Поз.
Артикул
Описание
1
RADIATOR , FROM CHASSIS 611358 EXCEPT FOR 611519,611537 ALSO INSTALLED ON 610763,610832,610834,610848,610863
1
RADIATORAUTOKUEHLER GMBH HOFGEISMAR, 009807 UP TO CHASSIS 611357 ALSO INSTALLED ON 611519,611537 EXCEPT FOR 610763,610832,610834,610848,610863
4
SCREW PLUG WATER DRAIN
6
SEAL RING FUEL LINE TO FEED PUMP
11
RADIATOR CAP WITH PRESSURE RELIEF VALVE
11
RADIATOR CAP TO 309 500 44 02 AUTOKUEHLER GMBH HOFGEISMAR
11
RADIATOR CAPTO 335 500 12 03
15
SCREW BRACKET TO CROSS CONNECTION STRUT
15
SCREW , Replaced By: N304017008034
16
NUT , Replaced By: N913004008001
16
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
21
RUBBER BUFFER BRACKET TO SUPPORT
22
WASHER RADIATOR TO RUBBER MOUNTING
22
WASHER , Replaced By: N000125010532
23
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
24
NUT BRACKET TO SUPPORT AND TO END PIECE
26
BRACKET ,556499
29
BRACKET ,193443
31
RUBBER BUFFER COVERING TO FRAME
32
WASHER EXHAUST MUFFLER TO STRAP
32
WASHER , Replaced By: N000125008443
33
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
34
NUT
37
FAN SHROUD , 309.0 FROM CHASSIS 001151, 309.1 FROM CHASSIS 015697 ALSO INSTALLED ON:015539,015594,015609
40
RUBBER SECTION AT LEFT SIDE MEMBER 85 MM
51
WASHER AS REQUIRED 3 MM
51
WASHER TOW HOOK TO SIDE MEMBER,FRONT
52
SCREW CONNECTOR TO EXHAUST MANIFOLD
52
SCREW BRACKET TO TRANSMISSION
52
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X65
52
SCREW FRONT EXHAUST PIPE TO EXHAUST MANIFOLD M 12X60
54
SHAFT , NOT USED
57
HOSE FROM THERMOSTAT TO RADIATOR, 309.0 FROM CHASSIS 003613-556499
61
CLAMP
61
CLAMP , Replaced By: N000000000671
62
HOSE FROM RADIATOR TO WATER PUMP, 309.0 FROM CHASSIS 003903-556499
66
CLAMP
66
CLAMP , Replaced By: N000000000671
67
PIPE ELBOW FROM CYLINDER HEAD TO HEAT EXCHANGER,373687
68
UNION NUT LINE CONNECTION
69
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
70
HOSE FROM CYLINDER HEAD TO HEAT EXCHANGER,373688-556499
73
HOSE FROM HEAT EXCHANGER TO WATER PUMP,556499
88
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
88
CLAMP , Replaced By: N000000000667
999
GASKET O.D., 37 MM
999
RUBBER SECTION , Replaced By: A0009870772
999
RUBBER BUFFER , Replaced By: A0019875240
999
RUBBER BUFFER EXHAUST MUFFLER
999
BRACKET ,193443
999
BRACKET , Replaced By: A3095000231
999
SUPPORT ,193443
999
SUPPORT ,193443
999
BRACKET , Replaced By: A3184924841
999
BRACKET , Replaced By: A3184924841
999
HOSE , Replaced By: A3095061335
999
HOSE , EXHAUST STOCK OF OLD PARTS FROM CHASSIS 373688-514819, Replaced By: A3095062735
999
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
