Поз.
Артикул
Описание
5
STEERING BOX ASSEMBLY LESS PITMAN ARM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
STEERING BOX ASSEMBLY LESS PITMAN ARM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
STEERING BOX WITH SLEEVE VALVE
8
STEERING BOX WITH SLEEVE VALVE
8
STEERING BOX WITH SLEEVE VALVE
11
SEAL RING
14
COVER VALVE HOUSING SEALING,007182
14
COVER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3164660105
17
LOCK
20
SEAL RING FLANGE
23
SEAL RING STEERING SHAFT BEARING
26
NEEDLE BEARING STEERING WORM SECTOR SHAFT
26
NEEDLE BEARING STEERING SHAFT BEARING
29
SEAL RING STEERING WORM SECTOR SHAFT SEALING
29
SEAL RING , Replaced By: A0169973947
29
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0049976047
32
LOCK STEERING SHAFT BEARING
35
SCREW PLUG , Replaced By: N000910012000
35
SCREW PLUGM 12X1.5
38
SEAL RING LINE CONNECTION
38
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
41
SCREW PLUG AIR DEHYDRATOR
41
SCREW PLUG 4/2-WAY VALVE
44
SEAL RING , Replaced By: N007603010110
44
SEAL RING PNEUMATIC VALVE
47
NEEDLE BEARING P.T.O.
50
SEAL RING
50
SEAL RING STEERING BOX 34 X 3
50
SEAL RING , Replaced By: A0139973648
53
BUSHING STEERING WORM BEARING,007181
53
BUSHING STEERING WORM BEARING,007182
56
LOCK RING SHACKLE TO CONSOLE TO 393 326 00 63,965965
56
LOCK BUSHING IN STEERING BOX,007182
59
STEERG. WORM SECTOR SHAFT ,008363, Replaced By: A3164600411, +001A3164661983
59
STEERG. WORM SECTOR SHAFT WITH SET SCREW,008364
62
SCREW , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1234620071
65
THRUST WASHER SHOCK ABSORBER TO TOP BRACKET
68
LOCK RINGTO 000 553 37 01,000 553 39 01,
71
THRUST WASHER2.85M
71
THRUST WASHER3.00 MM
71
THRUST WASHER3.05 MM
71
THRUST WASHER2.70 MM
71
THRUST WASHER3.10 MM
71
THRUST WASHER2.95 MM
71
THRUST WASHER2.75 MM
71
THRUST WASHER2.65 MM
71
THRUST WASHER2.80 MM, Replaced By: A1074620262
71
THRUST WASHER2.80 MM, TO BE ADAPTED DURING ASSEMBLY
74
LOCK , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0049949241
77
SEAL RING
80
NEEDLE BEARING STEERING SHAFT BEARING IN COVER
80
NEEDLE BEARING STEERING SHAFT BEARING IN COVER
80
NEEDLE BEARING , Replaced By: A0149812010
83
SEAL RING STEERING WORM SECTOR SHAFT SEALING
86
SEAL RING STEERING WORM SECTOR SHAFT SEALING
89
SEAL RING VALVE
92
STEERING BOX COVER LATERAL
95
SCREW COVER TO STEERING BOX
98
NUT
98
NUT , Replaced By: A0009904050
101
VALVE LIMITATION
104
SEAL RING FRONT
107
SEAL RING REAR
110
LOCK VALVE
113
SCREW , Replaced By: N304017006018
113
SCREW COVER PLATE TO COVER PLATE M 6 X 12
116
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
185
SEAL RING PITMAN ARM
194
GASKET KIT POWER STEERING
