Поз.
Артикул
Описание
10
AXLE HOUSING WITH REAR AXLE TUBES AND DIFFERENTIAL CASE BEARING CAPS,N 037772
15
CYLINDRICAL PIN
20
SCREW RUBBER MOUNTING TO BRACKET M 18X130
25
PIN AXLE TUBE TO AXLE HOUSING
40
OIL COLLECTOR
45
THRUST RING LEFT AND RIGHT
65
FITTING BLEEDING
130
SCREW PLUG BELL HOUSING
135
SCREW COLLAR DIFFERENTIAL LOCK
135
SCREW COLLAR DIFFERENTIAL GEAR ADJUSTMENT M 145X1.5
138
COUPLING (DOG COUPLING)
141
RING CLUTCH TO DIFFERENTIAL GEAR
144
FOLLOWER CLUTCH TO DIFFERENTIAL GEAR,655065
147
BUSHING
150
CYLINDER ,655065
153
SEAL RING
156
CYLINDRICAL PIN
159
PISTON ,655065
162
SPRING
171
SCREW COLLAR ,655065
174
FITTING COMPRESSED AIR CONNECTION
177
SEAL RING FITTING
180
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
183
SCREW SHIFTING CYLINDER
186
CYLINDRICAL PIN
189
SWITCH DIFFERENTIAL LOCK INDICATOR SWITCH
192
LOCK SCREW COLLAR,3 261697
195
SCREW
198
SET SCREW AXLE HOUSING
201
SLIDE , NOT USED
204
NUT RING GEAR CHECK
207
SCREW
207
SCREW , Replaced By: A3643510071
213
NUT BATTERY CABLE
213
NUT BRACKET TO SUPPORT AND TO END PIECE
216
GASKET REAR AXLE HOUSING COVER
219
COVER REAR AXLE HOUSING, FROM AXLE 3 310141
222
SCREW COVER TO REAR AXLE HOUSING M 12X22,3 310141
225
SCREW PLUG BELL HOUSING
279
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, REAR,AS REQUIRED 0.25 MM
279
SPACER WASHER
282
TAPERED ROLLER BEARING DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, REAR
282
TAPERED ROLLER BEARING ON PINION END
282
TAPERED ROLLER BEARING DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, REAR
285
TAPERED ROLLER BEARING
285
TAPERED ROLLER BEARING DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT
288
SPACER RING DRIVE PINION
291
SPACER WASHER AS REQUIRED, STEEL 6.88 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.92 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.12 MM
291
SPACER WASHER AS REQUIRED, STEEL 6.96 MM
291
SPACER WASHER AS REQUIRED, STEEL 6.76 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.16 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.32 MM
291
SPACER WASHER AS REQUIRED, STEEL 6.60 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.96 MM
291
SPACER WASHER AS REQUIRED, STEEL 6.72 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.24 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.24 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.28 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.32 MM
291
SPACER WASHER AS REQUIRED, STEEL 6.84 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.04 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.80 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.84 MM
291
SPACER WASHER AS REQUIRED, STEEL 6.64 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.12 MM
291
SPACER WASHER AS REQUIRED, BRASS 6.68 MM
291
SPACER WASHER AS REQUIRED, BRASS 6.64 MM
291
SPACER WASHER AS REQUIRED, STEEL 6.68 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.20 MM
291
SPACER WASHER AS REQUIRED, STEEL 6.92 MM
291
SPACER WASHER AS REQUIRED, BRASS 7.16 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.72 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.60 MM
291
SPACER WASHER AS REQUIRED, BRASS 7.20 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.88 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.08 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.00 MM
291
SPACER WASHER AS REQUIRED, BRASS 7.40 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.28 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.08 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 6.76 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.00 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.36 MM
291
SPACER WASHER DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED 7.36 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.04 MM
291
SPACER WASHER AS REQUIRED, STEEL 7.40 MM
291
SPACER WASHER
294
THRUST WASHER
297
SCREW COLLAR DIFFERENTIAL GEAR ADJUSTMENT
300
SEAL RING DRIVE SHAFT,REAR
302
SEAL RING
305
LOCK AXLE HOUSING
308
LOCK SCREW COLLAR LOCKING
315
SCREW
320
FLANGE FLANGE TO DRIVE PINION GEAR, DIAMETER:150 MM
330
NUT COUPLING FLANGE TO DRIVE SHAFT,5 298189
335
UNIT IDENTIFICATION PLATE
335
UNIT IDENTIFICATION PLATE
340
RIVET TYPE PLATE TO AXLE HOUSING
999
PLATE FRONT SPRINGS TO FRONT AXLE
999
BEARING BRACKET (AXLE CASING),STEEL VERSION
