Mercedes A0019951910 - ХОМУТ

OM 360 360.980 MANNHEIM

09 FUEL FILTER - 001 FUEL FILTER IL. 3

Поз.
Артикул
Описание
240
A0000944306
FILTER BOWL
245
A0000944206
ELEMENT
250
A0000944180
GASKET INSIDE
252
A0000944080
GASKET OUTSIDE
254
A0019947535
SNAP RING
476
A0059971490
HOSE CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, Replaced By: A0019951910
476
N916017110001
CLAMP , Replaced By: A0059971490
476
A0019951910
CLAMP FROM AIR CLEANER TO TRANSVERSE INTAKE PIPE, TO BE ADAPTED DURING ASSEMBLY
524
A3260940191
BOOT AIR INTAKE PIPE TO AIR CLEANER,950198
999
A0000943542
CLAMP
999
A0000943642
CLAMP
999
A0000943742
CLAMP
999
A0009904667
SEAL CONE
999
A3025281008
AIR INTAKE PIPE , FROM CHASSIS 003029 ALSO INSTALLED ON 002943,002951,002956,002958
999
A3529950332
CLAMP , ONLY APPLICABLE TO MODEL 935 ON CHASSIS WITH 5050-MM WHEELBASE
