Поз.
Артикул
Описание
45
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
182
FITTING , Replaced By: A0009970171
182
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
185
ELBOW FITTING TWO-WAY VALVE,CONNECTION "1.2"
185
ELBOW FITTING , Replaced By: A0019904371
188
NUT CHECK VALVE TO AIR RESERVOIR
191
THRUST RING CHECK VALVE TO AIR RESERVOIR
191
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
194
O-RING CHECK VALVE TO AIR RESERVOIR
197
SHUT-OFF COCK
197
SHUT-OFF COCK
200
REPAIR KITTO 000 429 14 31,5 116581
203
FITTING SHUTTLE VALVE,CONNECTION: "20"
203
FITTING , Replaced By: A0019972372
203
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
206
O-RING CHECK VALVE TO AIR RESERVOIR
206
SEAL RING LINE CONNECTION
209
THRUST RING CHECK VALVE TO AIR RESERVOIR
209
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
212
NUT CHECK VALVE TO AIR RESERVOIR
215
FITTING LINE MOUNTING
218
GROMMET FITTING, 807793
221
BRAKE LINE COUPLING
224
SEAL RING"WABCO"
227
O-RING CHECK VALVE TO AIR RESERVOIR
230
THRUST RING CHECK VALVE TO AIR RESERVOIR
230
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
233
NUT CHECK VALVE TO AIR RESERVOIR
236
BRACKET , 674068-875476
239
BRACKET AT BRAKE LINE COUPLING
242
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
242
SCREW BRACKET TO FRAME SIDE MEMBER M 8X75
242
SCREW BRACKET TO FRAME SIDE MEMBER M 8X75
242
SCREW BRACKET TO BEARING BRACKET
242
SCREW , Replaced By: N304017008045
242
SCREW FRONT AXLE REGULATING SOLENOID VALVE M 8X75
242
SCREW , Replaced By: N304014008001
242
SCREW VALVE TO BRACKET
242
SCREW VALVE TO BRACKET, Replaced By: N304014008002
245
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
248
NUT
251
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
251
SCREW BRACKET TO SIDE MEMBER
251
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
251
SCREW , Replaced By: N308676012012
251
SCREW CONSOLE TO SIDE MEMBER
254
LOCK WASHER FITTING TO BRACKET
257
NUT STRAP TO SUPPORT
260
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
263
NUT BRACKET TO SUPPORT AND TO END PIECE
266
WASHER
269
SCREW BRACKET TO BEARING BRACKET
269
SCREW , Replaced By: N304017008045
269
SCREW CLAMP TO BRACKET AND TO PIPE
269
SCREW BRACKET TO FRAME SIDE MEMBER M 8X75
269
SCREW FRONT AXLE REGULATING SOLENOID VALVE
272
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
275
NUT
278
SCREW BRACKET TO SIDE MEMBER
280
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
283
NUT BRACKET TO SUPPORT AND TO END PIECE
286
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
289
BRACKET , Replaced By: A3184280240
289
BRACKET LINE MOUNTING
292
CLAMP DELIVERY AND SUCTION LINES TO STEERING
292
CLAMP , Replaced By: A6739950001
292
CLAMP LINE MOUNTING
292
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
292
CLAMP ,K 147121, Replaced By: N000000000319
292
CLAMP , Replaced By: N916016008200
292
CLAMP , Replaced By: A3604300143
295
SCREW BRACKET TO CROSS CONNECTION STRUT
295
SCREW , Replaced By: N304017008034
295
SCREW PIPE CLAMP
295
SCREW , Replaced By: N304017008021
298
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
301
NUT
304
SCREW SHIFT CASE TO SLOTTED GATE
307
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
310
NUT BALL PIVOT TO LEVER
999
SHUT-OFF COCK , Replaced By: A0004291431
999
ADAPTER FITTING , Replaced By: N074313008101
999
COVER SUPPLY, RED "WABCO"
999
COVER BRAKE,YELLOW "WABCO"
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SEAL RINGTO 000 429 16 31,4 940458
999
BRAKE LINE COUPLING SUPPLY, RED "BOSCH"
999
BRAKE LINE COUPLING BRAKE,YELLOW "BOSCH"
999
BRAKE LINE COUPLING SUPPLY, RED "KNORR"
999
BRAKE LINE COUPLING BRAKE,YELLOW "KNORR"
999
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
999
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
999
BRAKE LINE COUPLING SUPPLY, RED "GRAU"
999
BRAKE LINE COUPLING BRAKE,YELLOW "GRAU"
999
PROTECTIVE CAP , Replaced By: A0014310487
999
HANDLETO 000 429 16 31,4 940458
999
LOOM TIE LINE MOUNTING
999
FITTING SHUTTLE VALVE,CONNECTION: "20",5 727399
999
REPAIR KIT BRAKE LINE COUPLING "WABCO"
999
REPAIR KIT BRAKE LINE COUPLING "KNORR"
999
FITTING (PARTS KIT),LINE RUPTURE
999
FITTING , Replaced By: A0029905971
999
SEAL RING , Replaced By: A0059976545
999
SEAL RING"GRAU"
999
SEAL RING25X2 MM,BOSCH
999
SEAL RING30X2 MM,BOSCH
999
SEAL RING22X2X4 MM, BOSCH
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
SEAL RINGTO 000 429 16 31,4 940458
999
SEAL RING33X2.5 MM,BOSCH
999
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
999
BRACKET
999
BRACKET , Replaced By: A3464296040
999
BRACKET OIL LINE MOUNTING
999
BRACKET
999
BRACKET (REAR CROSS MEMBER)
999
BRACKET RIGHT,4 369236
999
BRACKET , Replaced By: A3184923441
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
SCREW , Replaced By: N304017006016
999
SCREW SUPPORT TO CROSS MEMBER M 10X28
999
SCREW , Replaced By: N308676012026
999
GLAND LINE CONNECTION
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
T-FITTING , Replaced By: A0009902370
999
T-FITTING COMPRESSED AIR VALVE CONNECTION
999
PLATE BRAKE
999
PLATE SUPPLY
999
SCREW PUMP TO BRACKET
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
999
NUT SUPPORT TO SIDE MEMBER
999
NUT PUMP TO BRACKET
999
NUT , Replaced By: N913004006001
999
UNION NUT LINE CONNECTION
999
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
999
SLEEVE LINE CONNECTION
