Поз.
Артикул
Описание
4
T-FITTING 3/2-WAY VALVE
7
ELBOW FITTING
10
FITTING ,A 002297
13
FITTING , Replaced By: A0039979072
16
BRACKET PRESSURE REGULATOR
19
BUFFER BRACKET TO PRESSURE REGULATOR
19
RUBBER BUFFER , Replaced By: A0009887511
21
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
21
SCREW , Replaced By: N304017008039
23
WASHER , Replaced By: N009021008213
23
WASHER BRACKET TO LEFT SIDE MEMBER
24
VALVE PRESSURE REGULATOR "1",077966
24
VALVE PRESSURE REGULATOR "1"
26
VALVE PRESSURE REGULATOR "2"
26
VALVE PRESSURE REGULATOR "2",077966
28
VALVE PRESSURE REGULATOR, IDLE SPEED
30
SCREW COVER PLATE TO COVER PLATE M 6 X 12
30
SCREW , Replaced By: N304017006018
33
NUT , Replaced By: N913004006001
33
NUT PUMP TO BRACKET
35
SEAL RING AT PRESSURE REGULATOR "1+2"
36
SEALING RING. SEAL RING ENGINE BREATHING
38
FITTING THREE-WAY FAUCET ON PRESSURE REDUCING VALVE
40
T-FITTING THREE-WAY FAUCET ON PRESSURE REDUCING VALVE
42
LINE ,077966
44
NUT10 MM
46
SEAL CONE REAR 10 MM
46
SEAL CONE FRONT 10 MM
48
HOSE FROM PRESSURE REGULATOR TO STOP VALVE, ORDER BY THE METER
48
HOSE , Replaced By: A0004767826
51
HOSE AIR LINE PRESSURE REGULATOR ON GAS MIXER, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
51
HOSE , Replaced By: A0004767626
51
HOSE PRESSURE REGULATOR ON INTAKE CASE, ORDER BY THE METER
55
HOSE FROM PRESSURE REGULATOR TO STOP VALVE, ORDER BY THE METER
55
HOSE , Replaced By: A0004767726
55
HOSE , Replaced By: A0004767726
55
HOSE , Replaced By: A0004767726
68
HOLLOW SCREW HEATING CONNECTION
72
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
76
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
78
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
78
CLAMP , Replaced By: N000000000665
78
CLAMP , Replaced By: N916017011001
81
CLAMP HOSE TO FITTING AND TO OIL TANK
81
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
84
CLAMP25-40X13 MM
84
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
92
VALVE , Replaced By: A0049975736
92
VALVE (3/2-WAY SOLENOID VALVE) EKS
96
SEAL RINGWABCO
100
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
100
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
104
NUT , Replaced By: N913004008001
108
ELBOW FITTING REAR AXLE TWO-WAY VALVE,CONNECTION: "2"
112
NUT ,D 091466
116
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
120
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
HOSE
999
CLAMP FUEL LINE, 741959
999
CONNECTOR FROM FUEL TANK TO CONNECTOR I
999
INTERMEDIATE PIECE CONNECTION OF FUEL LINES
999
CLAMP
999
PAWL
999
PULLEY180 MM,000475
999
PULLEY ONE-GROOVE,ELBOWED 188 MM
999
V-BELT
999
FITTING FUEL FILTER
999
HOSE RETURN
999
HOSETO 346 500 60 03, ORDER BY THE METER
999
FUEL FILTER
999
INSULATING HOSE12 MM
999
FUEL FILTER FUEL FEED PUMP
999
LINE FEED & RETURN 10X1 MM, LENGTH AVAILABLE: 3000 MM
999
MAINTENANCE INDICATOR ,086793
999
COVER
999
PUMP (MANUAL AUXILIARY PUMP)
