Поз.
Артикул
Описание
1
AIR CLEANER
1
AIR CLEANER
1
AIR CLEANER , Replaced By: A0080947902
7
FILTER ELEMENT , Replaced By: A0010941804
7
FILTER ELEMENT , Replaced By: A0010941804
7
FILTER ELEMENT
10
GASKET OUTSIDE MANN & HUMMEL
13
FASTENER
13
FASTENER , Replaced By: A0010940055
16
RUBBER BUFFER , Replaced By: A0000940485
16
RUBBER BUFFER
34
REGULATOR
34
REGULATOR , Replaced By: A0000940464, +001A0000940125
34
REGULATOR , THE OLD PARTS MAY BE USED UP ONLY ON VEHICLES NOT EQUIPPED WITH AIR POLLUTION CONTROL, Replaced By: A0000940464
34
REGULATOR , Replaced By: A0000940464
37
SPRING CLIP , Replaced By: A0000940125, +001A0000940464
37
SPRING CLIP
40
NUT , Replaced By: N304035008001
40
NUT
67
INTAKE PIPE
70
AIR CLEANER
70
INTAKE PIPE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0050948102
73
SEAL RING , Replaced By: A0019905051
73
NUT
76
SCREW
79
BOOT
82
BOOT
85
CLAMP BOOT TO STEERING
88
RUBBER BUFFER
91
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
91
SPRING WASHER , Replaced By: N000137008212
94
SCREW , Replaced By: N304017008008
94
HEXAGON HEAD BOLT PROTECTIVE PLATE TO BRACKET
97
SPRING WASHER , Replaced By: N000137008212
97
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
100
NUT
104
SPRING WASHER , Replaced By: N000137008212
104
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
108
WASHER , Replaced By: N000125008443
108
WASHER EXHAUST MUFFLER TO STRAP
112
SCREW PIPE CLAMP
112
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
112
SCREW , Replaced By: N000933008337
112
SCREW , Replaced By: N304017008021
112
SCREW , Replaced By: A0099900101
114
CHAMPION BLIND NUT. NUT RETAINER , Replaced By: A0019901791
114
NUT RETAINER AIR INTAKE PIPE TO CAB, UP TO IDENT NO.4 872645, FROM IDENT NO. SEE GROUP 83
118
RUBBER HOSE. BOOT
121
HOSE , FROM CHASSIS: 130.920,921:108.016 071293
121
HOSE FROM AIR CLEANER TO PIPE ELBOW, ORDER BY THE METER
121
HOSE PROTECTIVE HOSE, FROM CHASSIS: 130.920,921:108.016 071293
121
HOSE , FROM CHASSIS: 114.920,923:114.010 054405 114.021 114.021 004991 180.954,955:114.005,007,008,015,017 063984
121
HOSE , Replaced By: A1020945182
121
HOSE , Replaced By: A0010948382
121
HOSE , Replaced By: A0010944882
121
HOSE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0010948382
127
SCOOP , Replaced By: A0000941011
127
SCOOP , Replaced By: A0000941011
127
SCOOP
130
INTAKE PIPE
133
CLIP PRE-GLOW TIME RELAY TO COWL
136
COMBINATION BOLT
139
BOOT
139
BOOT , Replaced By: A1150940191
999
BRACKET
999
BRACKET , Replaced By: A0000943541
999
GASKET
999
FILTER ELEMENTTO 006 094 63 02
