Поз.
Артикул
Описание
91
BRAKE MASTER CYLINDER
92
BRAKE MASTER CYLINDER FRONT/REAR BRAKE CIRCUIT "TEVES"
92
BRAKE MASTER CYLINDER
92
BRAKE MASTER CYLINDER , UP TO CHASSIS 603580 ON SPECIAL REQUEST, SEPARATE BRAKE FLUID RESERVOIR FOR HYDRAULIC BRAKE
93
HOUSING
93
HOUSING , ON SPECIAL REQUEST, ONE-CHAMBER AIR BRAKE WITH TWO-LINE TRAILER BRAKE, AND FOOTNOTE 184
94
DICHTRING. SEAL RING
95
SCREW PLUG
95
SCREW PLUG , Replaced By: A0004311756
96
SCREW PLUG
97
STRAINER , TO 000 430 55 01 BRAKE MASTER CYLINDER
98
VALVE CLUTCH SLAVE CYLINDER
98
VALVE , Replaced By: A3075530107
99
PROTECTIVE CAP ,5 962906
99
PROTECTIVE CAP , Replaced By: A0004210887
99
PROTECTIVE CAP , Replaced By: A0004217187
100
SEAL RING AT TANK
101
THREADED UNION
102
BOTTOM VALVE. VALVE , Replaced By: A0015861543
102
DICHTSCHEIBE. SEAL RING
103
KAPPENVENTIL. VALVETO 002 430 31 01,344 430 80 01
103
BOTTOM VALVE. VALVE , Replaced By: A0015861543
104
SPRING
105
WASHER
106
SPRING
107
SPRING RETAINER
108
CUP
109
PISTON
110
FILLER RING
111
CUPBOSCH
112
WASHER
113
SPRINGRING. SNAP RING
114
DISTRIBUTOR , TO TANDEM BRAKE MASTER CYLINDERS 001 430 51 01 AND 001 430 68 01
115
SEAL RING FUEL LINE TO FEED PUMP
116
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
118
SCREWED NIPPLE. CONNECTOR , FOOTNOTE 51 UP TO CHASSIS 010505
119
SEAL RING LINE CONNECTION
154
SWITCH , TO BE ADAPTED DURING ASSEMBLY
154
BRAKE LIGHT SWITCH. SWITCH , Replaced By: A0005456109
154
SWITCH , Replaced By: A0015450809
155
BOOT , 107.042 011568 EXCEPT FOR 010107,010328,010378,011305,011341,011348,011356,011418,011426,011434,011436,011444,011454,011455, 011464,011472,011473,011476,011480,011494,011496,011503,011504,011513,011514,011518,011519,011520, 011526,011528,011531,011533,011535,011537,011538,011539,011541-011567. 107.045 009131 EXCEPT FOR 004581,007703,008068,008344,008400,008401,008455,008627,008724,008836,008842,008885,008911,008920, 008925,008958,008967,008989,008994,009001,009100,009128. 107.046 000986 EXCEPT FOR 000518,000621,000841,000897,000899,000921,000933,000936,000938,000940,000942,000944,000956,000964, 000967,000970,000974-000985.
