Поз.
Артикул
Описание
5
PROPELLER SHAFT FROM TRANSMISSION TO INTERMEDIATE BEARING
5
PROPELLER SHAFT FROM TRANSMISSION TO INTERMEDIATE SHAFT BEARING 1946 MM, 827464 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
PROPELLER SHAFT FROM TRANSMISSION TO INTERMEDIATE BEARING 1789 MM,NO. A 069205
10
PROPELLER SHAFT TUBE , Replaced By: A3414101029
10
PROPELLER SHAFT TUBE ,NO. A 069205
10
PROPELLER SHAFT TUBE
15
GREASE NIPPLE INTERMEDIATE LEVER
20
PROTECTIVE CAP
23
DRIVE FLANGE
23
DRIVE FLANGE
26
UNIVERSAL JOINT CROSS , Replaced By: A3854100231
29
BEARING BUSHING
32
EXPANSION PLUG
35
GREASE NIPPLE
40
SNAP RING2.650 MM
40
SNAP RING2.750 MM
40
SNAP RING2.700 MM
40
SNAP RING2.500 MM
40
SNAP RING2.600 MM
40
SNAP RING2.550 MM
50
CENTERING FLANGETO 318 410 03 01
50
CENTERING FLANGE PROPELLER SHAFT BEARING
55
PROTECTIVE CAP
60
NUT FOLLOWER FLANGE TO PROPELLER SHAFT
65
BRACKET INTERMEDIATE SHAFT BEARING
65
BRACKET , Replaced By: A3224100540
66
REINFORCEMENT BRACKET TO CROSS MEMBER,024208
67
SCREW BRACKET TO CROSS MEMBER,024208
69
LOCK WASHER , Replaced By: N912004010102
70
NUT BRACKET TO CROSS MEMBER
72
RUBBER MOUNTING PROPELLER SHAFT BEARING
75
BALL BEARING
75
BALL BEARING , Replaced By: A3524100051
75
BALL BEARING , Replaced By: A3524100051
75
BALL BEARING PROPELLER SHAFT BEARING
80
BEARING RING , INTERMEDIATE BEARING, BALL BEARING WITH LOCK
91
PROPELLER SHAFT FROM INTERMEDIATE BEARING TO REAR AXLE 1790 MM,NO. A 069204
91
PROPELLER SHAFT FROM INTERMEDIATE BEARING TO REAR AXLE 1775 MM,NO. A 069205
91
PROPELLER SHAFT FROM INTERMEDIATE BEARING II TO REAR AXLE 1775 MM
91
91
152
SCREW , Replaced By: A0079901001
152
SCREW , Replaced By: A3539900001
152
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
155
LOCK WASHER , Replaced By: N912004010102
160
NUT , Replaced By: N308673010001
999
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
999
BALANCING PLATE AS REQUIRED 20 MM
999
BALANCING PLATE AS REQUIRED 60 MM
999
BALANCING PLATE AS REQUIRED 190 MM
999
BALANCING PLATE AS REQUIRED 160 MM
999
BALANCING PLATE AS REQUIRED 95 MM
999
UNIVERSAL JOINT CROSS , Replaced By: A3024100031
