Поз.
Артикул
Описание
109
VALVE (REDUCTION VALVE)
109
VALVE (REDUCTION VALVE),5 359430
109
VALVE (REDUCTION VALVE)
112
T-FITTING HOSE WIDTH, 9 MM,TO M 22
113
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
113
TEST CONNECTION
113
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
113
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
113
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
115
SCREW , Replaced By: N304017008021
115
SCREW PIPE CLAMP
115
SCREW , Replaced By: N304017008034
115
SCREW BRACKET TO CROSS CONNECTION STRUT
117
WASHER , Replaced By: N000125008443
117
WASHER EXHAUST MUFFLER TO STRAP
119
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
121
NUT , Replaced By: N913004008001
121
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
123
BRACKET BREATHER LINE TO SIDE MEMBER
125
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
127
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
129
SCREW. UNION SCREW LINE CONNECTION
131
SCREW PLUG , Replaced By: N000908022011
131
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
133
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
133
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
135
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
137
ELBOW FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
139
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
141
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
141
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
143
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
555
BRAKE PRESSURE REGULATORWABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
560
REPAIR KIT BRAKE POWER REGULATOR WABCO
999
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
999
AIR CLEANER COMPLETE TO BOSCH,KNORR
999
REPAIR KITWABCO
999
REPAIR KIT PRESSURE REGULATOR KNORR,K 126821
999
REPAIR KIT PRESSURE REGULATOR BOSCH,K 126821
999
MUFFLER TRAILER CONTROL VALVE
999
VALVE
999
HEATER CARTRIDGEBOSCH
999
HEATERKNORR
999
HEATERBOSCH, Replaced By: A0005450333
999
HEATERWABCO
999
VALVE (THROTTLE CHECK VALVE)
999
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0034291444
999
VALVE. REPAIR KIT SHUTTLE VALVE
999
SEAL RINGWABCO
999
CROSS FITTING AIR DEHYDRATOR,CONNECTION: "21"
