Поз.
Артикул
Описание
8
VIBRATION ABSORBER TWO-GROOVE
8
VIBRATION ABSORBER , Replaced By: A3520304203
8
VIBRATION ABSORBER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 408069YEAR OF MANUFACTURE 1995, Replaced By: A3520305903
14
ALTERNATOR , Replaced By: A0071542702
14
ALTERNATOR , Replaced By: A0071542402
14
ALTERNATOR , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0091540602
14
ALTERNATOR , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
14
ALTERNATOR
14
ALTERNATORN1 28V 10/55A, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
14
ALTERNATOR24 V /27 A, 74KW (100PS /DIN) 039271-043192 93-95KW (126-130PS /DIN) 086327-097403 110-124KW (150-168PS /DIN) 005864-006945
14
ALTERNATOR THREE-PHASE
14
ALTERNATOR , Replaced By: A0091540702
14
ALTERNATOR , Replaced By: A0091541502
20
SCREW , Replaced By: A0009908221
20
SCREW
20
SCREW , Replaced By: A0019900321
20
SCREW , Replaced By: A0009909721
20
SCREW , Replaced By: A0019900821
20
SCREW , Replaced By: A0009909821
20
SCREW , Replaced By: A0009908321
20
SCREW , Replaced By: A0009907921
20
SCREW , Replaced By: A0009907121
20
SCREW , Replaced By: A0019902120
20
SCREW , Replaced By: A0009907621
20
SCREW , Replaced By: A0009909621
20
SCREW
20
SCREW HOUSING
20
SCREW
20
SCREW
20
SCREWTO 005 154 51 02
20
SCREW
20
SCREWTO 005 154 11 02
26
BALL BEARINGTO 005 154 32 02
26
BALL BEARINGTO 007 154 27 02, 009 154 07 02
26
GROOVED BALL BEARING
26
BALL BEARING , Replaced By: A0059812225
26
BALL BEARING , Replaced By: A0079816625
26
GROOVED BALL BEARING , Replaced By: N000625436303
26
GROOVED BALL BEARING
32
BALL BEARING , Replaced By: A0089811225
32
GROOVED BALL BEARING , TO 002 154 38 02 TO 003 154 67 02 TO 002 154 46 02 TO 004 154 46 02
32
GROOVED BALL BEARING SLIP RING SIDE TO 005 154 11 02
32
NEEDLE BEARING
32
GROOVED BALL BEARING
32
BALL BEARINGTO 007 154 27 02, 009 154 07 02
32
BALL BEARINGTO 005 154 34 02
38
CARBON BRUSH SETTO 005 154 34 02
38
CARBON BRUSH SETTO 009 154 07 02
38
CARBON BRUSH SETTO 007 154 27 02
38
CARBON BRUSH SET
38
CARBON BRUSH SET , Replaced By: A0001548114
44
DIODE CARRIER COMPLETE
50
DIODE , Replaced By: A0005485018
50
DIODE POS.
56
DIODE NEG.
56
DIODE , Replaced By: A0005489818
56
DIODE , Replaced By: A0015481118
62
DIODE , Replaced By: A0015481518
62
DIODE
62
DIODE EXCITER TO 003 154 33 02
68
CONDENSER
68
CONDENSER
68
CONDENSER
74
REGULATOR AND CUT-OUTTO 005 154 34 02
74
REGULATORTO 007 154 27 02
74
REGULATOR AND CUT-OUT , Replaced By: A0021543906
74
REGULATOR AND CUT-OUT , Replaced By: A0001541705
74
REGULATOR AND CUT-OUT , Replaced By: A0001541705
80
SCREW , Replaced By: N007985004130
80
SCREW ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
80
SCREW REGULATOR MOUNTING TO 009 154 07 02
86
RECTIFIERTO 005 154 52 02
86
RECTIFIERTO 005 154 83 02,006 154 67 02
86
RECTIFIERTO 005 154 34 02
86
RECTIFIERTO 009 154 15 02
86
RECTIFIER
86
RECTIFIER
86
RECTIFIER , Replaced By: A0001545716
86
RECTIFIER , Replaced By: A0001545816
86
RECTIFIER , Replaced By: A0001544716
86
RECTIFIERTO 005 154 51 02
86
RECTIFIER , Replaced By: A0011541516
86
RECTIFIER
86
RECTIFIER , Replaced By: A0011541416
86
RECTIFIER , Replaced By: A0011541116
86
RECTIFIER , Replaced By: A0011541616
86
RECTIFIER , Replaced By: A0011542116
86
RECTIFIERTO 007 154 24 02,009 154 06 02, Replaced By: A0011541316
86
RECTIFIER , Replaced By: A0011542716
86
RECTIFIER , Replaced By: A0011542116
92
SCREW T-FITTING TO BRACKET M4X25
98
REPAIR KIT
98
REPAIR KIT (PARTS KT),ROTOR TO 007 154 27 02,009 154 07 02
104
REPAIR KIT (PARTS KT),ROTOR TO 007 154 27 02,009 154 07 02
104
REPAIR KIT
104
REPAIR KIT ROTOR TO 005 154 52 02
110
SPRING
116
SPRING
122
SEAL RINGTO 005 154 34 02
122
RINGTO 007 154 27 02
128
GASKET
134
SPRING WASHER , Replaced By: N000137008212
134
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
134
SPRING WASHER HEATER PLUG CABLE HARNESS
134
SPRING WASHER ALTERNATOR CONNECTION W
152
