Поз.
Артикул
Описание
1
CLUTCH PRESSURE PLATE , Replaced By: A0032502304
1
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
3
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
4
CLAMP , Replaced By: A0002523227
4
CLAMP RELEASE FLANGE TO RELEASE LEVER
5
PRESSURE PLATE , Replaced By: A0002525112
5
PRESSURE PLATE , FROM CHASSIS 004588,ALSO INSTALLED ON 004537,004538,004546-004548,004557,004558,004567,004569,004570,004581,004582,004586
6
RELEASE LEVER CLUTCH ACTUATION
7
SPINDLE FOR LEVER TO 98 345 586 00 25
8
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
10
ROLLER
10
ROLLER
11
BRACKET RELEASE LEVER
12
LOCK PLATE RELEASE LEVER TO SHAFT
13
INSULATING WASHER
15
FLANGE CLUTCH PRESSURE PLATE
16
SPRING CLUTCH PRESSURE PLATE
17
PRESSURE SPRING CLUTCH PRESSURE PLATE
17
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
19
LEAF SPRING FOR BRACKETS
20
NUT , Replaced By: A0002523372
20
NUT FOR BRACKETS
21
LOCK , Replaced By: A0002521173
21
LOCK FOR BRACKETS
22
LOCK WASHER BRACKET TO STEERING COLUMN END
23
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
23
SCREW RELEASE LEVER,BRACKET
43
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
44
SCREW VALVE TO BRACKET, Replaced By: N304014008002
44
SCREW VALVE TO BRACKET
45
CLUTCH DISC , Replaced By: A0122506703
45
CLUTCH DISC ASBESTOS-FREE LINING
45
CLUTCH DISC , EXHAUST STOCK OF OLD PARTS UP TO CHASSIS 004086, Replaced By: A0052502403
45
CLUTCH DISC , Replaced By: A0042507303
45
CLUTCH DISC
45
CLUTCH DISC , Replaced By: A0052501903
45
CLUTCH DISC
46
LEAF SPRING , Replaced By: A0002523419
46
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002524419, +002A0002523975
46
LEAF SPRING
47
RIVET , Replaced By: A0002522075
47
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
47
RIVET LEAF SPRING TO CLUTCH DISC
49
CLUTCH LINING ASBESTOS-FREE
49
CLUTCH LINING , Replaced By: A0012527610
49
CLUTCH LINING ASBESTOS-FREE
49
CLUTCH LINING , Replaced By: A0002528810
49
CLUTCH LINING , Replaced By: A0002528810
49
CLUTCH LINING , Replaced By: A0012524310
49
CLUTCH LINING
50
RIVET , Replaced By: A0002521275
50
RIVET LINING WITH INTERMEDIATE SPRING
50
RIVET LINING WITH INTERMEDIATE SPRING,5 563495
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
BALL SOCKET CLUTCH SLAVE CYLINDER, UP TO IDENT NO. 007219 ALSO INSTALLED ON 007228-007232,007241-007243,007245,007646,007254
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
SCREW MOUNTING AND RAIL TO LEAF SPRING
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125010532
999
REPAIR KIT , Replaced By: A3892500014
999
SHAFT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 285575, Replaced By: A3852500014
999
WASHER AS REQUIRED 1.10 MM
999
WASHER AS REQUIRED 0.90 MM
999
SPACER RING BRACKET TO TRANSMISSION,5 215322
999
VALVE CLUTCH SLAVE CYLINDER
999
LEVER CLUTCH ACTUATION,4 601610
999
WASHER , Replaced By: A3094310051
999
VALVE , Replaced By: A3075530107
999
PIN CLUTCH SLAVE CYLINDER,006538
999
LOCK
999
HOUSING
