Поз.
Артикул
Описание
13
SUPPORT FAN,002448
30
BEARING BODY FAN DRIVE
31
SCREW PLUG 4/2-WAY VALVE
32
SEAL RING PNEUMATIC VALVE
32
SEAL RING , Replaced By: N007603010110
33
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
33
SCREW , Replaced By: N304017008053
34
WASHER EXHAUST MUFFLER TO STRAP
34
WASHER , Replaced By: N000125008443
35
NUT BRACKET TO SIDE MEMBER
36
FAN SHAFT
37
GROOVED BALL BEARING BELT TIGHTENER PULLEY TO BELT TIGHTENER SPINDLE
38
LOCK RING52X2 MM
39
CYLINDR. ROLLER BEARING ON RADIATOR SIDE
39
CYLINDR. ROLLER BEARING FAN DRIVE
40
SEAL RING CASE COVER
42
PULLEY ,002448
43
HUB FAN DRIVE
44
SCREW PIPE CLAMP
44
SCREW , Replaced By: N304017008021
45
NUT , Replaced By: N913004008001
46
LOCK WASHERROCKINGER TYP 59 G140,59 G150
47
NUT WEAR INDICATOR
49
HUB POWER SAVER FAN
50
LOCK WASHERROCKINGER TYP 59 G140,59 G150
51
NUT WEAR INDICATOR
53
FAN
54
SCREW BRACKET TO EXHAUST PIPE BRACKET
54
SCREW , Replaced By: N304017008024
55
NUT BRACKET TO SIDE MEMBER
56
LEVER TIGHTENER PULLEY,042507
56
LEVER , Replaced By: A3072000173
57
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
57
SCREW , Replaced By: N308676012011
57
SCREW , Replaced By: N308676012031
60
SPACER WASHER BELT TIGHTENER 1.00 MM
60
SPACER WASHER BELT TIGHTENER 0.50 MM
60
SPACER WASHER BELT TIGHTENER 0.20 MM
61
GROOVED BALL BEARING BELT TIGHTENER PULLEY TO BELT TIGHTENER SPINDLE
62
SPACER TUBE
63
LOCK RING52X2 MM
65
LOCK RING
66
SEAL RING BATTERY MASTER SWITCH
67
EXPANSION PLUG
68
SCREW PLUG 4/2-WAY VALVE
69
NUT TIGHTENER PULLEY
70
SUPPORT CLAMPING LEVER
71
STUD SUPPORT TO FAN SUPPORT
72
SCREW RADIATOR M 10X45
73
WASHER BRACKET TO COVERING
73
WASHER , Replaced By: N009021010209
73
WASHER RADIATOR TO RUBBER MOUNTING
73
WASHER , Replaced By: N000125010532
74
NUT STRAP TO BRACKET
74
NUT , Replaced By: N910113010000
75
NUT STRAP TO SUPPORT
78
V-BELT FROM VIBRATION DAMPER TO TIGHTENER PULLEY 12.5X1950 MM,000164
78
V-BELT FROM VIBRATION DAMPER TO TIGHTENER PULLEY, UP TO IDENT-NO. 008997 EXCEPT FOR 008662,008668,008679,008701,008745,008746,008753-008757,008765-008769,008777-008782,008789-008793, 008800,008801,008802,008825,008835-008837,008839,008840,008868,008869,008881,008882,008885,008892- 008894,008905,008906,008917-008919,008929,008930,008941-008943,008954-008956,008967-008969,008980, 008983,008990,008993-008995. ALSO INSTALLED ON 009002,009023,009067,009090
79
V-BELT FROM TIGHTENER PULLEY TO FAN PULLEY 12.5X1150,002448
79
V-BELT , Replaced By: A0039970692
79
V-BELT , Replaced By: A0039970692
79
V-BELT FROM TIGHTENER PULLEY TO FAN DRIVE 12X1250 MM,D 180260
999
SCREW
999
GUIDE
999
SPACER RING
999
GASKET , Replaced By: A0002060680
999
FLANGE
999
COVERTO 000 200 06 23
999
PRIMARY CUPTO 000 200 06 23
999
GASKET
999
DRAIN PIPE
999
GASKET O.D., 37 MM
999
RADIATOR CAP FILLER NECK
999
RADIATOR CAP FILLER NECK
999
RECEPTACLE , Replaced By: A0005831835
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 70 CCM,TO 002 205 65 06
999
SCREW SENSOR TO BRACKET
999
SCREW , Replaced By: A0009842029
999
CLAMP , Replaced By: N916016038201
999
FAN
999
SEAL RING TIGHTENER PULLEY, UP TO IDENT NO.035608 ALSO INSTALLED ON 035610,035643,035659,035698,035709,035728,036213
999
BALL BEARING
999
V-BELT , Replaced By: A0039975992
999
V-BELT , Replaced By: A0039974892
999
SEAL RING
999
V-BELT , Replaced By: A0039974992
999
V-BELT , Replaced By: A0079975492
999
HOSE , Replaced By: A0219977682
999
V-BELT , Replaced By: A0069972192
999
V-BELT , Replaced By: A0039974892
999
V-BELT SET2 PIECES 12.5X1950 MM
999
SEAL RING
999
HOSE
999
COOLING WATER PIPE FROM BUBBLE SEPARATOR TO EXPANSION TANK TO 300 500 01 49
999
BELT TIGHTENER
999
PULLEY FAN DRIVE 180 MM
999
HUB
999
STAY LEFT TOP
999
BREATHER PIPE , FOR USE WITH MERCEDES-BENZ BODY UP TO IDENT NO. 030376, NOT FOR USE WITH MERCEDES-BENZ BODY UP TO IDENT NO. 030451, Replaced By: N900271012018, +002N900017016000
999
BRACKET , Replaced By: A3604280243
999
SLEEVE
999
MOUNTING
999
LEVER ,042506, Replaced By: A3072000573, +001A0119975447
999
BRACKET
999
ANGLE LINE MOUNTING
999
BRACKET DE-AERATION LINE, NOT USED
999
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
SCREW OIL PIPE TO SLEEVE VALVE
999
SCREW , Replaced By: N304017008018
999
SCREW , Replaced By: N304017006020
999
SCREW CAB FLOOR COVERING M 6X25
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW SUPPORT TO FENDER
999
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
999
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
NUT , Replaced By: N910113006001
999
CLAMP SAFETY VALVE AT BRACKET
999
CLAMP HOSE TO FITTING AND TO OIL TANK
