Поз.
Артикул
Описание
10
FRONT SEAT LEFT
26
SEAT CUSHION
58
CUSHION FRAME , UP TO CHASSIS: 015,017 129846 ALSO INSTALLED ON 130123 EXCEPT FOR: 128845,128980,129056,129058,129102,129216,129217,129704,129708,129728,129751-129753,129755-129758, 129761-129763,129768-129770,129772-129805,129807-129813,129815-129845.
64
SPRING CORE , Replaced By: A1149101622
72
PAD , FROM CHASSIS: 034089 ALSO INSTALLED ON: 033031,033673,033706,033709,033716,033736,033765,033914,033922,033926,033930,033934,033936,033938, 033939,033941-033951,033953,033955,033956,033959,033960,033962,033964,033966,033967,033969-033998, 034000-034010,034012-034022,034024-034087.
78
CLIP COVER TO PAD
80
COVER COMPLETELY SEWN, UP TO CHASSIS: 010 111535, EXCEPT FOR: 111524,111526,111528,111529,111531,111532,111534. 015 143407, EXCEPT FOR: 143313-143316,143318,143319,143321,143323,143327-143331,143333,143334,143336-143341,143343-143406. 110,112 294597, EXCEPT FOR: 293636,293758,293945,294045,294236,294237,294238,294336,294337,294449,294452,294456,294461-294465, 294467,294470,294473-294476,294478,294480,294483,294484,294487,294489,294490,294492,294493,294495- 294497,294499-294506,294509-294519,294521-294528,294530-294541,294543-294560,294562-294596. 115 150531, EXCEPT FOR: 150441,150447,150468-150476,150478-150480,150483-150485,150487-150494,150496-150503,150505-150530. STATE COLOR NUMBER WHEN ORDERING
86
CLIP COVER TO PAD
88
CLIP
104
BACKREST
120
BACKREST FRAME
141
PAD
141
PAD , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1089144816
152
COVER
159
PANELLING , STATE COLOR NUMBER WHEN ORDERING
165
WASHER
168
ADJUSTER LEFT, FROM CHASSIS: 010 004096 015 001848 110,112 010414 115 004254
172
SEAT GUIDE INSIDE LEFT
178
SEAT GUIDE
218
SCREW
221
BACKREST ADJUSTER OUTSIDE LEFT LEFT SEAT, 023827
223
HANDWHEEL , 023827
225
COVERING , 023827
227
LOCK , 023827-069775
229
LOCK , 023827-069775
231
BACKREST ADJUSTER INSIDE LEFT, RIGHT SEAT, 023827
235
LOCK , 023827-069775
247
LINK , 023827
249
SCREW
258
COVERING UPPER PART, LEFT, STATE COLOR NUMBER WHEN ORDERING 028495
263
COVERING LOWER PART, LEFT, STATE COLOR NUMBER WHEN ORDERING 028495
319
SCREW
319
SCREW , Replaced By: A0009909822
319
SCREW , Replaced By: A1249900222
319
SCREW , Replaced By: A1239901022
319
SCREW , Replaced By: A0009909622
319
SCREW , Replaced By: A1409901122
320
NUT RETAINER , Replaced By: A0019902891
999
BACKREST ADJUSTER OUTSIDE LEFT
999
BACKREST ADJUSTER INSIDE LEFT
999
BACKREST ADJUSTER OUTSIDE RIGHT
999
BACKREST ADJUSTER INSIDE RIGHT
999
BACKREST ADJUSTER OUTSIDE RIGHT
999
BACKREST ADJUSTER INSIDE RIGHT
999
COVERING , 023827
999
FOAM PLASTICS FRONT ROOF RAIL
999
SCREW , Replaced By: N914028006100
999
SCREW
999
SCREW , Replaced By: N914028006100
999
SCREW
999
BACKREST
999
BACKREST ADJUSTER , Replaced By: A1089100980
999
BACKREST ADJUSTER , Replaced By: A1089101080
999
BACKREST ADJUSTER RANGE OF DELIVERY LEFT
999
BACKREST ADJUSTER RANGE OF DELIVERY RIGHT
999
PANELLING FRONT SEAT BACKREST
999
LINK , Replaced By: A1119185127
999
SCREW , 023826
999
BACKREST BRACKET
999
ADJUSTER
999
ADJUSTER
999
PLATE RIGHT, 010 FROM CHASSIS 192770 ALSO INSTALLED ON, SEE FOOTNOTE 17, 011 FROM CHASSIS 035338 ALSO INSTALLED ON, SEE FOOTNOTE 18, 110 FR OM CHASSIS 336606 ALSO INSTALLED ON, SEE FOOTNOTE 19
999
SCREW , Replaced By: A1109840332
999
PANELLING
999
COVER
999
SEAT CUSHION
999
ADJUSTER RIGHT
999
COVER
999
BACKREST BRACKET , Replaced By: A1159102132
999
SEAT GUIDE INSIDE RIGHT
999
BACKREST BRACKET COMPLETE,BUT LESS COVER
999
FRONT SEAT LEFT
999
FRONT SEAT LEFT
999
BACKREST
999
FRONT SEAT LEFT
999
FRONT SEAT COMPLETE,BUT LESS COVER
999
FRONT SEAT RIGHT
999
BACKREST , Replaced By: A1089100633
999
FRONT SEAT , Replaced By: A1159107501
999
FRONT SEAT , Replaced By: A1159107601
999
FRONT SEAT , Replaced By: A1159107701
999
FRONT SEAT , Replaced By: A1159107801
999
FRONT SEAT LEFT
999
FRONT SEAT RIGHT
999
FRONT SEAT LEFT
999
FRONT SEAT RIGHT
999
FRONT SEAT RIGHT
999
COVERING , 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648
999
COVERING , 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648
999
COVERING , FROM CHASSIS: 010 025154 015 022707 110 054451 112 054299 115 025120 UP TO CHASSIS: 010 031141 015 028864 110,112 069196 115 031654, Replaced By: A1159132128, +001A1159132728, +001A1159132828, +001A1159133028
999
COVERING , FROM CHASSIS: 010 025154 015 022707 110 054451 112 054299 115 025120 UP TO CHASSIS: 010 031141 015 028864 110,112 069196 115 031654, Replaced By: A1159132228, +001A1159132728, +001A1159132828, +001A1159132928
999
COVERING , FROM CHASSIS: 010 025154 015 022707 110 054451 112 054299 115 025120 UP TO CHASSIS: 010 031141 015 028864 110,112 069196 115 031654, Replaced By: A1159132328, +001A1159132828, +001A1159132928, +001A1159133028
999
COVERING , FROM CHASSIS: 010 025154 015 022707 110 054451 112 054299 115 025120 UP TO CHASSIS: 010 031141 015 028864 110,112 069196 115 031654, Replaced By: A1159132428, +001A1159132728, +001A1159132928, +001A1159133028
999
COVERING , Replaced By: A1159132928
999
COVERING , Replaced By: A1159133028
999
COVERING , Replaced By: A1159132728
999
TUBE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 010 069775 011 009142 015 092410, Replaced By: A1159132828
999
COVERING RIGHT
999
COVERING RIGHT
999
PAD
999
PAD , Replaced By: A1159141214
999
TOOTHED WASHER CABLE TO FUSE BOX
999
TOOTHED WASHER BRACKET TO EXHAUST PIPE BRACKET
999
LOCK PLATE CONTROL SHAFT TO CAB
999
SHEET METAL SCREW
999
SCREW , 023855
999
SCREW , 010 FROM CHASSIS 130558, 110 FROM CHASSIS 225648
999
SCREW
999
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
