Поз.
Артикул
Описание
5
PLANETARY GEAR DRIVE RATIO: 1:3.429,V 207324V 496300
5
PLANETARY GEAR DRIVE RATIO: 1:4.000,V 207287
5
PLANETARY GEAR DRIVE RATIO: 1:3.429
5
PLANETARY GEARING RATIO: 1:4,000
5
PLANETARY GEARING RATIO: 1:3,429
5
PLANETARY GEARING , FIRST EXHAUST STOCK OF OLD PARTS UP TO REAR AXLE V 477618, Replaced By: A3463504209
5
PLANETARY GEARING RATIO: 1:4.000,V 207287, Replaced By: A9423501609
5
PLANETARY GEARING RATIO: 1:3.429,V 207324, Replaced By: A9423501809
5
PLANETARY GEARING RATIO: 1:3.429, Replaced By: A9423501509
5
PLANETARY GEARING
6
BELL HUB
6
BELL HUB
6
BELL HUB WITH PLANETARY CARRIER,393260
6
BELL HUB WITH PLANETARY CARRIER, LKW W 972500, BUS W974541, V 000001, Replaced By: A0003500633
6
BELL HUB WITH PLANETARY CARRIER, EXHAUST STOCK OF OLD PART NUMBER FIRST, Replaced By: A0003500433
6
BELL HUB WITH PLANETARY CARRIER
6
BELL HUB WITH PLANETARY CARRIER, LKW W 972500, BUS W974541, V 000001
6
BELL HUB WITH PLANETARY CARRIER
8
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
8
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
8
SCREW MAIN TRANSMISSION PLANETARY GEAR SET ON PLANETARY GEAR TRAIN
11
THRUST WASHER PLANET GEAR
14
THRUST WASHER PLANET GEAR
17
NEEDLE PLANET GEAR
20
PIN PLANET GEAR
26
SPACER WASHER , Replaced By: A3553540162
26
THRUST WASHER PLANET GEAR
32
PLANET GEAR PARTS KIT
32
PLANET GEAR PARTS KIT,393260
35
SEAL RING PLANETARY GEAR TRAIN TO REAR WHEEL HUB
35
SEAL RING , Replaced By: A0169974048
35
SEAL RING PLANETARY GEAR TRAIN TO REAR WHEEL HUB
38
WHEEL HUB CAST VERSION
38
WHEEL HUB STEEL VERSION
50
TAPERED ROLLER BEARING OUTSIDE
50
TAPERED ROLLER BEARING OUTSIDE
50
TAPERED ROLLER BEARING OUTSIDE
77
OIL COLLECTOR WHEEL HUB, OUTSIDE TO 346 356 28 01/29 01
77
OIL COLLECTOR AT REAR WHEEL HUB
77
OIL COLLECTOR
83
THRUST RING (MEASURING RING) ANTI-LOCK BRAKING SYSTEM, BEFORE ORDERING CHECK WHETHER ABS MEASURING RING IS INSTALLED
86
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
86
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
86
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
86
TAPERED ROLLER BEARING WHEEL HUB, INSIDE
89
COVER PLATE WHEEL HUB, INSIDE
89
COVER PLATE AT REAR WHEEL HUB
89
COVER PLATE WHEEL BEARING
92
RADIAL SHAFT SEALING RING WHEEL HUB, OUTSIDE, ORDER ADDITIONALLY: A 013 997 89 46
92
SEAL RING FRONT WHEEL HUB,OUTSIDE, ORDER ADDITIONALLY: A 013 997 94 47
92
SEAL RING WHEEL HUB, INSIDE, ORDER ADDITIONALLY: A 015 997 49 47
92
SEAL RING WHEEL HUB, INSIDE, ORDER ADDITIONALLY: A 015 997 90 45
92
SEAL RING WHEEL HUB, INSIDE, ORDER ADDITIONALLY: A 014 997 05 46M 053280 , N 288000
95
THRUST RING , Replaced By: A3463561415
95
THRUST RING WHEEL BEARING
98
OUTSIDE GEAR PLANETARY GEAR TRAIN,NUMBER OF TEETH: 75,V 207287
98
OUTSIDE GEAR NUMBER OF TEETH: 85
98
OUTSIDE GEAR NUMBER OF TEETH: 85
101
SUPPORT OUTSIDE GEAR
101
SUPPORT OUTSIDE GEAR
104
WIRE RING OUTSIDE GEAR TO SUPPORT
107
REAR AXLE SHAFT WITH INTERLOCK SERRATIONS
107
REAR AXLE SHAFT LESS INTERLOCK SERRATIONS
107
REAR AXLE SHAFT , Replaced By: A6583571501, +001N009045050001
107
REAR AXLE SHAFT , Replaced By: A6583571401, +001N009045050001
110
LOCK PLATE WHEEL HUB TO AXLE JOURNAL
113
GROOVED NUT HUB AND SUPPORT TO AXLE CASING
113
GROOVED NUT WHEEL HUB TO REAR AXLE TUBE
113
GROOVED NUT , Replaced By: A9423560026
113
GROOVED NUT , Replaced By: A9423560126
116
LOCK RING INTERMEDIATE SHAFT BEARING
116
SNAP RING
116
LOCK RING45X1.75 MM
119
SUN GEAR PLANETARY GEAR TRAIN,NUMBER OF TEETH: 25,V 207287
119
SUN GEAR NUMBER OF TEETH: 35
122
THRUST WASHER PLANET GEAR
125
SPACER WASHER PLANETRAY TRANSMISSION, IF REQUIRED 1.50 MM
125
SPACER WASHER PLANETRAY TRANSMISSION, IF REQUIRED 0.80 MM
125
SPACER WASHER PLANETRAY TRANSMISSION, IF REQUIRED 1.00 MM
125
SPACER WASHER PLANETRAY TRANSMISSION, IF REQUIRED 0.10 MM
125
SPACER WASHER PLANETRAY TRANSMISSION, IF REQUIRED 0.20 MM
125
SPACER WASHER AS REQUIRED 0.50 MM, MAN AXLE
128
LOCK RING THRUST WASHER TO BELL HUB
131
WHEEL MOUNTING BOLT LIGHT-ALLOY-SHEET DISC WHEEL, Replaced By: A0004013771
131
WHEEL MOUNTING BOLT DISC WHEEL ON WHEEL HUB
140
CAPSCREW W HEXAL. DRIVE BRACKET TO PUMP M12X25
143
HUB CAP BELL HUB
146
GASKET COVER TO HUB
149
SCREW COVER TO BELL HUB
152
SCREW PLUG OIL DRAIN
155
SEALING RING. SEAL RING OIL DRAIN
158
SCREW PLUG OIL FILLING
161
SEALING RING OIL FILLING
164
REPAIR KIT WHEEL HUB, ONLY APPLICABLE TO MODELS: 748.270
164
REPAIR KIT WHEEL HUB, ONLY APPLICABLE TO MODELS: 748.271
164
DS WHEEL HUB WHEEL HUB
164
DS WHEEL HUB WHEEL HUB
