Поз.
Артикул
Описание
20
FUEL TANK , Replaced By: A3094703001
20
FUEL TANK
22
FUEL STRAINER , 703022
23
SEAL RING FUEL STRAINER SCREEN
25
SENDER UNIT FUEL TANK
27
GASKET SENDER UNIT AND COVER TO FUEL TANK
27
GASKET FUEL GAUGE SENDER UNIT TO FUEL TANK
28
NUT TACHOGRAPH TO BRACKET
29
SEAL RING SENDER UNIT AND COVER TO FUEL TANK
37
FILLER CAP FUEL TANK
38
GASKET , Replaced By: A1104710280
38
GASKET
70
SUPPORT , Replaced By: A3094702442
70
SUPPORT FUEL TANK
72
SCREW BRACKET TO SIDE MEMBER
72
SCREW , Replaced By: N304017010002
74
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
76
SHIM SUPPORT TO SIDE MEMBER
77
STRAP FUEL TANK TO SUPPORT
79
RUBBER STRIP SUPPORT TO SIDE MEMBER
81
NUT BRACKET TO SUPPORT AND TO END PIECE
106
BRACKET FUEL FILTER,176361
106
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO. 176361-303382, Replaced By: A3094761336
107
SCREW END PIECE TO EXHAUST PIPE M 10X25
108
NUT AIR CLEANER ELEMENT
110
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
121
LINE FROM FUEL TANK TO "T" CONNECTION FITTING
125
RISING PIPE , PRIOR TO INSTALLATION,SHORTEN RISING PIPE TO 323 MM IN LENGTH
126
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
127
SEAL RING CONNECTION: 1,4 719029
128
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
138
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
138
LOOM TIE , Replaced By: N916017011000
138
CLAMP , Replaced By: N916017011001
138
CLAMP , Replaced By: N000000000665
999
LOOM TIE LINE MOUNTING
999
LOOM TIE VENT VALVE TO FUEL TANK
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
UNION SCREW ,B 688751
999
LINE , Replaced By: A3104282301
999
LINE ,176360, Replaced By: A3104282301, +001A1809900066
999
LINE , FOR TRUCKS UP TO CHASSIS 176360,FOR BUS UP TO CHASSIS 026054, Replaced By: A3094702665, +001A3104282301, +001A0004295235, +001A1809900066, +002A0009971190
999
LINE ,176361-303382, Replaced By: A3104282301, +001A0004290801, +001A0004295235, +001A1809900066, +002A0009971190
999
LINE , FOR TRUCKS FROM CHASSIS 176361,FOR BUS FROM CHASSIS 026055, Replaced By: A3094702665, +001A0004290801, +001A0004295235, +002A0009971190
999
SLEEVE LINE CONNECTION
999
CLAMP , Replaced By: N000000000665
