Поз.
Артикул
Описание
5
BRAKE ANCHOR (BRAKE ANCHOR)
5
BRAKE ANCHOR , Replaced By: A3464230906
5
BRAKE CARRIER (BRAKE ANCHOR)
8
SCREW BRAKE ANCHOR PLATE AND SUPPORTING SLEEVE TO JOINT HOUSING M 16X50
8
SCREW CROSS MEMBER TO SIDE MEMBERS M 16X1.5X65
8
SCREW FRONT WHEEL BRAKE TO STEERING KNUCKLE
8
SCREW CENTRAL BEARING CROSS MEMBER TO SIDE MEMBERS
11
NUT BEARING BRACKET TO BRAKE ANCHOR
11
NUT , Replaced By: A0009905750
14
PROTECTIVE PLATE LEFT REAR AND RIGHT FRONT
14
PROTECTIVE PLATE WITH BEAD,A B S AND BRAKE LINING WEAR INDICATOR
17
PROTECTIVE PLATE LEFT FRONT AND RIGHT REAR
17
PROTECTIVE PLATE ABS AND BRAKE LINING WEAR INDICATOR
20
HEXAGON HEAD BOLT BRACKET TO TRANSMISSION
23
PLUG
23
PLUG PROTECTIVE PLATE
26
PLUG
26
PLUG
29
SENDER UNIT BRAKE LINING WEAR INDICATOR, STANDARD VERSION: 18.9 MM
29
SENDER UNIT BRAKE LINING WEAR INDICATOR, REPAIR SIZE: 16.9MM
32
LOCK PLATE. CIRCLIP SENSOR CABLE TO PROTECTIVE PLATE
35
BRAKE SHOE , FIRST EXHAUST STOCK OF OLD PARTS UP TO REAR AXLE N 029070, Replaced By: A6204200319
35
BRAKE SHOE , Replaced By: A6204200519
35
BRAKE SHOE
35
BRAKE SHOE , Replaced By: A6594200519
35
BRAKE SHOE , Replaced By: A6594200419
35
BRAKE SHOE CAST VERSION
35
BRAKE SHOE , Replaced By: A6594200419
38
PIN , Replaced By: A9454210074, +008N000471012001
38
PIN , Replaced By: A6584210074
38
PIN
38
PIN BRAKE SHOE IN CAST VERSION
41
LOCK RINGTO 000 553 37 01,000 553 39 01,
44
BUSHINGTO 301 420 00 39
44
BUSHING BRAKE SHOE ROLLER
44
BUSHING
44
BUSHING
47
SEAL RING BRAKE SHOE ROLLER
50
FITTED WASHER BRAKE SHOE ROLLER
53
LOCK RING ,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3
56
REPAIR KIT BRAKE SHOE ROLLER
59
BRAKE LINING (PARTS KIT) REPAIR SIZE 0,FOR EXPORT, WITH WEAR INIDCATOR 16.70 MM,JURID
59
BRAKE LINING (PARTS KIT) STANDARD,WITH WEAR INDICATOR 18.00 MM,JURID
59
BRAKE LINING (PARTS KIT) REPAIR SIZE I,WITH WEAR INDICATOR 18.80 MM,JURID
59
BRAKE LINING (PARTS KIT) REPAIR SIZE II,WITH WEAR INDICATOR 19.50 MM,JURID
59
BRAKE LINING , Replaced By: A6174230530
59
BRAKE LINING , Replaced By: A6174230630
59
BRAKE LINING , Replaced By: A6174230730
59
BRAKE LINING , Replaced By: A6174230830
62
PANHEAD RIVET BRAKE LINING TO BRAKE SHOE 15 MM
62
PANHEAD RIVET BRAKE LINING TO BRAKE SHOE 18 MM
62
RIVET BRAKE LINING 15 MM
62
RIVET
65
PIN BRAKE SHOE TO BRAKE ANCHOR
68
SPACER WASHER BRAKE SHOE TO BRAKE ANCHOR
71
SEAL RING BRAKE SHOE PIN TO BRAKE ANCHOR
74
LOCK , Replaced By: A9429940009
74
LOCK BRAKE SHOE TO BRAKE ANCHOR
74
LOCK BRAKE SHOE TO BRAKE ANCHOR
77
LOCK BRAKE SHOE TO BRAKE ANCHOR PLATE, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185 UP TO CHASSIS FB588185,FROM CHASSIS FB588186,SEE SPARE PARTS LIST 743.0
77
LOCK PLATE BRAKE SHOE TO BRAKE ANCHOR PLATE, UP TO CHASSIS 588185,FROM CHASSIS FB588186,SEE SPARE PARTS LIS T,BM 732.7
80
HEXAGON HEAD BOLT BRACKET TO TRANSMISSION
80
SCREW SELF-LOCKING M 10X20
83
REPAIR KIT BRAKE SHOE BEARING
83
REAR WHEEL BRAKE BRAKE SHOE BEARING
83
REPAIR KIT , Replaced By: A3074204002
86
SPRING
86
SPRING , Replaced By: A6179931110
86
SPRING BRAKE SHOE IN WELDED VERSION
89
BRAKE DRUM220MM
