999
RUBBER SEAL , Replaced By: A1107870098
999
RUBBER SECTION , Replaced By: A0009833598
999
RUBBER PAD , Replaced By: A1107841597
999
HOSE 25 MM, ORDER BY THE METER
999
METAL SECTION , Replaced By: A0009850229
999
FELT , Replaced By: A0009830198
999
FOAM PLASTICS FRONT ROOF RAIL
999
CARPET *** 2 MM, ORDER BY THE METER
999
FELT WAFFLE-FACED FELT-,FOR FRONT FLOOR,TOP550 X 560 X 10 MM, ORDER BY THE METER 10/50,12/52,000,001,004,010 UP TO CHASSIS 099714,10/50,12/52,100,101,104,110 UP TO CHASSIS 210863,AND FOOTNOTE 4
999
FOAM PLASTICS 10 MM, ORDER BY THE METER
999
FOAM PLASTICS ROOF INTERIOR COVERING,7X80X100, ORDER BY THE METER
999
FOAM PLASTICS , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0009831298
999
FOAM PLASTICS , Replaced By: A0009833598