156
RESERVOIR LESS WARNING DEVICE, UP TO CHASSIS 603580 ON SPECIAL REQUEST, SEPARATE BRAKE FLUID RESERVOIR FOR HYDRAULIC BRAKE
156
RESERVOIR , Replaced By: A0004311302, +001A0004311033
157
FILLER CAP WITH WARNING DEVICE, TO 000 431 09 02 BRAKE FLUID RESERVOIR
158
FILLER CAP , Replaced By: A0004315133
159
SEAL RING
164
BRACKET , UP TO CHASSIS 603580 ON SPECIAL REQUEST, SEPARATE BRAKE FLUID RESERVOIR FOR HYDRAULIC BRAKE
166
LINE FROM BRAKE FLUID RESERVOIR TO BRAKE MASTER CYLINDER, FIRST PART, FOOTNOTE 39 FROM CHASSIS 020238-603580
166
LINE , FOOTNOTE 39 UP TO CHASSIS 020237, Replaced By: A3214202434, +001A0004287235
167
FITTING , 020238
168
BRAKE HOSE FROM BRAKE FLUID RESERVOIR TO BRAKE MASTER CYLINDER, SECOND PART, FOOTNOTE 39 FROM CHASSIS 020238-603580
169
GROMMET , UP TO CHASSIS 603580 ON SPECIAL REQUEST, SEPARATE BRAKE FLUID RESERVOIR FOR HYDRAULIC BRAKE
170
CLAMP
171
HOSE , FOOTNOTE 51 UP TO CHASSIS 010505
172
LINE FROM BRAKE POWER REGULATOR TO BRAKE PRESSURE RELIEF 1200 MM
172
LINE FROM DISTRIBUTOR TO LEFT FRONT WHEEL BRAKE HOSE, L911 UP TO IDENT NO. A 009531,L1112 UP TO IDENT NO. A 013091 L911 FROM IDENT NO. A 010218,L1112 FROM IDENT NO. A 013669
173
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
174
HOSE
176
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
176
LINE FROM DISTRIBUTOR TO RIGHT FRONT WHEEL BRAKE HOSE, L911 UP TO IDENT NO. A 009531,L1112 UP TO IDENT NO. A 013091 L911 FROM IDENT NO. A 010218,L1112 FROM IDENT NO. A 013669
177
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
178
HOSE
179
CLAMP LINE TO HOSE
180
CLAMP BREATHER LINE TO REAR AXLE
181
BRAKE HOSE
181
BRAKE HOSE AT REAR AXLE
182
BRAKE HOSE
182
BRAKE HOSE
182
BRAKE HOSE
183
BRACKET. LOCK , Replaced By: A6525040038
183
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
184
ANGLE , Replaced By: A3414280040
187
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
189
BRACKET , THE OLD PART MUST NO LONGER BE INSJTALLED, Replaced By: A3834280140
189
BRACKET BRACKET TO RIGHT SIDE MEMBER
190
DISTRIBUTOR REAR AXLE,4 478330
190
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
191
LINE FROM TEST CONNECTION TO LEFT WHEEL CYLINDER 1350 MM,4 644237
191
LINE , Replaced By: A3524206828
191
LINE , ON SPECIAL REQUEST, REAR SHOCK ABSORBERS, HIGH-CAPACITY AMBULANCE WITH REAR SHOCK ABSORBERS UP TO CHASSIS 015536, Replaced By: A3524206828
191
LINE , Replaced By: A3404202429
192
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
193
CLAMP BRAKE LINE MOUNTING
194
HOSE BRAKE LINE TO REAR AXLE,4 644238
195
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 650 MM
195
LINE , Replaced By: A3524207028
195
LINE , ON SPECIAL REQUEST, REAR SHOCK ABSORBERS, HIGH-CAPACITY AMBULANCE WITH REAR SHOCK ABSORBERS UP TO CHASSIS 015536, Replaced By: A3524207028
195
LINE , Replaced By: A3404201029
196
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
SCREW SUPPORT TO FENDER
999
SCREW PIPE CLAMP
999
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
999
SCREW BRACKET TO SIDE MEMBER
999
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
999
SCREW , Replaced By: N304017010055
999
NUT
999
NUT BRACKET TO SIDE MEMBER,K 035196
999
NUT , Replaced By: N308675014002
999
NUT RELEASE BEARING LUBRICATION
999
SPRING WASHER PULL ROD TO BRAKE PEDAL AND TO DOUBLE LEVER
999
SPRING WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
999
LOOM TIE HAND PUMP
999
STRAP , UP TO CHASSIS 693686 EXCEPT FOR:500001-599999
