Поз.
Артикул
Описание
5
PLASTIC PIPE RISING PIPE 4X6 MM
5
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
11
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
11
PLASTIC PIPE AERATION, ORDER BY THE METER
22
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
26
FITTING , Replaced By: A0029905971
26
FITTING (PARTS KIT),LINE RUPTURE
33
UNION NUT
38
UNION NUT LINE CONNECTION, Replaced By: N000000006239
38
UNION NUT LINE CONNECTION
38
UNION NUT LINE CONNECTION
44
GLAND , Replaced By: A0019901667
48
SEAL CONE LINE CONNECTION
48
GLAND LINE CONNECTION
48
GLAND , Replaced By: A0019901967
55
SLEEVE LEAK LINE
58
SLEEVE LINE CONNECTION
60
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
65
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION M 14 / 6 MM
70
ELBOW FITTING HOSE WIDTH, 9 MM,TO M22
72
CONNECTOR HOSE WIDTH, 6 MM, TO M22
75
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
80
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
85
SCREW. UNION SCREW LINE CONNECTION
90
GROMMET
95
PLATE LINE MOUNTING
100
LOOM TIE LINE MOUNTING
118
FITTING LINE CONNECTION
176
FITTING RELAY VALVE,CONNECTION: "10",950459
176
CONNECTOR , Replaced By: A0039970672, +001A0019901967, +001N915017012100
190
T-FITTING BRAKE POWER REGULATOR,CONNECTION: "10", Replaced By: A0049971689, +001A0009974834
