Поз.
Артикул
Описание
70
PITMAN ARM
70
PITMAN ARM , Replaced By: A3014630901
70
PITMAN ARM
70
PITMAN ARM , Replaced By: A3014630801
72
NUT PITMAN ARM TO STEERING BOX ASSEMBLY
80
STEERING SUPPORT
82
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X40
82
SCREW , Replaced By: N308676016013
84
LOCK WASHERROCKINGER TYP 59 G140,59 G150
86
SCREW ROD TO TRANSFER CASE M 14X65
86
SCREW , Replaced By: N308676014013
88
NUT STEERING SUPPORT TO FRAME
88
NUT , Replaced By: N910113014000
122
DRAG LINK FROM PITMAN ARM TO INTERMEDIATE LEVER EHRENREICH
122
DRAG LINK FROM PITMAN ARM TO INTERMEDIATE LEVER LEMFOERDER
122
DRAG LINK , Replaced By: A3004600405
123
JOINT R.H. THREAD EHRENREICH,5 180856
123
JOINT R.H. THREAD LEMFOERDER,5 180856
123
BALL JOINT , Replaced By: A0013300135
123
BALL JOINT , Replaced By: A0004633429
126
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER, TO 002 460 14 05, 15 05,K 226468
126
CLAMP , Replaced By: A0003382645
126
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER, TO 002 460 14 05, 15 05,K 226468
129
SCREW SHACKLE TO TORSION BAR,5 904661
132
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
132
NUT , Replaced By: N913004012008
135
BOOT FIXED PART OF JOINT
138
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
141
TRUNNION BEARING STEERING INTERMEDIATE ARM
144
SCREW BRACKET TO CAB CONSOLE,K 035197
147
SHIM STEERING INTERMEDIATE ARM
150
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
153
STEERING INTERMEDIATE ARM STEERING INTERMEDIATE ARM
153
STEERING INTERMEDIATE ARM , Replaced By: A3004630310
153
STEERING INTERMEDIATE ARM STEERING INTERMEDIATE ARM
153
STEERING INTERMEDIATE ARM , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 035574, Replaced By: A3004630010
156
SEAL RING
156
RADIAL SEAL RING , Replaced By: A0079976446
159
SPACER WASHER INTERMEDIATE LEVER TO BEARING BRACKET
162
TAPERED ROLLER BEARING FRONT
165
TAPERED ROLLER BEARING BOTTOM
165
TAPERED ROLLER BEARING INTERMEDIATE LEVER TO BEARING BRACKET
168
GREASE NIPPLE
171
THRUST WASHER STEERING INTERMEDIATE ARM BEARING
174
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
177
CAP AT STEERING INTERMEDIATE ARM
180
DRAG LINK REAR EHRENREICH
180
DRAG LINK REAR LEMFOERDER
180
DRAG LINK , Replaced By: A3004600605
183
JOINT R.H. THREAD EHRENREICH,5 180856
183
JOINT R.H. THREAD LEMFOERDER,5 180856
183
BALL JOINT , Replaced By: A0013300135
183
BALL JOINT , Replaced By: A0004633429
186
CLAMP CLAMP, ONE-HOLE
186
CLAMP , Replaced By: A4619955044
189
SCREW CLAMP, TWO-HOLE, UP TO CHASSIS 5 034559, FROM CHASSIS SEE SERIE
192
HEXAGON NUT
192
NUT , Replaced By: N910113010002
192
NUT , Replaced By: N913004010010
195
BOOT FIXED PART OF JOINT
198
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
201
SHOCK ABSORBER
201
SHOCK ABSORBER
201
SHOCK ABSORBER , Replaced By: A0004636132
201
SHOCK ABSORBER , Replaced By: A0004635932
204
RUBBER RING
204
RUBBER RINGTO 321 463 05 32
207
BUSHING
213
BOOTLEMFOERDER
213
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0003300785
216
NUT , UP TO CHASSIS 910369 ALSO INSTALLED ON 500000-501455 FROM CHASSIS 501456-599999 AND FROM CHASSIS 910370 SEE UNIT MICROFICHE 730.800
219
SCREW CROSS MEMBER TO FRONT SPRING REAR BRACKET M 14X1.5X70
219
SCREW , Replaced By: N308676014014
222
NUT M14X1,5 MM
225
BRACKET STEERING SHOCK ABSORBER
225
BRACKET STEERING SHOCK ABSORBER
228
HEXAGON HEAD BOLT. SCREW PULL ROD TO TRANSFER CASE AND TO SIDE MEMBER
228
SCREW , Replaced By: N308765012003
228
SCREW COVER PLATE TO BRACKET
228
SCREW COVER PLATE TO BRACKET
231
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
999
TIE ROD END , Replaced By: A0004632229
999
JOINT , Replaced By: A0004632229
999
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
999
CLAMP , Replaced By: A0003382645
999
CLAMPEHRENREICH
999
DRAG LINK END , Replaced By: A0003303235
999
BALL JOINT
999
REINFORCEMENT , Replaced By: A0004660095
999
SEAL CONE LINE CONNECTION
999
NEEDLE BEARING
999
NEEDLE BEARING , Replaced By: A0129818510, +001A3574620075
999
NEEDLE BEARING
999
NEEDLE BEARING TOP
999
NEEDLE BEARING TOP
999
PROTECTIVE CAP
999
LINE FROM CONNECTOR III TO CONNECTOR IV
999
STEERING SHAFT ,045858, Replaced By: A3014600909, +001A0119815110, +001A0119817310
999
BUSHINGTO 301 460 01 09
999
STEERING SHAFT , Replaced By: A3014601009, +001A0119815110, +001A0119817310
999
STEERING SHAFT
999
STEERING SHAFT
999
STEERING SUPPORT
999
BOOT
999
BUSHING BRACKET TO FRAME
999
BUSHING ,582084
999
WASHER TOP
999
STEERING COLUMN BRACKET , NOT USED
999
BOOT , NOT USED
999
SHELL STEERING COLUMN PANELLING,REAR
999
SHELL STEERING COLUMN PANELLING,FRONT
999
PLUG TOP,5 220080
999
CLAMP25-40X13 MM
999
COTTER PIN LEVER TO SUPPORT
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
WOOD SCREW STEERING COLUMN PANELLING
999
SCREW , Replaced By: N304017010050
999
GLAND , Replaced By: A0019901967
999
GLAND LINE CONNECTION
999
GLAND , Replaced By: A0019901267
999
SCREW , Replaced By: N304017010055
999
NUT STEERING WHEEL TO STEERING COLUMN
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N910113010000
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
UNION NUT LINE CONNECTION
999
UNION NUT LINE CONNECTION, Replaced By: N000000006243
999
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
