Поз.
Артикул
Описание
310
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
315
UNION NUT BUTT SCREW CONNECTION
320
GLAND LINE CONNECTION
324
THRUST RING BUTT SCREW CONNECTION
328
SEAL RING , Replaced By: N007603012121
328
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
335
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
340
UNION NUT LINE CONNECTION
344
GLAND LINE CONNECTION
350
LINE , Replaced By: A0004296201
350
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
354
UNION NUT
358
GLAND , Replaced By: A0019901667
358
SEAL CONE
365
HOSE FRONT/REAR AXLE BRAKE HOSE 13X22 MM, ORDER BY THE METER
369
FITTING BRAKE HOSE,5 418584
375
UNION NUT FEED LINE
379
SEAL RING , Replaced By: N007603012121
379
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
385
CLAMP , Replaced By: N000000000667
385
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
415
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
419
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
419
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
423
NUT
427
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
436
FITTING , Replaced By: A0039979072
436
FITTING , Replaced By: A0029906071
436
TS DOUBLE FITTING SOLENOID VALVE
480
BRAKE PRESSURE REGULATOR , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 412738, Replaced By: A0014311312
480
BRAKE PRESSURE REGULATOR
485
REPAIR KIT BRAKE POWER REGULATOR TO 000 431 37 12
489
LEVER LEVER TO ROD
493
LEVER LEVER TO ROD
497
SEAL RING LINE CONNECTION
502
T-FITTING
506
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
510
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
514
NUT CHECK VALVE TO AIR RESERVOIR
518
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
518
THRUST RING CHECK VALVE TO AIR RESERVOIR
522
O-RING CHECK VALVE TO AIR RESERVOIR
528
BRACKET BRACKET TO BRAKE POWER REGULATOR
532
BRACKET BRACKET TO BRAKE POWER REGULATOR
540
CONNECTOR , Replaced By: A0004310735
540
CONNECTOR PULL ROD TO LEVER
544
WASHER , Replaced By: N000125008443
544
WASHER EXHAUST MUFFLER TO STRAP
550
ROD
554
CLAMP , Replaced By: N000000000665
554
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
558
BRACKET
562
BALL PIVOT LEVER
562
BALL PIVOT , Replaced By: A3129910120
566
SCREW
570
NUT STRAP TO SUPPORT,5 149419
580
SWITCH
580
SWITCH , Replaced By: A0015455709
580
SWITCH
580
SWITCH , Replaced By: A0015458214
580
SWITCH SOLENOID VALVE
585
BRACKET
589
SPACER RING PIPE ELBOW TO BRACKET,K 023462
589
WASHER , Replaced By: A1894660751
593
NUT STRAP TO BRACKET
598
LOCK PLATE SWITCH TO BRACKET
602
PIN
606
NUT
610
SEALING CORD SWITCH TO BRACKET,46449965 024600
613
NUT SWITCH TO BRACKET
620
DISTRIBUTOR
620
FITTING
624
FITTING CONTROL UNLOCKING MECHANISM HIGHPRESSURE HOSE TO OIL DELIVERY LINE, 415 5 014669 416 5 000516 417 4 9720245 144227
624
T-FITTING CONTROL UNLOCKING MECHANISM HIGHPRESSURE HOSE TO OIL DELIVERY LINE, 415 5 014669 416 5 000516 417 4 9720245 144227, Replaced By: N000000006204
676
DISTRIBUTOR
680
T-FITTING BETWEEN THE LINES
683
BRACKET METAL SPRING BELLOWS
687
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
687
CLAMP ,K 147121, Replaced By: N000000000319
687
CLAMP , Replaced By: N916016008200
687
CLAMP , Replaced By: A3604300143
690
CLAMP LINE MOUNTING
693
CLAMP DELIVERY AND SUCTION LINES TO STEERING
693
CLAMP , Replaced By: A6739950001
693
CLAMP LINE MOUNTING
696
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
698
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
700
NUT BALL PIVOT TO LEVER
704
BRACKET
818
CLAMP
818
CLAMP ELECTRIC CABLE TO FRAME SIDE MEMBER
824
CLAMP CABLE HARNESS MOUNTING,4 494992
999
BUSHING DAMPING SPRING
999
LINE , Replaced By: A0005516256
999
T-FITTING AIR RESERVOIR I
999
VALVE PARKING BRAKE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
YOKE , Replaced By: A0004310667
999
METAL SPRING BELLOWS , Replaced By: A0004311418
999
VALVE FRONT
999
TEST CONNECTION
999
BRAKE PRESSURE REGULATOR. REGULATOR VALVE LESS LEVER,LOAD-DEPENDING
999
VALVE DISC , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
PLUG SOCKET , Replaced By: A3805400281
999
MAGNET , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
PIN BUSHING , Replaced By: A0075458226
999
REPAIR KITHERION,94171034/0711/24V,94172034/0711
999
REPAIR KITWABCO
999
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
999
CLAMP LINE CONNECTION
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
LOOM TIE , Replaced By: N916017020000
999
SPRING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
999
FIXING CLAMP. CLAMP , Replaced By: A0005460875
999
BRACKET , Replaced By: A6533260940
999
SWINGING LINK
999
BRACKET DAMPING SPRING STOP
999
BEARING BRACKET , Replaced By: A3353900035
999
DAMPING SPRING TORSION BAR,REAR
999
BEARING SHELL TOP
999
BEARING SHELL BOTTOM
999
BRACKET
999
BRACKET MOUNTING USED FOR COMPRESSED AIR LINES,974675
999
BRACKET
999
BRACKET OIL LINE MOUNTING
999
SCREW
999
SCREW PLUG AT TANK
999
BRACKET , Replaced By: A3934311140
999
BRACKET , Replaced By: A3464910441
999
BRACKET RELAY
999
CYLINDRICAL PIN , Replaced By: N001434014055, +001N000094004025, +001N000433015002
999
COTTER PINTO 345 460 94 05
999
COTTER PIN RIM BOW TO WHEEL SPIDER
999
COTTER PINROCKINGER TYP 260 G140
999
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
999
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
999
PIN TRAILING AXLE DETENT,966197
999
SCREW PLUG RELAY VALVE,CONNECTIONS: "23"
999
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