NUT IN CASE OF SUBSEQUENT INSTALLATION
152
NUT
152
NUT , Replaced By: N304032008006
152
NUT , Replaced By: N304032005005
152
NUT BALL PIVOT TO LEVER
164
FANTO 344 154 71 02
164
FAN FAN TWO-GROOVE V-BELT PULLEY TO 006 154 24 02
170
FAN , Replaced By: A0001558518
176
PULLEY
182
FAN ALTERNATOR
188
SCREW BRACKET TO ALTERNATOR
194
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
200
NUT , 002130
206
BRACKET
212
BUSHING
218
CLAMPING PIECE , OM 352 031149 100 PS/DIN OM 352 025865 110 PS/DIN OM 352 068814 126 PS/DIN OM 352 003727 150 PS/DIN
224
NUT TIGHTENER PULLEY TO LEVER
230
NUT , Replaced By: N304035012002
236
SCREW CLAMPING BOLT TO BRACKET
242
WASHER , Replaced By: A6319900140
242
WASHER ELBOW TO TURBOCHARGER
248
NUT
248
NUT , Replaced By: N304032008006
254
CLAMPING BOLT
260
BUSHING
266
SCREW , Replaced By: N304017010035
266
HEXAGON HEAD BOLT VIBRATION ABSORBER TO BRACKET
272
V-BELT SET2 PIECES 12.5X1300
272
V-BELT FAN DRIVE,D 180260
272
V-BELT SET2 PIECES
272
V-BELT SET OF NARROW V-BELTS2 PIECES 12.5X1325
272
V-BELT SET2 PIECES
272
V-BELT FROM ENGINE TO BELT TIGHTENER PULLEY 12.5X1450 MM
278
SCREW SUPPORT TO CYLINDER CRANKCASE M 14X1.5X115
278
SCREW SUPPORT TO SIDE MEMBER M 14X120, TO BE ADAPTED DURING ASSEMBLY
524
PULLEY WATER PUMP
530
FAN
530
FAN
536
INTERMEDIATE PIECE
542
SCREW BRACKET TO APPARATUS SUPPORT
542
SCREW , Replaced By: A0069909301
999
SEAL RINGTO 001 151 96 01
999
SEAL FLANGETO 000 151 76 01
999
SEAL RINGTO 002 151 07 01,002 151 56 01
999
ALTERNATOR , MB PART NO.003 154 81 02BOSCH PART NO. 0 120 400 754 MB PART NO.005 154 11 02BOSCH PART NO. 0 120 400 877 MB PART NO.005 154 34 02BOSCH PART NO. 0 120 469 518 MB PART NO.007 154 27 02BOSCH PART NO. 0 120 469 686, Replaced By: A0051543402
999
ALTERNATOR , MB PART NO.003 154 39 02BOSCH PART NO. 0 120 400 700 MB PART NO.005 154 29 02BOSCH PART NO. 0 120 489 723 MB PART NO.005 154 33 02BOSCH PART NO. 0 120 489 725, Replaced By: A0051543302
999
ALTERNATOR , Replaced By: A0051545102
999
ALTERNATOR , Replaced By: A0051548302
999
ALTERNATOR
999
SPRINGTO 001 151 96 01
999
SEAL RING , Replaced By: A0001513849
999
SEAL RINGTO 003 151 08 01
999
SEAL RINGTO 001 151 96 01
999
SEAL RINGTO 004 151 00 01
999
VIBRATION ABSORBER , Replaced By: A3520303103
999
NUT ALTERNATOR
999
FAN ALTERNATOR
999
PULLEY , Replaced By: A0001557218
999
FAN
999
SOLENOID SWITCH (RELAY PARTS KIT),FOR SUBSEQT.INSTALLATION,AGAINST INTRUSION OF HUMIDITY TO 002 151 07 01
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
SPRING WASHER CLAMP MOUNTING,4 478001
999
NUT WEAR INDICATOR
999
NUT TACHOGRAPH TO BRACKET
999
FITTED WASHER GEAR CLUSTER SHIFT
999
KEYTO 003 151 57 01,002 151 81 01
999
SEAL RING SCREW PLUG
999
SCREW , Replaced By: A0009907430
999
SEAL RINGTO 001 151 38 01
999
V-BELT
999
SPRINGTO 001 151 96 01
999
ALTERNATOR , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0051543102
999
ALTERNATOR
999
STARTING MOTOR , Replaced By: A0031518801
999
STARTING MOTOR , Replaced By: A0031518601
999
STARTING MOTOR , Replaced By: A0031511801
999
STARTING MOTOR , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE, Replaced By: A0031517301
999
STARTING MOTOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 105724, Replaced By: A0031517401
999
V-BELT , Replaced By: A0039975492
999
ALTERNATOR , Replaced By: A0021549002
999
ALTERNATOR , Replaced By: A0021549702
999
STARTING MOTOR , Replaced By: A0031510801
999
SPRINGTO 001 151 38 01
999
SCREWTO 003 151 08 01, Replaced By: A0019904102
999
COUNTERSUNK BOLT W SLOTTO 003 151 08 01
999
SCREW , Replaced By: A0009909621
999
SCREWTO 003 151 86 01/88 01
999
SCREW , Replaced By: A0019902120
999
BELT PULLEY F POLY-V BELT TWO-GROOVE,208848/91
999
PULLEY TWO-GROOVE,208848/91, Replaced By: A0011555815
999
PULLEY , Replaced By: A0011551015
999
ALTERNATOR12V 30A,000032
999
SOLENOID SWITCH ENGAGEMENT RELAY TO 003 151 57 01 DELCO
999
STARTING MOTOR
999
STARTING MOTOR , Replaced By: A0011519601
