Поз.
Артикул
Описание
30
T-FITTING LINE CONNECTION
48
MUFFLER PRESSURE REGULATOR BREATHING
54
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
72
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
72
BRAKE VALVE (SERVICE BRAKE VALVE) BOSCH
72
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
72
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
72
BRAKE VALVE (SERVICE BRAKE VALVE) BOSCH
72
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
72
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
72
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
72
BRAKE VALVE (SERVICE BRAKE VALVE) BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
72
BRAKE VALVEKNORR
72
BRAKE VALVEBOSCH
72
BRAKE VALVEWABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
78
REPAIR KIT SERVICE BRAKE VALVE WABCO
78
REPAIR KIT , Replaced By: A0004308106
78
REPAIR KIT SERVICE BRAKE VALVE WABCO
78
REPAIR KIT , Replaced By: A0004308506
78
REPAIR KIT"WABCO"
78
REPAIR KIT , Replaced By: A0004308406
84
VALVE (PRESSURE RATIO VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
90
REPAIR KIT PRESSURE RATIO VALVE
102
BRACKET PRESSURE RATIO VALVE
102
BRACKET ,8 004624
108
SCREW BRACKET TO FRAME M 12X35
114
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
114
NUT , Replaced By: N910113012003
120
WASHER EXHAUST MUFFLER TO STRAP
120
WASHER , Replaced By: N000125008443
126
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
126
NUT , Replaced By: N913004008001
132
VALVE. SHUTTLE VALVE (SHUTTLE VALVE) VOSS
132
VALVE , Replaced By: A0044291544
138
ADAPTER FITTING LINE CONNECTION TO ENGINE
144
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
150
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
156
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
162
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
168
SCREW. UNION SCREW LINE CONNECTION
174
NUT BRACKET TO SIDE MEMBER
180
VALVE (RELAY VALVE) BOSCH, REPAIR IMPOSSIBLE
180
VALVE , Replaced By: A0044293844
180
VALVE (RELAY VALVE) BOSCH, REPAIR IMPOSSIBLE
180
VALVE (RELAY VALVE) WABCO, REPAIR IMPOSSIBLE
180
VALVE FRONT AXLE II RELAY VALVE "GRAU", NOT USED
180
VALVE FRONT AXLE II RELAY VALVE "BOSCH"
180
VALVE FRONT AXLE II RELAY VALVE "WABCO"
186
REPAIR KIT RELAY VALVE TO 003 429 93 44,WABCO
186
REPAIR KIT RELAY VALVE "GRAU"
186
REPAIR KIT RELAY VALVE BOSCH
186
REPAIR KIT RELAY VALVE TO 004 429 38 44,WABCO
198
BRACKET RELAY VALVE
198
BRACKET FRONT AXLE RELAY VALVE,5 585846
198
BRACKET FRONT AXLE,RIGHT
198
BRACKET FRONT AXLE,LEFT
198
BRACKET RELAY VALVE TO CROSS MEMBER
198
BRACKET RELAY VALVE
198
BRACKET RELAY VALVE TO CROSS MEMBER
222
BUSHING VALVE TO BRACKET
228
SCREW BRACKET TO SIDE MEMBER M 14X1.5X50,5 543914
228
SCREW STRAP TO BRACKET
228
SCREW BRACKET TO SIDE MEMBER
228
SCREW , Replaced By: N304017008040
228
SCREW SUPPORT TO FENDER
228
SCREW , Replaced By: N304017008018
228
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
228
SCREW , Replaced By: N304017008027
240
WASHER BRACKET TO SIDE MEMBER
240
WASHER SUPPORT TO SIDE MEMBER
240
WASHER , Replaced By: N007349015002
246
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
246
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
246
NUT , Replaced By: N913004008001
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER TRAILER CONTROL VALVE
264
MUFFLER , Replaced By: A0004302370
264
MUFFLER DEHYDRATOR
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER VALVE BLEEDING
264
MUFFLER , Replaced By: A0004302470
270
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
276
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
276
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
999
BREATHER PIPE COMPRESSED AIR LINE TO EXHAUST MUFFLER
999
FITTING PRESSURE REGULATOR,CONNECTION: "30"
999
BRACKET REDUCTION VALVE, SIMPLE PART-PLEASE HAVE SHOP MADE