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
LOCK WASHER FITTING TO BRACKET
999
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
999
SHEET METAL SCREW , ON SPECIAL REQUEST, COMPRESSED AIR WARNING INDICATOR
999
SEAL RING PNEUMATIC VALVE
999
SEAL RING , Replaced By: N007603010110
999
LOCK PLATE
999
TOOTHED WASHER ELECTRIC CABLE TO FUSE BOX
999
TOOTHED WASHER
999
CONNECTION FITTING LINE CONNECTIONS
999
CAP NUT
999
PIN , Replaced By: N001434010009
999
SCREW BRACKET TO LEFT SIDE MEMBER
999
SCREW CONSOLE TO SIDE MEMBER
999
SCREW BRAKE ANCHOR PLATE TO STEERING KNUCKLE
999
SCREW CONSOLE TO SIDE MEMBER M 12X1.5X35, UP TO IDENT NO. 734559 EXCEPT FOR 500001-599999
999
SCREW
999
STUD BOLT
999
NUT , Replaced By: N308675014000
999
NUT
999
NUT
999
NUT BRAKE ANCHOR PLATE AND STEERING ARM TO STEERING KNUCKLE
999
NUT , Replaced By: N308673014001
999
NUT STRAP TO SUPPORT
999
NUT STRAP TO SUPPORT,5 149419
999
NUT PULL ROD
999
NUT L.H. THREAD
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT BALL PIVOT TO LEVER
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
SCREW , Replaced By: N304017010028
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SCREW , Replaced By: N304017010002
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW BRACKET TO CROSS MEMBER
999
SCREW , Replaced By: N304017008016
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008027
999
SCREW , Replaced By: N304017008021
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW COVER PLATE TO BRACKET
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017010050
999
SCREW
999
SCREW
999
HEX. HEAD. SCREW BEARING BRACKET TO FRAME
999
SCREW VALVE TO BRACKET
999
SCREW VALVE TO CAB M 8X85
999
SCREW , Replaced By: N304017008018
999
SCREW TEST CONNECTION TO BRACKET, ON SPECIAL REQUEST, HYDRAULIC BRAKE TEST CONNECTIONS IN CAB
999
HEX, HEAD. SCREW
999
SCREW
999
RIVET
999
LOCK RING22X1.2,TO 001 431 71 14
999
LOCK RING , FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB DISCONTINUED,PART IS NO LONGER REQUIRED
999
WASHER
999
WASHER VIBRATION ABSORBER TO BRACKET
999
WASHER , Replaced By: N000433010510
999
HEADLESS SETSCREW
999
LOCK WASHER BRACKET TO FRAME
999
LOCK WASHER CONTACT PLATE TO STEERING WHEEL
999
WASHER
999
WASHER
999
WASHER HORN TO ENGINE CROSS MEMBER
999
WASHER , 034 UP TO CHASSIS A 004589
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PINTO 345 431 70 16, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
COTTER PIN BRAKE CABLE TO BRAKE LEVER, 010 UP TO CHASSIS 023660 EXCEPT FOR,SEE FOOTNOTE 59 012 UP TO CHASSIS 049855 EXCEPT FOR,SEE FOOTNOTE 54
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PINTO 360 320 01 89
999
COTTER PIN ,000032
999
COTTER PIN
999
COTTER PIN
999
SCREW
999
SCREW MOUNTING CLAMPS TO SUBSTRUCTURE, FOOTNOTE 39 UP TO CHASSIS 020237
999
SCREW , UP TO IDENT NO. 674067 EXCEPT FOR 500001-599999, 673432, 673497, 673628,673629,673921
999
SCREW SHIFT CASE TO SLOTTED GATE
999
SCREW BRACKET TO CAB CROSS MEMBER
999
SCREW DIODE CASE
999
SCREW LINE TO HOSE
999
CYLINDRICAL PIN DRAIN VALVE, UP TO CHASSIS 001731
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
HANDLE , Replaced By: A3124271220
999
PIN BRAKE SHOE MOUNTING BOLT
999
REPAIR KIT , Replaced By: A3124201178
999
PROTECTIVE CAP , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
999
PIN FORKS TO LEVERS AT REAR AXLE TUBES
999
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
999
HOSE
999
BRACKET PRESSURE REGULATOR, UP TO IDENT NO. 693686 EXCEPT FOR:500001-599999
