Поз.
Артикул
Описание
57
MANIFOLD , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 147242/90, Replaced By: A3660982124
57
MANIFOLD (CHARGING AIR ELBOW)
102
CHARGING AIR INTERCOOLER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 737603/93, Replaced By: A3660981020
102
CHARGING AIR INTERCOOLER , Replaced By: A3660980920
102
CHARGING AIR INTERCOOLER
106
GASKET CHARGING AIR INTERCOOLER,945734
106
GASKET CHARGING AIR INTERCOOLER
106
GASKET
106
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3660982180
108
COVER REAR
110
COVER FRONT,737604/93
110
COVER FRONT,737603/93
120
SEAL RING VALVE
120
SEAL RING , Replaced By: A0189974848
120
SEAL RING REAR
134
SEAL RING FRONT
137
GASKET , Replaced By: A3660982080
137
GASKET
148
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
148
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
148
SCREW CLAMP ON BRACKET
148
SCREW VALVE TO BRACKET M 8X55
148
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
148
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
148
SCREW , Replaced By: N304017008043
148
SCREW , Replaced By: N304017008053
149
SPRING WASHER , Replaced By: N000137008212
149
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
150
LIFTING DEVICE REAR
153
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
156
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
156
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
156
SPRING WASHER , Replaced By: N000137008212
158
BRACKET ,737603/93
160
SCREW ,737604/93
160
SCREW ,737603/93
164
NUT FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22",4 821954
166
DISC SPRING
168
SNAP RING FRONT AND REAR,K 281331
186
SCREW BRACKET TO CONSOLE
186
SCREW , Replaced By: N304017010043
225
SCREW , Replaced By: N910105008019
225
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
226
LINE
231
HOSE 18-MM-DIA. LINE
232
CONNECTING PIPE TURBOCHARGER/CHARGE-AIR-ELBOW CONNECTION
232
CONNECTING PIPE TURBOCHARGER/CHARGE-AIR-ELBOW CONNECTION
232
CONNECTING PIPE TURBOCHARGER/CHARGE-AIR-ELBOW CONNECTION
232
CONNECTING PIPE
233
CLAMP , Replaced By: A0069970490
233
LOOM TIE , Replaced By: N000000000668
233
CLAMP25-40X13 MM
235
FITTING AT AIR COMPRESSOR
237
SEAL RING LINE TO OIL PUMP
239
ANGLE
239
ANGLE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3662030143, +001N916017020000
241
SCREW , Replaced By: N304017008016
241
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
243
CLAMP HOSE TO BRACKET 25/20,5 206397
243
CLAMP , Replaced By: N916016025200
246
SEAL RING , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 355427YEAR OF MANUFACTURE 1994, Replaced By: A0219978448
246
SEAL RING , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 355427YEAR OF MANUFACTURE 1994, Replaced By: A0219978648
246
SEAL RING TURBOCHARGER/CHARGE-AIR-ELBOW CONNECTION
246
SEAL RING
246
SEAL RING , Replaced By: A0279977948
247
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
247
SCREW , Replaced By: N304017008039
249
NUT , Replaced By: N304032008006
249
NUT
302
BRACKET FRONT
302
BRACKET FRONT
304
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
309
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
316
WASHER REAR FOGLAMP TO BRACKET
316
WASHER EXHAUST MUFFLER TO STRAP
323
HEXAGON HEAD BOLT SHIFT LEVER TO CAB FLOOR M 8X45
323
BOLT. SCREW BRACKET TO PUSH ROD CHAMBER COVER
999
NUT
999
SCREW CLUTCH OPERATION,4 282707
999
NUT , Replaced By: N304032010002
999
NUT , Replaced By: N304032008006
999
SCREW SUPPORT TO MOUNTING PLATE,D 180260
999
SCREW SUPPORT TO SIDE MEMBER M 10X65,B 884219
999
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
999
SCREW PLUG
999
SCREW PLUG OIL FILLING
999
WASHER , Replaced By: N000125008443
999
SUSPENSION EYE
999
GASKET
999
INTAKE MANIFOLD
999
INTAKE MANIFOLD
999
ELBOW
999
MANIFOLD (CHARGING AIR ELBOW)
999
CONNECTING PIPE FROM TURBOCHARGER TO CHARGING AIR ELBOW
999
ELBOW
999
CHARGING AIR INTERCOOLER , NOT USED
999
SUSPENSION EYE , NOT USED
999
SUSPENSION EYE
999
INTAKE MANIFOLD
999
INTAKE MANIFOLD , NOT USED
999
INTAKE MANIFOLD
999
ELBOW
999
ELBOW
999
ELBOW (CHARGING AIR ELBOW), NOT USED
999
SUSPENSION EYE
