Поз.
Артикул
Описание
5
DIFFERENTIAL GEAR LESS FLANGE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
AXLE HOUSING
11
CYLINDRICAL PIN
11
CYLINDRICAL PIN , Replaced By: N000007008101
14
SCREW BEARING COVER TO AXLE HOUSING
17
PIN AXLE HOUSING
20
SNAP RING
23
SPACER WASHER PINION HOUSING,AS REQUIRED 0.20 MM
23
SPACER WASHER PINION HOUSING,AS REQUIRED 0.15 MM
23
SPACER WASHER DIFFERENTIAL HOUSING,AS REQUIRED 0.50 MM
23
SPACER WASHER PINION HOUSING,AS REQUIRED 1.00 MM, NOT USED
23
SPACER WASHER PINION HOUSING,AS REQUIRED 0.10 MM, NOT USED
23
SPACER WASHER PINION HOUSING,AS REQUIRED 0.35 MM, NOT USED
23
SPACER WASHER PINION HOUSING,AS REQUIRED 1.50 MM
26
HOUSING. OIL COLLECTOR (PINION HOUSING)
29
SCREW APPARATUS SUPPORT TO FRAME
32
SEAL RING PINION HOUSING TO AXLE HOUSING
41
SCREW PLUG
137
SCREW , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3559901704
137
SCREW REAR AXLE HOUSING TO AXLE CASING M12 X 35
137
SCREW BRACKET TO BRACKET
140
SCREW , Replaced By: A0069908101
143
COVER
146
GASKET SHIFTING CYLINDER TO INTERMEDIATE FLANGE
149
SCREW PIPE CLAMP
