Поз.
Артикул
Описание
17
SHIFTING FORK TOP
17
SHIFTING FORK , Replaced By: A3832840401
20
SPACER TUBE REAR
23
SPACER TUBE , Replaced By: A3853230253
23
SPACER TUBE
26
SPACER TUBE FRONT
29
SCREW SHIFTING FORK TO SHIFTING ROD
35
PIVOT PIN SHIFT LEVER TO CASE
38
BUSHING
41
WASHER
44
NUT SHOCK ABSORBER TO CONSOLE AND TO CAB,A 053090
47
COTTER PIN LEVER TO SUPPORT
56
SHIFTING FORK BOTTOM
62
SHIFTING ROD
65
INTERLOCK PIN
68
SPRING
71
SHIFTING SHAFT
74
BOOT SHIFTING ROD
77
SNAP RING BOOT TO FLANGE
77
SNAP RING BOOT TO SHIFTING ROD
80
FLANGE
83
GASKET
86
SPACER RING
89
SEAL RING SHIFTING ROD
92
SCREW COVER PLATE TO BRACKET
95
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
116
SCREW PLUG
119
SEAL RING FROM FUEL TANK TO FUEL TANK
