Поз.
Артикул
Описание
10
15
BEARING BRACKET TRIANGULAR CONTROL ARM TO FRAME,RIGHT, NO.7390 IIIII I
15
BEARING BRACKET TRIANGULAR CONTROL ARM TO FRAME,LEFT, NO.7390 IIIII I
30
80
83
83
100
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X50
100
HEXAGON HEAD BOLT SUPPORT TO SIDE MEMBER M18X1.5X130
100
HEXAGON HEAD BOLT TOWING EYE TO FRAME M18X1.5X80
100
SCREW BRACKET TO FRAME M 18X110
100
HEXAGON HEAD BOLT ANGLE TO SPRING BRACKET
100
HEXAGON HEAD BOLT STEERING BRACKET TO FRAME M18X1.5X50
100
SCREW. HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X40
103
SCREW GUSSET PLATE TO SIDE MEMBER
120
NUT TRAILER COUPLING TO FRONT CROSS MEMBER M18X1.5
120
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
123
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
130
140
RIVET SUPPORT TO SIDE MEMBER 14X45 MM
