Поз.
Артикул
Описание
5
DIFFERENTIAL GEAR LESS FLANGE 29:17
5
DIFFERENTIAL GEAR
8
AXLE HOUSING , Replaced By: A9423500603
8
AXLE HOUSING WITH BEARING CAP
11
CYLINDRICAL PIN , Replaced By: N000007008101
14
SCREW BEARING COVER TO AXLE HOUSING
20
PIN AXLE HOUSING
23
SNAP RING
92
HOUSING PINION HOUSING
119
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.20 MM
119
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 1.00 MM
119
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.10 MM
119
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.35 MM
119
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 1.50 MM
119
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.15 MM
119
SPACER WASHER DIFFERENTIAL GEAR,AS REQUIRED 0.50 MM
122
SEAL RING PINION HOUSING TO AXLE HOUSING
125
SCREW APPARATUS SUPPORT TO FRAME
176
SCREW , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3559901704
176
SCREW , Replaced By: A3559900604
176
SCREW BRACKET TO BRACKET
178
SCREW IN CASE OF STEEL AXLE M 12X85
178
SCREW PINION HOUSING TO AXLE HOUSING M12X1,5X85
178
HEXAGON HEAD BOLT COVER TO DIFFERENTIAL CASE M12X1.5X85
179
COVER
182
SCREW PIPE CLAMP
182
SCREW , Replaced By: N304017008021
185
GASKET SHIFTING CYLINDER TO INTERMEDIATE FLANGE
188
SCREW PLUG
