Поз.
Артикул
Описание
58
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
59
SCREW SHIFTING ROD TO JOINT
59
HEXAGON HEAD BOLT VIBRATION ABSORBER TO BRACKET
59
SCREW , Replaced By: N304017010035
60
SUPPORT ,352.900-009-000545
62
PIN HYDR. PUMP SUPPORT TO SUPPORT OF FUEL FILTER OR POWER STEERING PUMP,RESP.
63
LOCK WASHERROCKINGER TYP 59 G140,59 G150
65
NUT , Replaced By: N308673016001
80
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
82
SCREW STRUT TO CROSS MEMBER M 10X25
108
PULLEY ,352.900-009-000545
110
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
112
NUT RELEASE BEARING LUBRICATION
112
NUT
115
V-BELT12.5X875,352.900-009-000545
120
BRACKET (CLAMPING BRACKET),HYDRAULIC PUMP
122
WASHER
124
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
126
SCREW , Replaced By: N304017010040
126
SCREW STRUT TO CROSS MEMBER M 10X25
