Поз.
Артикул
Описание
160
TRANSMISSION CASE
160
TRANSMISSION CASE ,019885
160
TRANSMISSION CASE ,019885
160
TRANSMISSION CASE , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365, Replaced By: A1152705911, +001A1092700689, +001A1092701189
160
TRANSMISSION CASE , FROM TRANSMISSION: 115.000,002,010,015 031535 115.100,102,103,110,112,115 024366, Replaced By: A1152707711, +001A1152700457
160
TRANSMISSION CASE , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365, Replaced By: A1152705911, +001A1092700689, +001A1092701189
162
BRACKET ,024695
163
SCREW PLUG
164
SEAL RING
165
BOOT
167
SCREW PLUG
168
SEAL RING
169
SEAL RING
170
GUIDE TUBE , AGAINST SQUEALING OF TRANSMISSION
172
HOUSING
172
HOUSING
173
SPRING
174
SCREW
175
SPRING WASHER LICENSE PLATE TO BRACKET
178
SWITCH
179
SEAL RING
180
SPRING WASHER ALTERNATOR CONNECTION D+
181
SCREW PLUG SOCKET
184
LEVER
184
LEVER , Replaced By: A1152700656
184
LEVER , UP TO CHASSIS: 115.010 033023 115.015 030973 115.110 073870 115.115 033702, Replaced By: A1152700856, +001A1152780910, +001A1152780950, +001A1152780153, +001A0005453306, +001A0049973745, +001N000084004155, +001N000125006407, +001N000137004101, +001N000931006095, +001N000934006006, +001N009021004202
186
CONTROL SHAFT , FROM CHASSIS: 115.010 033024 115.015 030974 115.110 073871 115.115 033703
187
BUSHING , FROM CHASSIS: 115.010 033024 115.015 030974 115.110 073871 115.115 033703
188
SPACER TUBE , FROM CHASSIS: 115.010 033024 115.015 030974 115.110 073871 115.115 033703
189
SEAL RING , FROM CHASSIS: 115.010 033024 115.015 030974 115.110 073871 115.115 033703
192
SCREW AT SIDE MEMBER,OUTSIDE
193
WASHER , UP TO CHASSIS: 017 029988 114 000523 117 064694
194
NUT BALL PIVOT TO LEVER
195
SCREW PLUG SOCKET TO COVERING
196
WASHER COVERING TO CYCLONE AIR TRAP
196
WASHER , Replaced By: N009021004207
197
SPRING WASHER ALTERNATOR CONNECTION D+
200
DETENT
201
SCREW COVERING
202
SPRING WASHER LICENSE PLATE TO BRACKET
205
VALVE , FROM TRANSMISSION: 115.000,002,010,015 031535 115.100,102,103,110,112,115 024366
205
VALVE , Replaced By: A1092701089, +001A1152771758
208
VALVE , Replaced By: A1092701189, +001A1152771758
208
VALVE , FROM TRANSMISSION: 115.000,002,010,015 031535 115.100,102,103,110,112,115 024366
210
O-RING , FROM TRANSMISSION: 115.000,002,010,015 031535 115.100,102,103,110,112,115 024366
210
SEAL RING , Replaced By: A0169973448
211
SPRING
212
PIN AS REQUIRED 22 MM
218
PIN
219
LEVER
225
PIN
226
SPRING
227
SCREW
228
NUT
230
PISTON
232
BOOT
233
SPRING
234
PIN
235
SNAP RING
236
SPRING
237
COVER
238
SEAL RING
239
SNAP RING
243
LEVER
244
WASHER
245
LOCK PLATE
246
LEVER
248
SCREW
249
SPRING WASHER LICENSE PLATE TO BRACKET
250
NUT BATTERY MOUNTING
250
NUT CYLINDER TO BRACKET TO0002902112
254
BRAKE BAND , Replaced By: A1162701762
254
BRAKE BAND
256
SPRING , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365
257
SPRING , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365
259
PISTON , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365
260
BOOT
262
COVER
266
SEAL RING
267
SNAP RING
270
PISTON
272
SEAL RING
274
SEAL RING
275
SPRING SECOND BRAKE
275
SPRING , Replaced By: A1159932305, +001A1152771677
278
COVER
279
SNAP RING
282
BRAKE BAND
282
BRAKE BAND , Replaced By: A1152707062
284
BRAKE BAND , Replaced By: A1152707362
284
BRAKE BAND
290
SPRING WASHER , Replaced By: N000137008212
291
SCREW VALVE TO BRACKET
293
GASKET , Replaced By: A1152773380
293
GASKET
403
PISTON
409
VACUUM BOX
410
PIN 39.65 MM
412
SPRING ,020054
850
GASKET KIT , Replaced By: A1152702201
850
GASKET KIT
999
SOLENOID
999
NEEDLE
999
SEAL RING ,000029
999
NEEDLE BEARING ,011777
999
LOCK ,022986
