Поз.
Артикул
Описание
7
TEST CONNECTION , L/LP 352/358 UP TO CHASSIS 674067
14
TEST CONNECTION , L/LP 352/358 UP TO CHASSIS 674067
21
T-FITTING AT HAND BRAKE VALVE, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 872788 EXCEPT FOR, 500033-599999
21
T-FITTING AIR RESERVOIR I
28
TEST CONNECTION
35
TEST CONNECTION
35
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
35
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
35
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
42
T-FITTING AIR RESERVOIR I
42
T-FITTING AIR RESERVOIR,CONNECTION: "13", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
56
ELBOW FITTING
63
T-FITTING
70
NUT
70
NUT CHECK VALVE TO AIR RESERVOIR
77
O-RING CHECK VALVE TO AIR RESERVOIR
84
THRUST RING CHECK VALVE TO AIR RESERVOIR
84
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
98
T-FITTING
105
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
105
FITTING , Replaced By: A0009977172
112
T-FITTING EXHAUST-BRAKE POWER CYLINDER
119
T-FITTING TEST CONNECTION
119
FITTING
126
BRACKET TEST CONNECTION
133
SHEET METAL SCREW BUZZER TO CAB,4 374617
140
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
147
LOCK WASHER FITTING TO BRACKET
154
HOSE
161
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
161
LINE , Replaced By: A0005516256
168
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
168
LINE , Replaced By: A0004296201
175
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
175
PLASTIC PIPE RISING PIPE 4X6 MM
182
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
189
UNION NUT
196
GLAND , Replaced By: A0019901667
196
SEAL CONE
203
SLEEVE LEAK LINE
999
FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
