Поз.
Артикул
Описание
5
DOOR LOCK LEFT
5
DOOR LOCK RIGHT
8
CLIP
11
COVERING LEFT, 023 115257 033 048065 123 095185 130 118562
11
COVERING RIGHT, 023 115257 033 048065 123 095185 130 118562
14
SCREW , Replaced By: A1409843029
14
SCREW
17
COMBINATION BOLT
20
LOCKING EYE RIGHT
20
LOCKING EYE LEFT
23
PLATE0.5 MM
23
PLATE , Replaced By: A1167230111
26
PLATE
29
SCREW
32
EDGING LEFT
32
EDGING RIGHT
39
SCREW
39
SCREW
42
INTERIOR HANDLE ASSEMBLY LEFT
42
INTERIOR HANDLE ASSEMBLY RIGHT
45
SCREW
48
NUT RETAINER , Replaced By: A3229900091
51
LOCKING ROD RIGHT
51
DOOR LOCKING DEVICE , Replaced By: A1237330039, +001A1237300121, +001A1009940160
51
DOOR LOCKING DEVICE , Replaced By: A1237330039, +001A1237300121, +001A1009940160
54
LEVER , TO BE ADAPTED DURING ASSEMBLY
57
CLIP
60
RIVET UPPER PART
60
RIVET , Replaced By: A0009906092
63
RIVET , Replaced By: A0009905548
63
WASHER LOWER PART
66
LOCK PULL ROD TO DOOR LOCK
69
LOCKING ROD RIGHT
69
LOCKING ROD LEFT
75
CLIP , Replaced By: A0069886378
75
CLIP
78
PULL ROD RIGHT
78
PULL ROD LEFT
84
CLIP , Replaced By: A0069886378
84
CLIP
87
KNOB , 023 116973 033 048510 123 097280 130 120563
90
LOCK (LOCKING KNOB),DOOR LOCKING MECHANISM, 023 116974 033 048511 123 097281 130 120564
93
ESCUTCHEON LEFT
93
ESCUTCHEON RIGHT
99
SEAL
102
SCREW LINE MOUNTING
105
TOOTHED WASHER CABLE TO FUSE BOX
108
INSERT LEFT
108
INSERT RIGHT
111
DOOR HANDLE
114
SCREW BRACKET TO COVERING
114
SCREW , Replaced By: N000000001145
117
PAD
120
COMBINATION BOLT
