Поз.
Артикул
Описание
210
SHUT-OFF COCK
210
SHUT-OFF COCK
212
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
213
FITTING TWO-WAY VALVE "12",4 4121264 691315
214
SEAL RING LINE CONNECTION
216
SCREW VALVE TO BRACKET
216
SCREW VALVE TO BRACKET, Replaced By: N304014008002
217
NUT ELECTRONIC ACCELERATOR PEDAL
217
NUT , Replaced By: N913004008001
218
SEAL RING
219
FITTING HYDRAULIC LINE TO BRACKET,K 130132
219
FITTING AT BRACKET
221
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
223
ADAPTER FITTING DRAIN VALVE
225
FITTING FITTING TO BRACKET
232
FITTING RELAY VALVE,CONNECTION: "10",950459
234
UNION NUT LINE CONNECTION, Replaced By: N000000006239
234
UNION NUT LINE CONNECTION
247
SEAL CONE LINE CONNECTION
247
GLAND , Replaced By: A0019901967
260
TEST CONNECTION BULKHEAD FITTING
263
COUPLING REFILLING CONNECTION,CENTER
266
SEAL RING
273
PROTECTIVE CAP TEST CONNECTION
275
PROTECTIVE CAP TEST CONNECTION
275
PROTECTIVE CAP REFILLING CONNECTION
277
FITTING FITTING TO SUBSTRUCTURE
279
FITTING (PARTS KIT),LINE RUPTURE
279
FITTING AIR RESERVOIR
280
WASHER PLATE TO SIDE MEMBER
280
WASHER
280
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
280
WASHER , Replaced By: N000125015019
281
SEAL RING LINE CONNECTION
283
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
283
NUT BRACKET TO SIDE MEMBER
286
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
286
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
286
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
286
TEST CONNECTION
289
BRACKET REFILLING CONNECTION
289
BRACKET TEST CONNECTION,058949
289
BRACKET TEST CONNECTION
290
BRACKET TEST CONNECTION
292
BRACKET AT BRACKET
294
ADAPTER FITTING FLUID RESERVOIR TO BRACKET
296
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
298
O-RING CHECK VALVE TO AIR RESERVOIR
300
FITTING AT BRACKET
300
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
300
FITTING AT BRACKET
300
FITTING , Replaced By: A0009977172
301
FITTING DOOR I ENTRANCE
302
WASHER
302
WASHER , Replaced By: N000125015019
302
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
304
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
304
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
305
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
306
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
307
NUT COVERING TO CAB FIRE WALL
310
GUIDE SIGN
310
UNIT IDENTIFICATION PLATE
999
REPAIR KIT CHECK TO 003 429 07 44
999
BRACKET TEST CONNECTION,058948
999
BRACKET REFILLING CONNECTION
