Поз.
Артикул
Описание
5
TURBOCHARGER
10
STUD BOLT
15
GASKET CONNECTOR TO EXHAUST MANIFOLD
20
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
25
NUT BRACKET TO SUPPORT AND TO END PIECE
35
ELBOW
50
LEVER
60
OIL FILLER NECK
70
BRACKET
75
PIN BRAKE CYLINDER AND ANGULAR LEVER TO OIL PAN
80
NUT STRAP TO SUPPORT,5 149419
85
LOCK WASHER FITTING TO BRACKET
90
SCREW PIPE CLAMP
90
SCREW , Replaced By: N304017008021
96
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
107
PIN YOKE TO INTERMEDIATE LEVER, FROM IDENT-NO. 002690 EXCEPT FOR 002708
113
WASHER COMPRESSED AIR LINE TO BRACKET
113
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
132
HOSE
136
CLAMP , Replaced By: A0059972990
136
CLAMP , Replaced By: N000000000675
136
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
142
BRACKET
167
OIL LINE
176
SEAL RING VALVE TO VALVE,K 025179
183
HOLLOW SCREW OIL DELIVERY LINE TO CYLINDER CRANKCASE
189
GASKET
189
GASKET , Replaced By: A4421870280
194
SCREW , Replaced By: N304017008021
199
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
206
BRACKET
211
CLAMP TO MOUNT MAIN CABLE HARNESS
221
OIL LINE
226
GASKET
386
THROTTLE HOUSING
391
SHAFT
396
THROTTLE VALVE
396
THROTTLE VALVE , Replaced By: A4031440213, +001A4031440314
402
BRACKET , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A4021400540
402
BRACKET , Replaced By: A4071400140
402
BRACKET
407
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
412
PIN INTERMEDIATE SPEED STOP
412
PIN CYLINDER TO BRACKET
412
PIN , Replaced By: A4221440174, +001N999900008004
412
PIN , Replaced By: A4421440574
442
LEVER , Replaced By: A4031440835, +001A4429915315, +001N000934008013
442
LEVER THROTTLE VALVE
447
SCREW , Replaced By: N304017006012
447
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
452
WORKING CYLINDER (POWER CYLINDER),EXHAUST BRAKE
452
CYLINDER , Replaced By: A0004303026
452
CYLINDER
452
CYLINDER , Replaced By: A0004304926
452
CYLINDER (POWER CYLINDER),EXHAUST BRAKE, Replaced By: A0004307926
452
CYLINDER , Replaced By: A0004305926
459
WASHER , Replaced By: N000125008443
459
WASHER EXHAUST MUFFLER TO STRAP
459
WASHER INTERMEDIATE SPEED STOP
466
BALL SOCKET ROD TO BALL PIVOT
471
NUT ,B 884219
477
GASKET
486
NUT BRACKET TO SUPPORT AND TO END PIECE
496
EXHAUST MANIFOLD
507
GASKET
512
NUT BRACKET TO SUPPORT AND TO END PIECE
522
STUD BOLT CONTROL BLOCK M 10X35
999
STRAINER , Replaced By: A0011843325
999
CYLINDER , Replaced By: A0004302726, +001A4039910222
999
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
999
CYLINDER INTERMEDIATE SPEED STOP
999
REPAIR KITTO 000 430 48 26,KNORR
999
REPAIR KIT POWER CYLINDER TO 000 430 60 26
999
REPAIR KIT SHIFTING CYLINDER TO KNORR, SZ 1130 I/74963,000 430 3026
999
LOOM TIE
999
LOOM TIE , Replaced By: N916018090000
999
LOOM TIE , Replaced By: N916018080000
999
HOSE , Replaced By: A0029979282
999
REPAIR KIT , Replaced By: A0024300060
999
LOOM TIE
999
LOOM TIE , Replaced By: N916018090000
999
LOOM TIE PIPE ELBOW TO COMPRESSOR
999
REPAIR KIT
999
ROD
999
PIN
999
CYLINDER
999
PIPE BEND ENGINE BREATHING
999
BRACKET
999
INTAKE MANIFOLD , Replaced By: A3461404601
999
BRACKET
999
CYLINDER HEAD COVER
999
OIL FILLER NECK
999
OIL FILLER NECK
999
CRANKSHAFT , Replaced By: A3550303601
999
CRANKSHAFT
999
CRANKSHAFT , Replaced By: A3550305001
999
CRANKSHAFT , Replaced By: A3550306701
999
CRANKSHAFT WITH CRANKSHAFT BEARING SHELLS AND CONNECTING ROD BEARING SHELLS, 355 586 39 03 LAPPED BEARING TO BE ORDERED SEPARATELY AND TO BE INSTALLED IN PLACE OF THE ONE INCLUDED IN RANGE OF DELIVERY
999
CYLINDER
999
ELBOW
999
SCREENING PLATE
999
SCREENING PLATE
999
CLAMP
999
ELBOW
999
EXHAUST MANIFOLD , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3551400809
999
LEVER
999
LEVER
999
LEVER , 035612
999
ROD
999
EXHAUST MANIFOLD
999
EXHAUST MANIFOLD
999
GASKET , Replaced By: A3551410480
999
GASKET CONNECTION PIPE ELBOW TO INTAKE PIPE
999
GASKET , Replaced By: A3551420880
999
PIN , 035612
999
OIL LINE
999
OIL LINE
999
OIL LINE
999
OIL FILTER , Replaced By: A3551802310
999
LINE
999
LINE
999
SLEEVE
999
HOSE
999
BALL SOCKET SHIFTING CYLINDER TO SHIFT LEVER
999
BALL SOCKET , Replaced By: A4039910222
999
BALL SOCKET
999
BUSHING"WABCO"
999
CLAMP , Replaced By: A0059972990
999
COTTER PIN BRACKET TO SUPPORT
999
COTTER PIN CYLINDER TO BRACKET
999
WASHER
999
LOCK WASHER CLAMP TO BRACKET
999
SCREW SUCTION BASKET TO BRACKET
999
SCREW TRANSMISSION CASE COVER TO TRANSMISSION CASE, UP TO IDENT NO. 207851 FROM IDENT NO. 207852 SEE MICROFICHE MODEL 712.0
999
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
999
SCREW
999
SCREW , Replaced By: N304017008039
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008016
999
SCREW BRACKET TO FRAME
999
NUT , Replaced By: N304032006004
999
NUT , Replaced By: N304032008006
999
NUT. HOLLOW SCREW
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
999
NUT
999
LOCK WASHER
999
LOCK WASHER
999
CLAMP , Replaced By: N000000000675
999
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
