Поз.
Артикул
Описание
3
MODULATOR
3
MODULATOR ,5 223297 ALLISON 23040001,23040006
3
MODULATOR ,4 8134975 223296 ALLISON 4344,23010714,2301134
3
MODULATOR ,4 813496
5
SEAL RING
7
END PIECE MODULATOR
7
END PIECE MODULATOR TO INJECTION PUMP CONTROL LEVER,4 410548
7
INTERMEDIATE PIECE MODULATOR,290002 ONLY FOR USE WUTH MECHANICAL MODULATOR
11
SPACER TUBE END PIECE TO LEVER,4 410548
11
SPACER TUBE END PIECE TO LEVER,4 410547
16
SCREW CONNECTOR
16
SCREW , Replaced By: N304017006026
16
SCREW , Replaced By: N304017006026
21
WASHER COMPRESSED AIR LINE TO BRACKET
21
WASHER , Replaced By: N009021006208
21
WASHER BRACKET TO TRANSMISSION
23
WASHER RADIATOR TO RUBBER MOUNTING
23
WASHER , Replaced By: N000125010532
26
NUT PUMP TO BRACKET
26
NUT , Replaced By: N913004006001
26
NUT BALL PIVOT TO LEVER
29
BRACKET MODULATOR
29
BRACKET MODULATOR,5 151291
29
BRACKET MODULATOR,5 151291
35
CLAMP CABLE HARNESS MOUNTING
35
CLAMP CABLE HARNESS MOUNTING
35
CLAMP , Replaced By: N000000001045
35
CLAMP , Replaced By: N916016010211
38
SCREW LICENSE PLATE TO BRACKET
38
SCREW , Replaced By: N304017006020
41
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
41
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
44
NUT PUMP TO BRACKET
44
NUT PUMP TO BRACKET
44
NUT , Replaced By: N913004006001
47
WASHER COMPRESSED AIR LINE TO BRACKET
47
WASHER COMPRESSED AIR LINE TO BRACKET
47
WASHER COMPRESSED AIR LINE TO BRACKET
47
WASHER , Replaced By: N009021006208
50
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
50
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
50
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
53
BRACKET PULL ROD TO SUPPORT,5 352764 TO BE ADAPTED DURING ASSEMBLY
53
BRACKET , Replaced By: A3184924841
56
LOOM TIE LINE MOUNTING
59
SPRING ACCELERATOR CONTROL LINKAGE RELEASE SPRING
62
BRACKET RELEASE SPRING
62
BRACKET MODULATOR
62
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3833021540
65
COTTER PIN RIM BOW TO WHEEL SPIDER
999
SLEEVE CONVERSION KIT
999
SCREW , Replaced By: N304017010030
999
WASHER BRACKET TO APPARATUS SUPPORT
999
SCREW , Replaced By: N304017010053
999
SCREW PIPE ELBOW TO BRACKET M 10X50
