Поз.
Артикул
Описание
1
TS DOUBLE FITTING SOLENOID VALVE
1
FITTING , Replaced By: A0029906071
7
T-FITTING AT DISTRIBUTOR,4 481288
17
VALVE (SOLENOID VALVE) HERION
19
FITTING LINE CONNECTION, Replaced By: N000000006446
19
FITTING LINE CONNECTION
20
SEAL RING LINE CONNECTION
22
BRACKET VALVE
24
CLAMP , Replaced By: N916016006201
24
CLAMP SENSOR CABLE TO BRACKET
26
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
26
BRACKET FUEL LINES
28
HOSE (QUICK BREATHER VALVE)
28
HOSE
29
SEAL RING LINE CONNECTION
30
SCREW-IN FITTING
31
BRACKET LINE MOUNTING
32
CLAMP LINE MOUNTING
36
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 24X1
37
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
38
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
39
CLAMP , Replaced By: A0005460875
39
CLAMP CABLE HARNESS MOUNTING,4 494992
40
SWITCH TWO-SPEED REAR AXLE CONTROL,4 188089
41
NUT POTENTIOMETER TO INSTRUMENT PANEL
41
NUT ,928519
41
NUT SWITCH TO APPARATUS PLATE
42
BUTTON SWITCH,928519
42
BUTTON TWO-SPEED REAR AXLE CONTROL,4 188089
43
BOOT ,928519
44
BOOT SWITCH,928519
999
SHELL TWO-SPEED REAR AXLE CONTROL,4 188089
999
SHELL TWO-SPEED REAR AXLE CONTROL,4 188089
999
NUT , Replaced By: A0029906251
999
SWITCH , Replaced By: A3445457111
999
REPAIR KITTO 001 997 34 36,002 997 58 36,
999
PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 2.5 MM2
999
REPAIR KIT , Replaced By: A0012608357
999
BRACKET , Replaced By: A3124761236
