Поз.
Артикул
Описание
2
BEARING BRACKET ,4 247125, Replaced By: A3812901319, +001A3812901016, +001A3812910073, +001A3812910574, +001A3812940707, +001A3819930710, +001N000933006102, +001N912004006102
2
BEARING BRACKET ,4 247126 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 655107, Replaced By: A3812901219
2
BEARING BRACKET CLUTCH, IN CASE OF PEDAL BEARING BRACKET WITH SHIMS,DELIVER ADDITIONALLY: 3X 000939 008136,1X 620 290 03 34 UP TO IDENT NO. 5 238024, SEE SERVICE INFORMATION 29/4
3
STUD BOLT BRACKET TO TRANSMISSION
3
STUD BOLT BRACKET TO CROSS MEMBER
5
WASHER EXHAUST MUFFLER TO STRAP
5
WASHER , Replaced By: N000125008443
7
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
7
NUT , Replaced By: N913004008001
10
STOP PEDAL ASSEMBLY
10
STOP , Replaced By: A3812910186
12
LOCK RING , Replaced By: A0079942041
12
LOCK STOP TO BEARING BRACKET
20
PEDAL ,4 247125, Replaced By: A3812900916, +001A3812901319, +001A3812910073, +001A3812910574, +001A3812940707, +001N000933006102, +001N912004006102
20
PEDAL , Replaced By: A3812901016
20
PEDAL , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS: 4 972492, Replaced By: A6202900216, +001A3529902101, +001N000439008211
20
PEDAL , 415 5 014669 416 5 000516 417 4 972024, Replaced By: A6202900216
20
PEDAL CLUTCH PEDAL,4 915383
25
PIN CLUTCH PEDAL,5 238024
27
NUT , Replaced By: N913004008001
27
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
30
SPACER TUBE CLUTCH PEDAL
32
NEEDLE BEARING , Replaced By: A0119813410
32
NEEDLE BEARING , Replaced By: A0119813410
32
NEEDLE BEARING
34
PAD BRAKE
34
PAD , Replaced By: A1072910182
35
SPRING CLUTCH PEDAL RESET
36
PIVOT PIN PEDAL TO BEARING BRACKET
36
PIVOT PIN PEDAL TO BEARING TUBE,4 257007
38
LOCK PEDAL TO BEARING BRACKET
40
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
41
SCREW COVER PLATE TO BRACKET
42
LOCK RING
42
LOCK RING
45
SPRING RETAINER SPRING TO PUSH ROD
47
SPRING (DEAD CENTER SPRING) 23.2 MM
49
SPRING (DEAD CENTER SPRING) 35 MM
51
SPRING RETAINER SPRING TO PUSH ROD
58
JOINT BEARING ROD TO CLUTCH PEDAL,4 247125
59
NEEDLE BEARING JOINT TO PIN
59
NEEDLE BEARING JOINT TO PIN
59
NEEDLE BEARING JOINT TO PIN
59
NEEDLE BEARING JOINT TO PIN
61
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
67
WASHER BRACKET TO CROSS MEMBER
69
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
72
REPAIR KIT DEAD CENTER SPRING
75
MASTER CYLINDER CLUTCH,LESS DE-AERATION
75
MASTER CYLINDER , Replaced By: A0012956006
75
MASTER CYLINDER , Replaced By: A0012952906
78
VALVE CLUTCH SLAVE CYLINDER
78
VALVE , Replaced By: A3075530107
79
PROTECTIVE CAP ,5 962906
79
PROTECTIVE CAP , Replaced By: A0004217187
79
PROTECTIVE CAP , Replaced By: A0004210887
79
PROTECTIVE CAP , Replaced By: A0004210887
79
PROTECTIVE CAP , Replaced By: A0004217187
82
INTERMEDIATE PIECE CLUTCH MASTER CYLINDER
84
PLUG , Replaced By: A0009971186
84
PLUG
85
REPAIR KIT , Replaced By: A0002903412
85
REPAIR KIT TO MASTER CYLINDER HAVING ALUMINUM PISTON TO 000 295 68 06,001 295 29 06
85
REPAIR KIT TO MASTER CYLINDER HAVING SYNTHETIC PISTON TO 001 295 60 06
90
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
92
SCREW DELIVERY AND SUCTION HOSES TO COUPLING MOUTH CROSS MEMBER,5 598039
93
ROD MASTER CYLINDER
94
NUT , Replaced By: N304035008001
94
NUT
96
ARTICULATION PIECE CLUTCH MASTER CYLINDER
96
ARTICULATION PIECE CLUTCH MASTER CYLINDER
98
NEEDLE BEARING JOINT TO PIN
98
NEEDLE BEARING JOINT TO PIN
98
NEEDLE BEARING JOINT TO PIN
98
NEEDLE BEARING JOINT TO PIN
100
WASHER BRACKET TO CROSS MEMBER
102
