Поз.
Артикул
Описание
1
ELEMENT SUMMER VENTILATION FLAP, FROM CHASSIS:114.011 017604 114.015 131834 114.023 009936 115.010 112908 115.015 145989 115.110 299410
4
ROD , FROM CHASSIS:114.011 017604 114.015 131834 114.023 009936 115.010 112908 115.015 145989 115.110 299410
6
LOCK PLATE
9
LOCK , Replaced By: N918002004000
9
CLAMPING SPRING
11
CLAMP WIRE CABLE TO FIRE WALL
13
SCREW , Replaced By: N007985004107
16
ELEMENT , Replaced By: A0008001175
16
ELEMENT FOR EVAPORATOR CASE CHANGE-OVER FLAP
19
ROD , FROM CHASSIS:114.011 017604 114.015 131834 114.023 009936 115.010 112908 115.015 145989 115.110 299410 FROM CHASSIS: 115.115 153338
21
LOCK PLATE
24
LOCK , Replaced By: N918002004000
24
CLAMPING SPRING
26
SHEET METAL SCREW BOOT TO CAB FLOOR
30
HOSE *** 30 MM
40
HOSE FROM VACUUM SWITCH TO CIRCULATING-AIRFLAP-ELEMENT Y-SHAPE DISTRIBUTOR 600 MM
45
HOSE , Replaced By: A0089978582
45
HOSE FROM Y-DISTRIBUTOR TO AIR CONDITIONER CASE VACUUM ELEMENT,RIGHT
49
HOSE FROM VACUUM SWITCH TO CIRCULATING-AIRFLAP-ELEMENT Y-SHAPE DISTRIBUTOR 600 MM
55
BRANCH-OFF FITTING
58
CLAMP
70
HEATER CASE
95
HEATER CASE
95
HEATER CASE , Replaced By: A1158304462
100
COVER , UP TO CHASSIS: 115.010 118594 115.015 115810 115.110,112 318429 115.115 155810 FROM CHASSIS,SEE SA 55959
999
EVAPORATOR
999
CARBON BRUSH SET
999
CARBON BRUSH SET , Replaced By: A0008352575
999
HOSE , Replaced By: A0009976552
999
HOSE FROM Y-DISTRIBUTOR TO AIR CONDITIONER CASE VACUUM ELEMENT,RIGHT
999
ELEMENT , Replaced By: A0008001775
999
ELEMENT , Replaced By: A0008000875
999
DISTRIBUTOR , Replaced By: A1170780145
999
EVAPORATOR
999
HEATER CASE , Replaced By: A1158304462
999
LOCK WASHER. SPRING LOCK WASHER ELECTRIC CABLE TO HORN TO 004 542 44 20 /45 20
999
WASHER
999
LOCK WASHER T-FITTING TO BRACKET
