Поз.
Артикул
Описание
40
40
46
UNION NUT LINE CONNECTION, Replaced By: N000000006243
52
GLAND , Replaced By: A0019901267
58
HOSE
64
CLAMP COOLING WATER LINE TO EXPANSION TANK & TO BUBBLE SEPARATOR
64
CLAMP25-40X13 MM
64
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
70
70
70
94
GLAND LINE CONNECTION
100
UNION NUT LINE CONNECTION
106
106
108
112
118
118
124
124
130
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
130
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
130
130
130
130
136
142
142
148
150
UNION NUT LINE CONNECTION
152
GLAND LINE CONNECTION
154
GLAND , Replaced By: A0019901267
160
UNION NUT LINE CONNECTION, Replaced By: N000000006243
166
SEAL RING
172
FITTING RETURN LINE TO STEERING,5 424435
178
FITTING HIGH PRESSURE LINE TO STEERING
202
SEAL RINGTO 006 997 00 72
208
FITTING POWER STEERING PUMP M16X1,5/M22X1,5,D 084765
214
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
220
CLAMP LINE MOUNTING
226
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
232
SCREW BRACKET TO EXHAUST PIPE BRACKET
238
SHEET METAL SCREW BOOT TO CAB FLOOR
244
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
250
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
256
NUT SPRING-LOADED PUSH ROD
256
NUT BALL PIVOT TO LEVER
262
HOSE FROM PUMP TO STEERING
262
HOSE FROM PUMP TO STEERING
262
HOSE FROM PUMP TO STEERING
268
TANK STEERING OIL TANK
274
COVER , Replaced By: A0004664405
280
SEAL RINGTO 000 466 38 02
286
NUT
292
WASHER HEAT PROTECTION PLATE ON EXHAUST PIPE
298
OIL DIPSTICK
304
RUBBER SLEEVETO 000 466 38 02
310
CENTERING RINGTO 000 466 38 02
316
REINFORCEMENT , Replaced By: A0004660095
322
FILTER CARRIERTO 000 466 38 02
328
SPACER TUBETO 000 466 38 02
334
FITTING , 993034
340
FILTER
340
FILTER , Replaced By: A0004660604
346
CONNECTOR ,12068000, 344.030,031,032,03312009117, 345.001,002,003,300
352
SEAL RING
358
CONNECTOR ,12068001, 344.030,031,032,03312009118, 345.001,002,003,300
364
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
370
NUT TAIL LAMP TO BRACKET
376
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
376
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
382
LOCK WASHER , Replaced By: N912004010102
388
NUT , Replaced By: N910113010000
999
RUBBER RINGTO 321 463 05 32
999
999