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
112
BEARING BRACKET ,4 247125, Replaced By: A3812901519, +001A3812910073, +001A3812940707, +001N000127006205, +001N000933006102
112
BEARING BRACKET BRAKE, 415 5 014668 416 5 000515 417 4 972023
130
PEDAL BRAKE, 415 5 014668 416 5 000515 417 4 972023
135
SPACER TUBE CLUTCH PEDAL
137
NEEDLE BEARING , Replaced By: A0119813410
137
NEEDLE BEARING , Replaced By: A0119813410
137
NEEDLE BEARING
139
PAD , Replaced By: A1072910182
139
PAD BRAKE
155
PIVOT PIN PEDAL TO BEARING TUBE,4 257007
155
PIVOT PIN PEDAL TO BEARING BRACKET
157
LOCK RING
157
LOCK RING
159
SPRING BRAKE PEDAL RELEASE SPRING, 415 5 014668 416 5 000515 417 4 972023
162
LOCK PEDAL TO BEARING BRACKET
164
SCREW COVER PLATE TO BRACKET
167
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
170
MASTER CYLINDER FOR BRAKE VALVE,SEE GROUP 42, 415 5 014669 416 5 000516 417 4 972024
174
BOOT , Replaced By: A0005864729
174
BUSHING , 415 5 014668 416 5 000515 417 4 972023
176
INTERMEDIATE PIECE DEPARTURE ANGLE DEGREE: 45, 415 5 014668 416 5 000515 417 4 972023
178
INTERMEDIATE PIECE DEPARTURE ANGLE DEGREE: 90, 415 5 014668 416 5 000515 417 4 972023
180
SENDER UNIT , Replaced By: A0005455509
180
SWITCH BRAKE FLUID TELL-TALE LAMP, 415 5 014668 416 5 000515 417 4 972023
182
VALVE , Replaced By: A3075530107
182
VALVE CLUTCH SLAVE CYLINDER
184
PROTECTIVE CAP , Replaced By: A0004210887
184
PROTECTIVE CAP , Replaced By: A0004217187
184
PROTECTIVE CAP , Replaced By: A0004217187
190
REPAIR KIT MASTER CYLINDER, 415 5 014668 416 5 000515 417 4 972023
195
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
197
SCREW DELIVERY AND SUCTION HOSES TO COUPLING MOUTH CROSS MEMBER,5 598039
200
YOKE PISTON ROD AND PUSH ROD, 415 5 014668 416 5 000515 417 4 972023
202
ROD PISTON ROD AND PUSH ROD, 415 5 014668 416 5 000515 417 4 972023
204
NUT
206
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
208
WASHER VIBRATION ABSORBER TO BRACKET
211
COTTER PIN CYLINDER TO BRACKET
999
LOCKING CAP ,4 238841 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002951915
999
VALVE , Replaced By: A0009885435
999
BOOTTO 001 295 30 06
999
SPRING RETAINER , Replaced By: A3092910091
999
BRACKET , Replaced By: A3092910091
999
BUSHING , Replaced By: A3092910091
999
BRACKET , Replaced By: A3604292940
999
BRACKET , Replaced By: A3525422840
999
LINE , Replaced By: A3812901714
999
LINE , Replaced By: A3812901814
999
LINE , Replaced By: A3812903214
999
LINE , Replaced By: A3812901614
999
LINE , Replaced By: A3812902214
999
LINE , Replaced By: A3812902314
999
LINE , Replaced By: A3812906413
999
LINE , Replaced By: A3812902414
999
ROD , Replaced By: A3812910233
999
ROD OVER-CENTER ACTING SPRING
999
ROD OVER-CENTER ACTING SPRING
999
PIN PUSH ROD TO PEDAL,4 247125
999
PIN PUSH ROD TO PEDAL
999
SPRING , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO.: 4 164659, Replaced By: A3819930710
999
SPRING , Replaced By: A3819930710
999
GROMMET , Replaced By: A3149970581
999
BRACKET LINE TO ENGINE FRONT CROSS MEMBER
999
BRACKET WITH ENGINE REAR CROSS MEMBER TO RUBBER-MOUNTING CONSOLE,4 276783
999
BRACKET , Replaced By: A3354292440
999
BRACKET LINE TO ENGINE REAR CROSS MEMBER,4 276783
999
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO. 4 337905- 4 413470, Replaced By: A3852952140
999
BRACKET , Replaced By: A3124761535
999
BRACKET BRACKET TO CAB FLOOR,4 655107
999
PIPE , Replaced By: A3872950313
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
NUT PUMP TO BRACKET
999
NUT , Replaced By: N913004006001
