Поз.
Артикул
Описание
5
CRANKCASE , REMAN PART - WHEN YOU ORDER THIS PART PLEASE ADD THE PREFIX"R" IN FRONT OF THE PART NO.
11
SLEEVE FLYWHEEL HOUSING TO CYLINDER CRANKCASE
14
BALL TO PLUG OIL CONNECTION TO AIR COMPRESSOR
15
CRANKSHAFT BEARING CAP
17
DOWEL PIN CRANKSHAFT BEARING CAP
20
SCREW CRANKSHAFT BEARING CAP TO CYLINDER CRANKCASE,*0185257
23
CAMSHAFT BEARING PARTS KIT TO 906 010 80 05,926 010 02 05/04 05,503097
26
BUSHING CAMSHAFT BEARINGS, Replaced By: A9060511050
26
BUSHING CAMSHAFT BEARINGS,*0185257
29
BUSHING CAMSHAFT BEARINGS, Replaced By: A9060510950
29
BUSHING CAMSHAFT BEARINGS
32
EXPANSION PLUG
32
EXPANSION PLUG WATER PASSAGE 36.2 MM
35
EXPANSION PLUG WATER PASSAGE
35
EXPANSION PLUG PLUG FOR OIL CHAMBER,UNIT PUMP SIDE
37
EXPANSION PLUG FASTENER COOLING WATER PRE-HEATER O 60 MM
38
FITTING. INTERMEDIATE PIECE TURBOCHARGER OIL RETURN
39
THROTTLE FUEL BORE COVER,UNIT PUMP SIDE
41
BALL SHIFTING ROD
41
BALL FRONT AND REAR 14.288 MM
41
BALL HOUSING,TOP
41
BALL TO PLUG OIL CONNECTION TO AIR COMPRESSOR
41
BALL TO PLUG AIR COMPRESSORE OIL BORE,FRONT SIDE
44
INTERMEDIATE PIECE LOCK, OIL SUPPLY UNIT PUMP
47
SLEEVE OIL PUMP TO CRANKCASE
50
FITTED SLEEVE PULSE SENDER UNIT AT CYLINDER CRANCASE
53
OIL NOZZLE PISTON COOLING
57
SEAL RING INTERMEDIATE FLANGE
59
SCREW PLUG , Replaced By: N007604018101
62
SEALING RING OIL LINE TO CYLINDER CRANKCASE
65
SCREW PLUG, FILLING CHARGE AIR PRESSURE M20X1.5
68
SEALING RINGTO A957 490 05 14
71
SCREW PLUG
74
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
80
SCREW PLUG CYLINDER CRANKCASE WATER DRAIN
86
SLEEVE CYLINDER HEAD TO CYLINDER CRANKCASE
92
SCREW PLUG OIL FILLING
98
SCREW PLUG FUEL TANK
104
SEALING RING
128
VALVE (OVERFLOW VALVE) 4.5 BAR,*0002603, Replaced By: A9060921210
128
OVERFLOW VALVE4.5 BAR,*0002603
131
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
141
SENDER UNIT TEMPERATURE GAUGE SENDER UNIT
141
SENDER UNIT TEMPERATURE SENDER UNIT
142
PRESSURE SWITCH OIL PRESSURE
143
SEALING RING
146
SEALING RING OIL PRESSURE GAUGE SENDER UNIT
161
VALVE (SOLENOID VALVE)
167
VALVE
170
SEAL RING
173
GASKET
173
GASKET EXPANSION PLUG TO CYLINDER CRANKCASE
176
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
