Поз.
Артикул
Описание
1
3
SPRING
4
RELEASE LEVER , ON SPECIAL REQUEST, H.D. CLUTCH
5
6
PIN
7
CLAMPING SLEEVE
8
SPACER RING
9
NUTTO 001 250 03 04
10
PRESSURE SPRING CLUTCH PRESSURE PLATE
12
PRESSURE SPRING , FROM IDENT NO. 760272 ALSO INSTALLED ON 500001-599999
13
SLEEVE
15
SCREW
15
SCREW , Replaced By: N000000000190
18
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
26
HOUSING
26
27
BALL PIVOT
28
BOOT
30
SEAL HOLDER
31
SCREW , Replaced By: N304017006018
31
SCREW COVER PLATE TO COVER PLATE M 6 X 12
32
SCREW CONNECTOR TO EXHAUST MANIFOLD
33
LOCK WASHER FITTING TO BRACKET
35
WASHER
36
NUT STRAP TO SUPPORT,5 149419
44
44
48
49
49
50
52
SNAP RING DOUBLE LEVER TO BRACKET
53
54
SCREW , Replaced By: N304017010050
54
SCREW CLUTCH TO FLYWHEEL
54
SCREW , Replaced By: N304017010055
56
WASHER , Replaced By: N000125010532
56
WASHER RADIATOR TO RUBBER MOUNTING
57
SPRING WASHER STEERING COLUMN BRACKET TO CAB
58
NUT BATTERY CABLE
58
NUT BRACKET TO SUPPORT AND TO END PIECE
60
61
SCREW CLUTCH TO FLYWHEEL
62
SCREW , Replaced By: N304017008021
62
SCREW PIPE CLAMP
63
SPRING WASHER , Replaced By: N000137008212
63
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
70
SLAVE CYLINDERTEVES
70
SLAVE CYLINDER CLUTCH OPERATION FAG
71
BOOT , Replaced By: A2012950983
71
BOOTFAG
72
LOCK
73
VALVE CLUTCH SLAVE CYLINDER
74
PROTECTIVE CAP , Replaced By: A0004217187
74
PROTECTIVE CAP ,5 962906
80
REPAIR KIT , Replaced By: A0002900611
80
REPAIR KIT , Replaced By: A0002901111
80
REPAIR KIT SLAVE CYLINDER FAG
85
86
87
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
87
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
87
SCREW , Replaced By: N000933008337
87
SCREW , Replaced By: N304017008027
87
SCREW , Replaced By: A0099900101
88
SPRING WASHER , Replaced By: N000137008212
88
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
89
NUT
999
BELL HOUSING , Replaced By: A1152512601
999
BELL HOUSING , 030 000140 033 000071 PART INCLUDED IN RANGE OF DELIVERY OF TRANSMISSION ASSEMBLY
999
RELEASE YOKE , 102,103 219674 ALSO INSTALLED ON 219935,219936,220064,220096,220232. EXCEPT FOR 219267,219275,219283,219285,219287,219293,219296,219301,219302,219304,219307,219309,219313,219317, 219319-219321,219325,219326,219328-219331,219333,219335,219336,219338,219339,219341,219342,219346, 219347,219350,219351,219354,219357-219361,219363-219380,219384,219385,219387-219389,219391-219395, 219397,219399,219400,219402-219409,219411-219415,219417-219422,219424-219426,219428-219435,219437, 219439-219447,219449-219453,219459-219471,219473-219483,219485-219499,219502-219516,219520-219599, 219601-219673. 183 014172 ALSO INSTALLED ON 014174-014198,014203,014209,014215,014221,014225,014231,014407,014486,014630.
999
RELEASE YOKE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1152900029
999
BALL PIVOT
999
BELL HOUSING , FROMIDENT NO. 240107-499999 ALSO INSTALLED ON 237253,237254,240088556500P 000001P 030294, Replaced By: A6022501905
999
CYLINDRICAL PIN
999
WASHER , Replaced By: N000125010532
999
NUT BRACKET TO EXHAUST PIPE BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
