Поз.
Артикул
Описание
5
SENDER UNIT OUTBOARD TEMPERATURE FEELER,126372
8
CABLE TIE. LOOM TIE150 X 3.6 MM
10
ELECTRIC CABLE (CABLE COIL) ABS/APB 7POL
10
CABLE HARNESS FROM REAR JUNCTION BOX TO TRAILER PLUG SOCKET
10
11
SWITCH STOP LIGHT SWITCH
14
TERMINAL STOP LIGHT SWITCH
17
PRESSURE SWITCH RELAY VALVE,CONNECTION: "21", 5.5 BAR
17
OIL-BREAK SWITCH VALVE UNIT, REAR OF REAR AXLE 6.5 BAR, Replaced By: A0065451114
17
PRESSURE SWITCH VALVE UNIT, REAR OF REAR AXLE 6.5 BAR
18
19
CAP 90 DEGREE BRACKET
20
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
22
CLAMPING RING
23
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
23
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
24
GASKET WITHE 8 MM
25
GASKET , P 718187 R 000001
26
SUPPORTING BODY 15-POLE TRAILER PLUG SOCKET
26
SUPPORTING BODY TRAILER PLUG SOCKET,7-POLE
27
28
30
CONTACT SUPPORT 5-POLE
35
SCREW , Replaced By: N910143008002
41
NUT HORN TO BRACKET M8
48
50
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M12 X 1.5 X 40
53
NUT BRACKET TO SIDE MEMBER M12X1.5
59
SCREW , Replaced By: N914146006102
65
PLUG SOCKET FOR OPERATION WITH TRAILER
65
PLUG SOCKET FOR OPERATION WITH TRAILER
68
SCREW PLUG SOCKET TO FRAME
68
SCREW CABLE HARNESS MOUNTING
71
WASHER , Replaced By: N000125008443
71
WASHER EXHAUST MUFFLER TO STRAP
86
NUT BRACKET TO SIDE MEMBER
86
NUT STRAP TO BRACKET
92
CLIP ELECTRIC CABLE MOUNTING