999
NEEDLE BEARING , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO TRANSMISSION 720.103 000019 720.103 000047, Replaced By: A0059818110
999
SEAL RING
999
NEEDLE BEARING ,043589
999
SEAL RING ,031534
999
SEAL RING
999
HOSE FROM TRANSMISSION TO OIL COOLER
999
HOSE , FROM CHASSIS: 010 043070 015 042951 110 101088 115 046326
999
OUTER DISC , Replaced By: A1092721826
999
LOCK ,020254
999
GASKET , NO LONGER AVAILABLE INDIVIDUALLY
999
ANNULUS , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN RANGE OF DELIVERY OF FRONT PLANETARY GEAR TRAIN
999
BOOT , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
OUTER DISC
999
OUTER DISC
999
OUTER DISC , 017664 EXCEPT FOR 015709-017194
999
OUTER DISC , WITH 108 270 09 01: FROM TRANSMISSION 025698-033564 ALSO INSTALLED ON 020066-023715, WITH 108 270 13 01: FROM TRANSMISSION 000 001
999
OUTER DISC , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
PIN AS REQUIRED 23 MM
999
PIN AS REQUIRED 24 MM
999
PIN 25 MM,AS REQUIRED
999
PIN 26 MM,AS REQUIRED
999
GROMMET OIL LINE TO CONVERTER HOUSING
999
CLAMP
999
GASKET KIT , Replaced By: A1142703301
999
LINE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1232701347, +001A1162700241, +001A1232700079, +001A1129970381, +001A1159975082
999
VALVE BODY ASSEMBLY
999
VALVE BODY ASSEMBLY
999
VALVE BODY ASSEMBLY , 007008 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
AUTOMATIC TRANSMISSION , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE BODY ASSEMBLY
999
GASKET KIT , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
THRUST PIN
999
GASKET KIT , Replaced By: A1152702001
999
REGULATOR VALVE
999
THRUST PIN
999
DETENT RANGE SELECTOR LEVER
999
VALVE BODY ASSEMBLY ,000029, Replaced By: A1152701607, +002A1152701068
999
VALVE ,024694
999
PIN
999
VALVE , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365
999
VALVE ,019885
999
FLANGE , 017664 EXCEPT FOR 015709-017194, Replaced By: A1152704120, +001A1092720326, +002A1092722326
999
GOVERNOR ,024694
999
VALVE BODY ASSEMBLY
999
VALVE BODY ASSEMBLY
999
GASKET KIT ,019885
999
FLANGE , 014863 EXCEPT FOR 013132-014433, Replaced By: A1152704120, +001A1092720326, +002A1092722326
999
VALVE BODY ASSEMBLY
999
DRIVE SHAFT ,009363
999
VALVE BODY ASSEMBLY
999
FLANGE , 017665-023454 ALSO INSTALLED ON 015709-017194 NO LONGER AVAILABLE
999
DRIVE SHAFT , Replaced By: A1152705425, +001A0029942641
999
DRIVE SHAFT ,031315
999
PISTON ,019885
999
DRIVE SHAFT ,029735043589 NO LONGER AVAILABLE
999
DRIVE SHAFT ,031316
999
PLANETARY CARRIER , UP TO CHASSIS: 010 036484 015 034954 110 084330 115 038326
999
SPACER WASHER AS REQUIRED 0.2 MM
999
SPACER WASHER AS REQUIRED 0.5 MM
999
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.20 MM
999
SPACER WASHER 0.5 MM,AS REQUIRED
999
SPACER WASHER AS REQUIRED 0.2 MM
999
SPACER WASHER 0.5 MM,AS REQUIRED
999
ANNULUS , NO LONGER AVAILABLE INDIVIDUALLY
999
PLANET GEAR
999
PLANET GEAR
999
OUTER DISC , Replaced By: A1092722026
999
PISTON
999
ANNULUS , NO LONGER AVAILABLE INDIVIDUALLY
999
PIN
999
SUN GEAR , NO LONGER AVAILABLE INDIVIDUALLY
999
BOOT
999
FLANGE
999
GUARD PLATE , 013131 EXCEPT FOR 010364-010763
999
DISC SUPPORT ,017085
999
GUARD PLATE
999
GUARD PLATE
999
SEAL RING , Replaced By: A0119976447
999
CASE ,026754
999
TUBE ,000029
999
GUIDE
999
GUIDE
999
SPACER WASHER
999
INTERMEDIATE PLATE ,024694
999
DETENT
999
LOCKING SHEET ,019885
999
INTERMEDIATE PLATE ,024694
999
SCREW , TO 115 270 12 11, 115 270 17 11
999
SHIFT VALVE
999
VALVE PART
999
SCREW , TO 115 270 27 11, 115 270 30 11, 115 270 39 11
999
SHIFT VALVE
999
VALVE BODY ASSEMBLY , Replaced By: A1152771801, +001N000084005105
999
SHIFT VALVE
